See part 31 in the diagram
Replacing your Maytag Dishwasher Spray Arm Snap Retainer play video
( Grid squares measure 1x1 inch )

Get in touch, we're here to help!

Open until 12am EST

customerservice@partselect.com

Spray Arm Snap Retainer

★★★★★
★★★★★
11 Reviews
$7.97   In Stock

Get this part fast. Average delivery time via standard shipping: 1.8 days.

PartSelect Number PS11748489
Manufacturer Part Number WPW10116811
Manufactured by Whirlpool
Product Description

Spray Arm Snap Retainer Specifications

Used with your upper spray arm.
How Buying OEM Parts Can Save You Time and Money play video

How Buying OEM Parts Can Save You Time and Money

Troubleshooting
This part fixes the following symptoms:
Not cleaning dishes properly
This part works with the following products:
Dishwasher.
This part works with the following products:
Maytag, Jenn-Air, Amana, Admiral.
Part# WPW10116811 replaces these:
AP6015216, 912681, W10116811, Y912681
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

Part Videos

Replacing your Maytag Dishwasher Spray Arm Snap Retainer

Replacing your Maytag Dishwasher Spray Arm Snap Retainer play video
Customer Repair Stories
 Average Repair Rating: 4.7 / 5.0, 19 reviews. What's this?
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
Spray holes clogged by hard water deposits
I took off old upper spray arm by gently prying it and the retainer off the upper section of the dishwasher. When I first did this, two prongs of the original retainer clip broke off so I had to order a new retainer clip. The new arm fit perfectly in place and was easily held in place by the new retainer clip. This is a very simple and easy repair. The only tool I used was a flat headed screwdriver to pry off the old arm, but one could probably pry it off manually also.
  • Timothy from Salt Lake City, UT
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Screw drivers
  • Parts Used:
    WPW10116811, WP903079
41 of 49 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Upper washer arm holes plugged up
The upper washer arm can be removed by just snapping it out of place. Just take a screw driver and put in underneath the spray arm and pry it out of its socket. It will just snap out its place. Sometimes this retainer will break so make sure you have this retainer before trying to remove the upper spary arm. I removed the spray arm and back flushed it out with a garden hose to get the debri out of the washer arm. The holes are all clean now. Washes much better now. To put in back on just put the washer arm back where it goes and then just snap the clip back in its hole. Pretty easy fix.
  • STEVE from RAYTOWN, MO
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
  • Parts Used:
    WPW10116811
15 of 18 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Spray arms were split in the seams & clogged
After I figured out how to remove the spray arms, and filter guard (that was the hardest part) it was a piece of cake. Just a matter of snapping the spray arm into the filter guard, and replacing it the dishwasher, and tightening it with the screw in retainer. Upper arm was also easy to replace after removing the top rack.
12 of 29 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Grinding noise/dishes not washing properly. Soap not dissolving.
Other parts used:
Discharge Housing Assembly (#11)
Impeller Assembly (Wash Impeller) (#14)
O-Ring (#37)
Upper Discharge Housing Gasket (#38)

Removed upper and lower washing baskets.

Pulled off Upper Spray Arm (#33). It pulls off easily by hand. No tools required. Replaced with new Upper Spray Arm (#33) and Snap Spray Retainer (#31).

Removed Large Spray Arm Cap(#34,)which has a right hand thread. This allowed me to take the Lower Spray Arm(#2)off.
Removed Filter Guard (#36).

Next I removed the 6 screws from the Pump Cover & Secondary Filter Assembly (#4) with a Torx screwdriver. Removed Lower Spray Arm Seal(#3), Pump House Filter (#6)(which I cleaned), Assembly, Rinse Arm (#7) Jump Up Nozzle (#1). Unscrewed Discharge Housing Nut(#8) by hand. Removed Support, Wash Arm (#9). This allowed me to remove the three screws holding the Discharge Housing Assembly(#11)with a 5/16th nut driver. Next I removed the Impeller Screw (#12) with a 5/16th nut driver. You must hold the Impeller Assembly (#14) firmly while loosening the nut. Removed Impeller Assembly (#12) and Plate, Suction (#15). Cleaned out area of debris,lint, etc. Put back old Plate, Suction (#15) and replaced Impeller Assembly (#14) with new part. Replaced Upper Housing Gasket and Discharge Housing Assembly with new parts. Put back all parts in the reverse order I removed them replacing the O-Ring (#37) with a new part. This O-Ring goes in the Pump Cover & Secondary Filter Assembly (#4).

After completely assembled it ran as good as new!
  • Eric from Gualala, CA
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver, Screw drivers
7 of 9 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Upper Spray Arm replacement
popped out the spray arm snap retainer that held in the upper spray arm and pushed the new snap retainer into the new upper spray arm to complete the job. I thought I must have done something wrong because it only took about a minute.
  • NICKIE from Weaverville, NC
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Screw drivers
  • Parts Used:
    WP903079, WPW10116811
5 of 7 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Dishwasher not cleaning dishes
Lower Dishrack assembly just rolled into the dishwasher-easy, easy, easy!
The Upper Spray Arm assembly- broke off tab to old arm using a screwdriver to pry off the tab. Pushed the new arm assembly and tab into place. The only problem was not to bend the prongs on the plastic tab (they bend back easily if you do happen to bend them, though)
My dishwasher cleans like new!!
  • Nancy from Midlothian, IL
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
4 of 8 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Upper dishwasher arm fell off
I undid the four clips that attach the upper dish rack to the dishwasher. The upper arm simply unscrews from the top of the dishwasher. Unsnap clip that holds arm and remove arm. Installation is the reverse of removal.
  • Gregory from Eureka, UT
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Parts Used:
    WPW10116811
3 of 3 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
snap spray retainer had broken; sprayer arm had fallen off
Inserted snap spray retainer through center of sprayer arm, snapped whole thing into place, and I was done!
  • Claudia from Highlands Ranch, CO
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Parts Used:
    WPW10116811
3 of 5 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Old spray arm was plugged up with build up.
Pull straight down to remove upper arm. Hold new arm in place and push the locking retainer into the center hole in the arm and locking it into the holder. Very simple.
  • Jim from Corpus Christi, TX
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Parts Used:
    WP903079, WPW10116811
3 of 7 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Old retainer was broken and spray difuser fell out.
Retainer easily holds spray difuser in place. I simply pressed the retainer into place and it fixed the probem.
  • Glenn from Scottsbluff, NE
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Parts Used:
    WPW10116811
2 of 4 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer Reviews
Average Rating:
★★★★★
★★★★★
11 Reviews
5.0
Filter By Rating:
  • 5 Stars
    11
  • 4 Stars
    0
  • 3 Stars
    0
  • 2 Stars
    0
  • 1 Star
    0
Sort by:
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
Model Cross Reference
This part works with the following models:
PartSelect Number: PS11748489
Manufacturer Part Number: WPW10116811
Brand
Model Number
Description
Amana
ADW662EAB
Dishwasher
Amana
ADW662EAB-PADW662EAB0
Dishwasher - Amana Dishwasher Model ADW662EAB-PADW662EAB0 (ADW662EABPADW662EAB0, ADW662EAB PADW662EAB0) Parts
Amana
ADW662EAC
Dishwasher
Amana
ADW662EAC-PADW662EAC0
Dishwasher - Amana Dishwasher Model ADW662EAC-PADW662EAC0 (ADW662EACPADW662EAC0, ADW662EAC PADW662EAC0) Parts
Amana
ADW662EAS
Dishwasher
Amana
ADW662EAW
Dishwasher
Amana
ADW662EAW-PADW662EAW0
Dishwasher - Amana Dishwasher Model ADW662EAW-PADW662EAW0 (ADW662EAWPADW662EAW0, ADW662EAW PADW662EAW0) Parts
Amana
ADW862EAB
Dishwasher
Amana
ADW862EAC
Dishwasher
Amana
ADW862EAS
Dishwasher
Amana
ADW862EAW
Dishwasher
Amana
DDW2470AWP
Dishwasher - Undercounter
Amana
DDW361RAB
Dishwasher
Amana
DDW361RAB-PDDW361RAB0
Dishwasher - Amana Dishwasher Model DDW361RAB-PDDW361RAB0 (DDW361RABPDDW361RAB0, DDW361RAB PDDW361RAB0) Parts
Amana
DDW361RAC
Dishwasher
Amana
DDW361RAC-PDDW361RAC0
Dishwasher - Amana Dishwasher Model DDW361RAC-PDDW361RAC0 (DDW361RACPDDW361RAC0, DDW361RAC PDDW361RAC0) Parts
Amana
DDW361RAW
Dishwasher
Amana
DDW361RAW-PDDW361RAW0
Dishwasher - Amana Dishwasher Model DDW361RAW-PDDW361RAW0 (DDW361RAWPDDW361RAW0, DDW361RAW PDDW361RAW0) Parts
Jenn-Air
DW1000B
Dishwasher
Jenn-Air
DW1000W
Dishwasher
Admiral
DWB1000AWE
Dishwasher
Admiral
DWB1000AWX
Dishwasher
Maytag
DWC4910AAW
Dishwasher
Maytag
DWC6402AAE
Dishwasher
Maytag
DWC6402ABE
Dishwasher
Maytag
DWC7302AAB
Dishwasher
Maytag
DWC7302ABB
Dishwasher
Maytag
DWC7400AAW
Dishwasher
Maytag
DWC7400ABW
Dishwasher
Maytag
DWC7602AAB
Dishwasher
