Single Solenoid Water Valve 218859701 | Official Frigidaire Part | Fast Shipping | PartSelect
Single Solenoid Water Valve – Part Number: 218859701
Single Solenoid Water Valve – Part Number: 218859701 Single Solenoid Water Valve – Part Number: 218859701 Single Solenoid Water Valve – Part Number: 218859701 https://partselectcom.azureedge.net/Schematics/Frigidaire/WYMB2KPX.gif

Single Solenoid Water Valve

Product Description

Single Solenoid Water Valve Specifications

This valve has a 1/4" compression inlet.

How Buying OEM Parts Can Save You Time and Money

Troubleshooting

This part fixes the following symptoms:

Leaking, Ice maker not making ice, Not dispensing water.

This part works with the following products:

Refrigerator.

This part works with the following brands:

Frigidaire, Kenmore, Gibson, Westinghouse, Uni.

Part # 218859701 replaces these:

218859701, 452316, AP2115350.
Questions and Answers
Ask our experts a question on this part and we'll respond as soon as we can.
Sort by:
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Part Videos

Replacing your Frigidaire Refrigerator Single Solenoid Water Valve

Customer Repair Stories
Average Repair Rating: 3.4 / 5.0, 18 reviews What's this?
Sort by:
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Billy from Newport News, VA
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Screw drivers, Wrench set
Parts Used:
218859701
no water for ice-maker or cold water
Unplugged refrig and shut off water supply. Removed cardboard backing on back of refrig. Then removed water lines and power plug from old water valve. Removed screws holding water valve on refrig chassis. Attached water lines and power plug to new water valve. Then repeated the above steps in reverse order. Took a max of 30 mins to install the water valve and worked properly when plugged in refrig and turned water supply on.
42 of 47 people found this instruction helpful.
Was this instruction helpful to you?
Ted from Glendale, AZ
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Wrench (Adjustable)
Parts Used:
218859701
No water from dispenser in front or fill the icemaker
Since we will be working with water and do have an electrical connection nearby, it will be best to unplug the refrigerator to do this repair. It should only take about 15-20 minutes to complete the repair so your contents in the refrigerator should be fine.

1-SImply pull your referigerator away from the wall and unplug it.

2-Locate water supply valve and turn off water to refrigerator by closing the water valve.

3-Remove two 1/4" screws that hold the black "cardboard" cover at the bottom right corner of refrigerator.

4-Then locate the two 1/4" screws holding a light blue valve assembly, again in the bottom right corner of refrigerator. Remove screws and assembly will be loose.

5- Remove water line from the top of the valve assembly you just loosened.

6-Then unscrew the large plastic nut on bottom of valve assembly.

7-Unplug the electrical connector that is on the top of the valve assembly.

8-Install the new valve by reversing the installation. Plug in electrical connector, tighten water line on bottom of assembly, re-attach/tighten main water line on top of assembly- and re-attach valve assembly to refrigerator and re-install cardboard cover. Turn on water supply to refrigerator and check for leaks. Don't forget to plug the refrigerator back in.

Thats it! Problem solved!
16 of 19 people found this instruction helpful.
Was this instruction helpful to you?
Anil from SOMERSET, NJ
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Screw drivers
Parts Used:
218859701, 218832401
No water coming in to the water dispenser or the ice maker
Went online to the Part Select to look for the possible parts that could affect the water delivery. Noticed there were 2 parts that could possibly affect the delivery. Purchased both the parts. Shipped promptly and received in no time. First changed the water valve and checked water was flowing easily to both the places. Did not have to replace the Dual Inlet Water Valve. Called customer service to return the valve. The retrun went smoothly and monet credited to my charge account. Not my first time dealing with this company and will certainly recommend to every one I know.
12 of 13 people found this instruction helpful.
Was this instruction helpful to you?
Jeffrey from Simpsonville, SC
Difficulty Level:
Easy
Total Repair Time:
30 - 60 mins
Tools:
Screw drivers, Socket set
Parts Used:
218947201, 218859701
Ice maker would not fill with water
Both water valves on this model have small rubber seals in them. When the seals wear, they stick and do not open, preventing water flow. To replace;
- unplug
- remove back bottom cover
- unplug valve
- remove valve
- detach water inlet and outlet (put a towel under first)
- install new valve in opposite order
11 of 21 people found this instruction helpful.
Was this instruction helpful to you?
brent from central city, KY
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver, Wrench (Adjustable)
Parts Used:
218859701
Ice maker was not working.
I checked all areas such as water flow in the door and to see if any of the lines from the water valve was clogged. After finding that the lines were clear and the water flow was good through the door. I also checked the Ice maker to make sure it was going through its cycles. I also noticed the valve was making a loud noise when it would try to put water in the Ice maker. I did check the line to the Ice maker inside the refrigerator to see if the water had frozen in the tube. I removed the two screws that hold in the valve and reconnected the water line and the line heading to the lce maker and now my Ice maker is fully functional and making ice like always. The repair was easy and anyone could do it. Also remember to unplug appliances when you work on them, just a safety reminder.
3 of 4 people found this instruction helpful.
Was this instruction helpful to you?
Richard from INDIANAPOLIS, IN
Difficulty Level:
Very Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver, Wrench set
Parts Used:
218859701
No water to dispenser or ice cube maker
Since I didn't have any water to both dispenser or cube maker, I assumed I needed the Double Solenoid Water Valve. I first ordered and installed the double valve, but it did not solve my water supply. I then ordered the Single Solenoid Water Valve and installed it per instructions. These valves are easy to install and do not take over 15 minutes. The water is now flowing to both dispenser and cube maker and everything is working like new. I probably would not have needed to buy the double solenoid valve, but since my refrig was about 20 years old, I left it installed.
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Claude M. from Kerrville, TX
Difficulty Level:
A Bit Difficult
Total Repair Time:
More than 2 hours
Tools:
Nutdriver, Wrench (Adjustable)
Parts Used:
218859701
water leak at valve, no ice, no water thnbrough the door
The repair would have been very easy, however, the replacement valve had a change to the outlet size from 5/16" to 1/4". I had to build a reducer coupling (brass). I have been searching for a quick connect poly reducing union that is leak free. I had to order one as it is not a standard item at Home Depot, Lowes, etc. As we stand now, I have ice cubes and cold water through the door. Found a crack in the 5/16" original line at the connection. Cut that section away and put the coupling in. Had to really tighten up on the brass fitting to stop any minor leaks. It has been leak free for 4 days, but I will still put the quick connect part in when it arrives. BTW Parts Select does not stock the quick connect reducing union.
2 of 3 people found this instruction helpful.
Was this instruction helpful to you?
Maurice from Dallas, TX
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers, Wrench set
Parts Used:
218859701, 218832401
Of course : no water ; no ice
Easy repair, matched parts from this web-site, removed several screws for each valve assy, installed each item, had water & ice !!!!! Both items $90 w shipping, we went to dinner with the money saved from not calling some a tech to repace them east items.
2 of 6 people found this instruction helpful.
Was this instruction helpful to you?
Robert from Gilberts, IL
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Pliers
Parts Used:
218859701
No water at the fridge door and no ice being made.
Nut drivered off the old on, Disconnected the water line in and the water line out. Installed both water lines onto new valve and attached back on to refridgerator and presto magic water and ice again.
1 person found this instruction helpful.
Was this instruction helpful to you?
Maury from Chandler, AZ
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Pliers, Screw drivers, Socket set, Wrench (Adjustable)
Parts Used:
218859701
No water was running to make ice
The main water valve did not open when we wanted to get water out from the refrigerator, nor did any water get delivered to the ice maker when it called for water (to make ice cubes).

Replaced the bad inlet water valve, and we are back in business....
1 person found this instruction helpful.
Was this instruction helpful to you?
Customer Reviews
Average Rating:
6 Reviews
4.7
out of 5
Filter By Rating:
  • 5 Stars
    5
  • 4 Stars
    0
  • 3 Stars
    1
  • 2 Stars
    0
  • 1 Stars
    0
Sort by:
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Model Cross Reference

This part works with the following models:

PartSelect Number: PS429085
Manufacturer Part Number: 218859701
Brand
Model Number
Description
Kenmore
253.59683390
Refrigerator - Kenmore Refrigerator Model 253.59683390 (25359683390, 253 59683390) Parts
Kenmore
25350682000
Refrigerator
Kenmore
25350682001
Refrigerator
Kenmore
25350682002
Refrigerator
Kenmore
25350683000
Refrigerator
Kenmore
25350683001
Refrigerator
Kenmore
25350683002
Refrigerator
Kenmore
25350684000
Refrigerator
Kenmore
25350684001
Refrigerator
Kenmore
25350684002
Refrigerator
Kenmore
25350689000
Refrigerator
Kenmore
25350689001
Refrigerator
Kenmore
25350689002
Refrigerator
Kenmore
25358082891
Refrigerator
Kenmore
25358082892
Refrigerator
Kenmore
25358082893
Refrigerator
Kenmore
25358082894
Refrigerator
Kenmore
25358082895
Refrigerator
Kenmore
25358082897
Refrigerator
Kenmore
25358082898
Refrigerator
Kenmore
25358082899
Refrigerator
Kenmore
2535808289A
Refrigerator
Kenmore
2535808289B
Refrigerator
Kenmore
25358085891
Refrigerator
Kenmore
25358085892
Refrigerator
Kenmore
25358085893
Refrigerator
Kenmore
25358085894
Refrigerator
Kenmore
25358085895
Refrigerator
Kenmore
25358085897
Refrigerator
Kenmore
25358085898
Refrigerator
