Model numbers can be made up of numbers (1005400, for example) or a combination of letters and numbers (LAT1000AAE). The model number will most likely appear on either a paper sticker or a metal plate. Your appliance's model number tag may look similar to the sample model number tags shown here (model number highlighted in yellow):
The timer controls most of the operations of the washer: water level, tub filling and emptying, length of cycles, and cycle setting sequences.
How Buying OEM Parts Can Save You Time and Money
Why buy the real thing?
OEM stands for Original Equipment Manufacturer. Simply put, this means that the company who made your appliance is also supplying the replacement part for it.
Average Repair Rating: 3.3 / 5.0, 1 reviews.
What's this?
Sort by:
< Prev
1
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Washer control unit went out
Removed two front covers, the one with the dials and one between the washer drier which is at an angle. It was mostly plug and play. The tough part was not knowing the large dials do not pull off like the small dials. You need to pop off the end caps to expose the nuts that bolt the dials to their control boxes. Then remove the right
... Read morescrew on the the top front panel and slide the plastic edge to the right and the metal panel will come off exposing the left retaining screw.
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
4 questions answered by our experts.
Sort by:
< Prev
1
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Gary
April 3, 2019
Water does not come into the tub when I pull the knob on the washer. I have checked the water inlet valve and it is ok and there is plenty of water available. What are the chances that this part is faulty or could it be something else? When i turn the knob to spin and pull it out the washer will spin.
For model number LSE7806ADE
Hello Gary, Thank you for the question. If the valve checks out good and there is good water pressure to the valve, the timer is the next most likely part to replace. You can also check the Water Level Switch Kit, PartSelect Number PS2003728. Hope this helps!
4 people found this helpful.
Did this question help you?
Thank you for voting!
Bryan
October 10, 2023
Tub fills with water but won’t cycle to wash mode
For model number LSG7806ABE
Hello Bryan, thank you for the question. Based on our understanding of the issue, we would suggest checking the washer timer, part number PS11739312, to fix the issue. The timer controls most of the operations of the washer: water level, tub filling and emptying, length of cycles and cycle setting sequences. We hope this solves your problem!
1 person found this helpful.
Did this question help you?
Thank you for voting!
Andy
December 29, 2024
Washer worked fine and then the next load wouldn't even start. No water, no motor sounds, nothing. If I advance the switch manually to spin it will spin for a normal period and then shut down, but won't work in any other part of the cycle. I'm thinking the timer, but is there any test to prove it, apart from replacing it? Thanks in advance!
For model number LSE7806ADE
Hello Andy, thank you for the inquiry. It does sound like the timer. You can test the Timer with a multimeter. Please see the attached video. We hope this helps.
Did this question help you?
Thank you for voting!
Bryan
October 13, 2023
I tried changing the washer timer as the washer will fill , but won’t cycle to wash- that did not work ,same problem ??
For model number LSG7806ABE
Hi Bryan, thank you for getting in touch. If you have already replaced the timer and the issue persists, we would suggest checking the lid check switch, part number PS11738787, as it is most likely faulty and may need to be replaced. We hope this solves your problem!
