PFSS6PKXASS General Electric Refrigerator - Overview

Sections of the PFSS6PKXASS

[Viewing 9 of 9]

Manuals & Care Guides for PFSS6PKXASS

Click to download
Keep searches simple, eg. "belt" or "pump".
Refrigerator Ice and Water Filter – Part Number: MWFP
Refrigerator Ice and Water Filter
★★★★★
★★★★★
(66)
PartSelect #: PS8746144
Manufacturer #: MWFP
This OEM ice and water filter fits side-by-side and bottom-freezer GE models. The most common reason you would need to change this part is if you have never updated your model and it is no longer filt...
$67.55
  In Stock
French Spring – Part Number: WR02X12650
French Spring
★★★★★
★★★★★
(19)
PartSelect #: PS2322785
Manufacturer #: WR02X12650
Sold individually.
$12.03
  In Stock
French Spring Pin – Part Number: WR02X12651
French Spring Pin
★★★★★
★★★★★
(3)
PartSelect #: PS2322786
Manufacturer #: WR02X12651
This is a replacement spring pin for French door-style refrigerators. This part is made of white plastic and is approximately ½ an inch in length. If the mullion that keeps the doors closed is not wor...
$9.63
  In Stock
Pantry Flip Lid Cover – Part Number: WR32X10666
Pantry Flip Lid Cover
★★★★★
★★★★★
(14)
PartSelect #: PS2338104
Manufacturer #: WR32X10666
This is the replacement pantry flip lid cover for your refrigerator. It is made of clear and white plastic and is approximately 30 inches in width and 6 inches in length. The pantry flip lid cover is ...
$118.61
  In Stock
Pantry Cover Frame - White – Part Number: WR32X10668
Pantry Cover Frame - White
★★★★★
★★★★★
(6)
PartSelect #: PS2338106
Manufacturer #: WR32X10668
This is just the frame. The insert window must be order separately.
$64.91
  In Stock
Vegetable Pan Cover – Part Number: WR32X10662
Vegetable Pan Cover
★★★★★
★★★★★
(8)
PartSelect #: PS2338100
Manufacturer #: WR32X10662
This part includes both the glass and the frame.
$255.94
  In Stock
French Door Hinge – Part Number: WR13X10516
French Door Hinge
★★★★★
★★★★★
(4)
PartSelect #: PS2322947
Manufacturer #: WR13X10516
This part is the replacement French door hinge for your refrigerator. It is made of white plastic and is approximately 1 ¼ inch by 1 inch. The French door hinge can also be known as the flipper hinge....
$19.70
  In Stock
Ice Bucket Assembly with Auger – Part Number: WR29X10097
Ice Bucket Assembly with Auger
★★★★★
★★★★★
(17)
PartSelect #: PS2371090
Manufacturer #: WR29X10097
Used in bottom mount refrigerators.
$241.13
  In Stock
Refrigerator Door Bin – Part Number: WR02X12664
Refrigerator Door Bin
★★★★★
★★★★★
(5)
PartSelect #: PS2322799
Manufacturer #: WR02X12664
Sold individually.
$142.18
  In Stock
Evaporator Fan Motor – Part Number: WR60X10254
Evaporator Fan Motor
★★★★★
★★★★★
(4)
PartSelect #: PS2338132
Manufacturer #: WR60X10254
This evaporator fan motor is located in the back of the freezer, and circulates air over the refrigerator coils. These coils will convert the heat into cool air, which is then circulated.
$241.23
  In Stock

Questions And Answers for PFSS6PKXASS

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

6 questions answered by our experts.
    Sort by:
    Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
    Sandy
    January 22, 2020
    It won't cool or freeze. The circuit board was jiggled and it started to cool and freeze for a couple of days, then warmed up again. The circuit board was replaced but then the fan and compressor would not turn on. Told it was the compressor. Could it be the start relay switch or something else?
    For model number PFSS6PKXASS
    Hello and thank you for writing. Yes, it could be the compressor start relay PS2322852, you should check the part(s) for signs of damage, and replace as necessary. We hope this helps. Please contact us anytime if you require further assistance.

    1 person found this helpful.

    Was this helpful?
    Thank you for voting!
    Related Parts:
    Jerry
    March 4, 2020
    How to remove fan motor
    For model number PFSS6PKXASS
    Hello Jerry, Thank you for your question. Unplug the fridge, then remove the shelves to gain access to the back panel to remove the screws out so you can gently pull the panel out. There are 2 wire connections in the upper right corner, so disconnect the wires making sure you take pictures of how they were connected, then remove the 4 screws holding the metal fan panel in place. When its removed, twist the fan 90 degrees and it will be free, and a spring clip that holds the fan blades on the motor will need to be removed. Use a pair of needle hose pillars to pull the spring clip off, then finally pull the fan blade off the motor. Reverse the process for re installation. We hope this helps.

    1 person found this helpful.

    Was this helpful?
    Thank you for voting!
    Leroy
    August 3, 2021
    Does not mak ice there’s water flow but no ice it’s on unlock mode i just recently changed filter Help
    For model number PFSS6PKXASS
    Hi Leroy, Thank you for your question. If you have just replaced the water filter, it is important to flush the water filter before using it. Also check the lines that provide water to the ice maker to see if they have an ice blockage. If you have already done this, there are some parts that you will need to check to see which one is causing the issue. You will need to check the ice maker assembly, the water inlet valve and the ice bucket assembly with auger. We hope this helps! Good luck with the repair!

    Was this helpful?
    Thank you for voting!
    Related Parts:
    Joann
    January 7, 2022
    my fridge is leaking water in the bottom under the long drawer, how can I find the leak? Please help
    For model number PFSS6PKXASS
    Hello JoAnn, Thank you for your inquiry. The most common causes of the refrigerator leaking water are the water filter, the filter housing and the water inlet valve. To check the water filter head and water inlet valve, first unplug the refrigerator and turn off the water supply. Remove lower cover of the back compartment. This will expose the water valve. Once you have valve exposed you will disconnect the water supply line and line to the valve. Once this is done, there is a cover at the top of the refrigerator where the lines go into the cabinet. Remove cover then go to the front of unit. With doors open remove the filter and cover over the filter head. Once removed there will be a 1/4 " screw holding the filter head in place. You can now check the valve, water tubing and the water filter head for any leaks. Good luck with your repair.

    Was this helpful?
    Thank you for voting!
    Related Parts:
    Steven
    December 16, 2019
    I’m looking for the long inside door magnets
    For model number PFSS6PKXASS
    Hi Steve, thank you for your question. It sounds like you are looking for your mullion. That would be this part: PS2322804. Good luck with your repair.

    Was this helpful?
    Thank you for voting!
    Related Parts:

      Common Symptoms of the PFSS6PKXASS

      [Viewing 9 of 9]
      Not dispensing water
      Fixed by
      these parts
      Show All
      Door won’t open or close
      Fixed by
      these parts
      Show All
      Ice maker not making ice
      Fixed by
      these parts
      Show All
      Leaking
      Fixed by
      these parts
      Show All
      Ice maker won’t dispense ice
      Fixed by
      these parts
      Show All
      Ice maker dispenses too little ice
      Fixed by
      these parts
      Show All
      Noisy
      Fixed by
      these parts
      Show All
      Fridge too warm
      Fixed by
      these parts
      Show All
      Touchpad does not respond
      Fixed by
      these parts
      Show All
      Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
      Replace water filter
      Unscrew old filter and remove(counterclockwise). Line up arrow on new filter with arrow on connection housing. Turn clockwise till resistance met. Do not overtighten. Follow directions. Simple.
      Parts Used:
      Refrigerator Ice and Water Filter
      • Alfred from Novato, CA
      • Difficulty Level:
        Really Easy
      • Total Repair Time:
        Less than 15 mins
      216 of 321 people found this instruction helpful.
      Was this instruction helpful to you?
      Thank you for voting!
      Pantry drawer lid had broken pivot
      First, I have to say I live in the next state over, and I recieved the parts the next day. Yeah! OK, I removed the adjacent drawers *and the removable lower storage shelves on the doors for clearance*. Taking out the broken lid is easy. The new one is a tight fit. The right side has a raised pad on the pivot point, but the left one does not. I worked the peg (pivot point) in on the right side and slowly and carefully pushed the stationary plastic left side in slightly(and sprung the lid slightly) to get enough clearance to get in the left peg without breaking the new lid pivot. While doing this, one has to make sure the shelf immediately behind the lid is in place since there are support tabs located on it, and you will have to rework the thing if you don't get them to mate on the installation.
      Parts Used:
      Pantry Flip Lid Cover
      • James from Painesville, OH
      • Difficulty Level:
        A Bit Difficult
      • Total Repair Time:
        15 - 30 mins
      45 of 57 people found this instruction helpful.
      Was this instruction helpful to you?
      Thank you for voting!
      water running slow
      unscrewed old filter by hand, installed new filter.
      Parts Used:
      Refrigerator Ice and Water Filter
      • David from Tacoma, WA
      • Difficulty Level:
        Really Easy
      • Total Repair Time:
        Less than 15 mins
      33 of 48 people found this instruction helpful.
