Sample Model Number Tags
Model numbers can be made up of numbers (1005400, for example) or a combination of letters and numbers (LAT1000AAE). The model number will most likely appear on either a paper sticker or a metal plate. Your appliance's model number tag may look similar to the sample model number tags shown here (model number highlighted in yellow):
Model has been saved to My Models. If you're not signed in, your lists are available on this device and will expire within 30 days.
Model has been saved to My Models.
This part is a retaining ring, sometimes called a retaining clip, that holds the drum support roller onto the shaft of a dryer. It is made entirely of metal and measures less than an inch in diameter....
This gear is used to power your stand mixer. It is attached to the planetary shaft. The gear can become stripped over time or accumulate grease. You may need to replace other mechanical parts at the s...
Includes both the attachment and beveled gear. This worm follower gear is for stand mixers.
Worm follower gear meshes with the worm gear, causing the rotation of the planetary assembly where the ac...
This durable metal worm gear is designed to rotate the planetary assembly in select stand mixers, enabling smooth and consistent operation of attached accessories. As a key internal component, it help...
This wire whip attaches to your stand mixer and is used for whipping food products. It is made of metal wire and is one of several attachments that you can add to your mixer. If you attempt to start y...
This speed control switch assembly is a precision electronic component designed to regulate motor speed in stand mixers. It includes a black control knob and is engineered to deliver consistent perfor...
Ask our experts a question about this model and we'll get back to you as soon as possible!
4 questions answered by our experts.
Sort by:
< Prev
1
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Sue
March 26, 2020
Hi my kitchen aid will not turn when i turn it on makes a grinding noise i was told it was the gear if this is so is there only one gear and which is the correct one to buy for this model kitchen aid hd thank you
For model number 4KG25H3XSL5
Hello, Thank you for your question. You will want to check the Hub Gear- Part #: PS12348886, Worm Gear- Part #: PS12070620, and Worm Gear- Part #: PS11747012. We hope this helps.
1 person found this helpful.
Was this helpful?
Thank you for voting!
Doug
January 17, 2024
Do you put grease in the final drive- bellow the main gear assembly?
For model number 4KG25H3XSL5
Hello Doug, thank you for getting in touch. We suggest opening the case to check the grease. If most of the grease was lost, it will be a good idea to have the grease replaced. We have attached a relevant video that will help you in replacing the grease. The video may not be of the same exact model but will help you with the process. We hope this information helps!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Peter
January 9, 2025
the bowl does not pass the dime test as far as blade clearance from the bottom of the bowl. Its at about a nickels worth .
I understand the screw in the neck is to be used to adjust the clearance. It only turns a tiny bit making no difference.
What do you suggest?
For model number 4KG25H3XSL5
Hello Peter, Thank you for your inquiry. According to the beater to bowl clearance on page 22 of the owners manual (we have provided a link to the copy on our site) adjustments should be made
only with the flat beater in place. Gently turn screw (A) slightly counterclockwise to raise the bowl (reduced beater clearance), or clockwise to lower the bowl (increased beater clearance). A slight turn is all that is required; the full range of adjustment is achieved in just 1/2 turn of the screw. Do not rotate the screw more than 1/2 turn in either direction. If it does not adjust the clearance properly, then the issue may be with the cam, the bowl arm lift, the lift rod and the spring. Check for any loose or worn parts. Good luck with your repair.
Mixer is dropping small black bits into the bowl, not sure what they are, it has been suggested that a new seal on the gear housing should fix the problem. Given its age (15 years) would it be advisable to replace other parts while I have it apart.
For model number 4KG25H3XSL5
Hi Doug, thank you for reaching out. The substance you are seeing is grease. This happens when the grease gets older and loses viscosity. We would recommend putting some grease on the on the planetary gears to fix the issue. We hope this solves your problem!
Was this helpful?
Thank you for voting!
< Prev
1
Next >
✖
Ask a Question
Ask our experts a question on this model and we'll respond as soon as we can.
removed metal strap around motor housing then remove the 4 screws holding top motor cover on, then removed the 4 screws that hold gear cover in place, remove long gear that is driven by the motor gear, then with ring pliers remove ring off long drive shaft and lift off worm gears. once all gears are removed --removed all the old grease (
... Read moredo this to get all the metal shavings out from the failed gear) repace the grease in the gear housing and reassemble in reverse order
1, Removed trim piece (1 screw) 2, removed cover (4 screws) 3, removed speed switch assembly (2 screws) 4, removed gear cover (4 screws) 5, removed and examined 2 worm gears for wear. Gear cover was badly cracked, don"t know if it was caused by a previous repair or by heat, as old cover is plastic. Received new parts and installed them
... Read more, 2 bearings, 2 worm gears, 1 new cover of diecast metal and a new gasket. All repairs made with a #2 phillips screw driver. My wife then made bread, and it preformed flawlessly.
Removed four screws to remove main cover. Removed four more screws to remove fractured plastic gear housing cover. Removed retainer ring and slid two gears and dowel off main shaft. Lifted out remaining gear train and bearings, Removed all grease and metal chips from all components. Greased new gears and reassembled. Replaced plasti
... Read morec gear housing cover with oreviously purchased die cast replacement part. Assembled main cover.
