Cold Control Thermostat – Part Number: 241537103
( Grid squares measure 1x1 inch )
Cold Control Thermostat – Part Number: 241537103 Cold Control Thermostat – Part Number: 241537103 Cold Control Thermostat – Part Number: 241537103 https://partselectcom.azureedge.net/Schematics/Frigidaire/ZTS1DPTU.gif

Cold Control Thermostat

PartSelect Number PS8769007

Manufacturer Part Number 241537103

Manufactured by Frigidaire

Product Description

Cold Control Thermostat Specifications

This cold control thermostat cycles on and off regularly to keep your refrigerator cold.

How Buying OEM Parts Can Save You Time and Money

Troubleshooting

This part fixes the following symptoms:

Fridge too warm | Will Not Start | Freezer section too warm | Fridge too cold

This part works with the following products:

Refrigerator.

This part works with the following brands:

Frigidaire, Kenmore, Crosley, Westinghouse, Gibson, Kelvinator, Electrolux, Tappan, Uni.

Part # 241537103 replaces these:

241537101, 5304421256, 5304445058, AP5803894.
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
20 questions answered by our experts.
Sort by:
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Part Videos

Replacing your Frigidaire Refrigerator Cold Control Thermostat

Customer Repair Stories
Average Repair Rating: 3.3 / 5.0, 4 reviews What's this?
Sort by:
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Bruce from Alton, IL
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Pliers, Screw drivers
Parts Used:
241537103
Refrigerator would not run but interior light was on.
I unplugged the refrigerator, then opened the door and removed four screws holding the plastic electrical panel to the interior top of the main refrigerator compartment and noticed the cold control was corroded badly, apparently from moisture in the panel. I ordered a new one from partselect.com. When it arrived the next day, I then pulled off the control knob, unclipped the cold control, unplugged the three wires to the control, then removed the styrofoam insulation blocks holding the thermocouple wire and then removed the thermocouple wire to complete the removal. I then reversed the process to install the new thermostat and control. That is repositioned the thermocouple wire, put the insulation blocks back to hold the wire, then replugged the three electrical wires, clipped the control back and pushed the control knob back on and finally screwed the panel back to the top of the main compartment and plugged the refrigerator electrical cord back in to provide current to the refrigerator. It immediately started up and ran fine. Total time - about 8 minutes.
165 of 214 people found this instruction helpful.
Was this instruction helpful to you?
Charles from NEW YORK, NY
Difficulty Level:
Easy
Total Repair Time:
More than 2 hours
Tools:
Nutdriver, Socket set
Parts Used:
5303918549, 241652301, 241537103, 5303918202, 215846602
top freezer working properly, but lower fridge not cooling.
since I had my fridge since 2003 it seems that I've gotten my moneys worth but it has worked flawlessly with no issues. I did not want to part with it so I troubled shoot the system and realized that it could have been number of things so I just decided after reading some reviews here on this site I decided to just purchase the items that would be effecting the fridge not working properly which was the evaporator fan, defrost thermostat, defrost timer, temperature cold control thermostat, I also cleaned the condenser coils in the back of the unit so they can be able to withdraw heat from the unit. my repair and installation took about 4 hours due to the cleaning of the coils but now the fridge is working like brand new. thanks to this sitt and it's comprehensive video tutorials on installations and repair it my job a lot easier to do.this is not my first time ordering from this site and will not be my last. anyone considering ordering from this site do not hesitate there are great with parts and customer service.
15 of 19 people found this instruction helpful.
Was this instruction helpful to you?
Kenneth from SAVANNAH, GA
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver
Parts Used:
241537103
Not running
After waiting over 2wks for my part to arrive, I purchased the part locally and made the repair the same day as I am still waiting for the part to arrive from you guys. Your customer service really needs improving. I paid for 2 day shipping, what a joke. I will be returning the part as soon as I receive it thanks.
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Orlando from FT LAUDERDALE, FL
Difficulty Level:
Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver, Pliers, Screw drivers
Parts Used:
241537103, 215846604
Freezer no freezing the food
Disconnect the power. To install the Defrost timer which is located inside the console at the top of the fridge I followed a YouTube video. It is very easy. Keep in mind that the Defrost timer comes settled in defrost mode so the compressor will not start after the power is reconnected.There is a hole in the console just behind the Defrost timer where you engaged it with a flat driver and rotate the clock until the compresor start. Now the compressor works for 6 hours and stop for 20 minutes for the defrosting cicle. The freezer now is freezing the meat!!
1 person found this instruction helpful.
Was this instruction helpful to you?
Customer Reviews
Average Rating:
6 Reviews
4.8
out of 5
Filter By Rating:
  • 5 Stars
    5
  • 4 Stars
    1
  • 3 Stars
    0
  • 2 Stars
    0
  • 1 Stars
    0
Sort by:
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Model Cross Reference

This part works with the following models:

PartSelect Number: PS8769007
Manufacturer Part Number: 241537103
Brand
Model Number
Description
Kenmore
25331113300
Refrigerator
Kenmore
25331113302
Refrigerator
Kenmore
25331113304
Refrigerator
Kenmore
25331113308
Refrigerator
Kenmore
2533111330A
Refrigerator
Kenmore
2533111330B
Refrigerator
Kenmore
2533111330C
Refrigerator
Kenmore
2533111330D
Refrigerator
Kenmore
2533111330E
Refrigerator
Kenmore
2533111330F
Refrigerator
Kenmore
2533111330G
Refrigerator
Kenmore
2533111330H
Refrigerator
Kenmore
2533111330J
Refrigerator
Kenmore
2533111330K
Refrigerator
Kenmore
2533111330L
Refrigerator
Kenmore
25331115300
Refrigerator
Kenmore
25331115302
Refrigerator
Kenmore
25331115304
Refrigerator
Kenmore
25331115308
Refrigerator
Kenmore
2533111530A
Refrigerator
Kenmore
2533111530B
Refrigerator
Kenmore
2533111530C
Refrigerator
Kenmore
2533111530D
Refrigerator
Kenmore
2533111530E
Refrigerator
Kenmore
2533111530F
Refrigerator
Kenmore
2533111530G
Refrigerator
Kenmore
2533111530H
Refrigerator
Kenmore
2533111530J
Refrigerator
Kenmore
2533111530K
Refrigerator
Kenmore
2533111530L
Refrigerator
