Model Number Locations
1Select Category Type
Select Category Type
2Select Product Type
Select Product Type
3Select {MODEL} Type
Select {MODEL} Type
Sample Model Number Tags
Model numbers can be made up of numbers (1005400, for example) or a combination of letters and numbers (LAT1000AAE). The model number will most likely appear on either a paper sticker or a metal plate. Your appliance's model number tag may look similar to the sample model number tags shown here (model number highlighted in yellow):
Give your washing machine a new lease of life with this authentic LG Pulsator Assembly! This original part by LG can greatly enhance the efficiency of your machine. This assembly is key to ensuring your laundry is moving properly through the water, as it rotates back and forth at the bottom of the spin basket. We understand that an efficient washing machine is key to a comfortable home, and this part plays a critical role in making that happen. So, get your washer back to its top performance and take your washing experience back to what it used to be when the appliance was new. But safety first?make sure you unplug your washer and turn off the water supply before starting the installation process. It's also a good idea to wear work gloves to keep your hands safe during replacement. When you choose an original manufacturer's part, like this one, you?re sure to get a part that fits just right and works perfectly with your LG washer model. This is your best bet for getting your washing machine working at its best again. So why wait? Let's get your washer running like new!
How Buying OEM Parts Can Save You Time and Money
Why buy the real thing?
OEM stands for Original Equipment Manufacturer. Simply put, this means that the company who made your appliance is also supplying the replacement part for it.
Average Repair Rating: 4.3 / 5.0, 1 reviews.
What's this?
Sort by:
< Prev
1
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Replacing Oven Control Panel
Disconnected electricity and using a Phillip Screwdriver I removed the panel in the back of electric range. I took a photo, pulled the wires off control panel, unscrewed 2 screws to loosen control panel. Replaced with new one, reconnected wires. I reconnected electricity to make sure it was working, then unplug it again after confirming a
... Read morend replaced metal panel behind range. Plug it back, set clock and ready to use. Very easy to do it yourself.
Read less
Miguel from Okatie, SC
Difficulty Level:
Very Easy
Total Repair Time:
30 - 60 mins
Tools:
Screw drivers
2 of 2 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
< Prev
1
Next >
Questions and Answers
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
6 questions answered by our experts.
Sort by:
< Prev
1
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Robert
February 1, 2023
Oven , no display lights , oven do not work, oven light do not work.
For model number wfe550sohz1
Hi Robert, thank you for reaching out. You need to check the terminal block, part number PS11750972, the safety thermostat, part number PS11740991, and the electronic control board, part number PS16555205, to fix the issue. We hope this solves your problem! If you need help placing an order, customer service is open 7 days a week. Thanks again for your great question.
The oven kicks off shortly after preheat begins. Never gets hot
For model number WFE550S0HZ1
Hello Dwight, Thank you for writing. We suggest testing the Oven Sensor. Testing the temperature sensor probe on your oven is easy. With the sensor at room temperature, measure the resistance between the two prongs at the end of the sensor connector. The resistance of the sensor should read approximately 1080 – 1090 ohms at room temperature. If the Sensor is good, you may have a faulty Oven Control Board. We hope this helps!
Oven seemed to overheat frozen dinner by melting plastic & burning tray before cooking food. Error code F6E1 appeared. After shutting off I found no loose or burnt wires in panel. Put in test mode everything seemed to work. Is control board on the way out ?
For model number WFE550S0HV0
Hi George, thank you for the question. Based on our research, the F6 E1 error code indicates that there may be a problem with the appliance manager, or the associated wiring. We would suggest checking the wire harness first. If it is fine, the issue could be with the oven control board, part number PS16555205. You may need to replace it to fix the issue. We hope that helps!
Did this question help you?
Thank you for voting!
Eric
April 3, 2024
My oven when I'm baking something it will switch from bake to broil and then the temperature goes super high until I turn off and unplug it. This happens randomly. It started about 6 months after purchase and I have had the stove for almost 2 years now.
For model number WFE550S0HZ1
Hello Eric, thank you for your inquiry. Based on the description that you have provided, we would recommend checking the control board, part number PS16555205, to fix the issue. We hope this sorts out your problem!
Did this question help you?
Thank you for voting!
Kenneth
April 6, 2024
Oven will not work a Err F1 & E0 comes up I tried turning the breaker off for minutes and it still says the same issue
For model number WFE550S0HZ2
Hello Kenneth, thank you for contacting us. Based on our research, the error code F1 E0 indicates that there may be a problem with the oven control, or the associated wiring. We would recommend replacing the control board, part number PS16555205, to fix the issue. We hope this helps!
Did this question help you?
Thank you for voting!
Rick
April 19, 2025
My stove has an error code f1-E0 What do you think is wrong with it? And what part do I need to fix this problem. Thanks Rick
For model number WFE550S0HZ1
Hello Rick, thank you for getting in touch. Based on our research, the error code you mentioned indicates a problem with the oven control, or the associated wiring. We would recommend making sure that the wire harness regarding the control board is intact. If the problem persists, then you may need to check the control board, part number PS16555205, to fix the issue. We hope this helps!
Did this question help you?
Thank you for voting!
< Prev
1
Next >
Model Cross Reference
This part works with the following models:
PartSelect Number: PS16555205
Manufacturer Part Number: W11528249
Item is in stock and is estimated to be delivered in 2-3 business days via Standard Shipping.
On Order
Item is not in stock and usually ships 3-5 business days from the time you place your order.
Special Order
Item is not in stock and usually ships 10-15 business days from the time you place your order.
NLA - No Longer Available
This item is no longer being made by the manufacturer, and cannot be added to your shopping cart.
