MAV7600AGW Maytag Washer - Overview
Sections of the MAV7600AGW
[Viewing 7 of 7]
Keep searches simple, eg. "belt" or "pump".
Suspension Spring
PartSelect #: PS11738823
Manufacturer #: WP21001598
This suspension spring is 7 inches in length, and is sold individually. It is a good idea to replace all six springs at once to maintain the same tension level. To complete this repair you will need a...
$7.30
In Stock
Drain Pump with Pulley
PartSelect #: PS11741799
Manufacturer #: WP35-6465
This drain pump with pulley, also known as the washing machine drain pump assembly, is a pump with two ports. The function of this pump is to help expel water from your washing machine. The pump is ac...
$95.23
In Stock
Snubber Ring
PartSelect #: PS11738845
Manufacturer #: WP21002026
The snubber ring is a piece that is specific to your washing machine. The function of the snubber ring is to reduce noise and vibrations within your washer. It fits in between the leg and the dome ass...
$10.45
In Stock
Transmission Pulley and Bearing Kit
PartSelect #: PS2003651
Manufacturer #: 12002213
This transmission pulley and bearing kit, also known as thrust bearing kit or washer pulley and bearing kit, includes the pulley, washer, thrust bearing, two upper race washers, and one lower race was...
$44.24
In Stock
Dryer Screw
PartSelect #: PS11746840
Manufacturer #: WP90767
This screw is sold individually.
$7.30
In Stock
Washer Hose Clamp
PartSelect #: PS11743008
Manufacturer #: WP596669
This hose clamp is used in a wide variety of household appliances. Most often it is found in washers, dishwashers, refrigerators, freezers, dehumidifiers, garbage disposals, or air conditioners. This ...
$7.30
In Stock
Timer Knob Insert Cap
PartSelect #: PS11739300
Manufacturer #: WP22001664
This timer knob insert cap is just over two inches in diameter. It is all white in color and is made of plastic.
$9.40
In Stock
Motor with Pulley
PartSelect #: PS11738839
Manufacturer #: WP21001950
This motor is a 2 speed, 1/2 HP, 120V, 60Hz.
$172.96
In Stock
Lid Switch Actuating Cam
PartSelect #: PS11723080
Manufacturer #: W10814230
This is a replacement lid switch actuating cam for your washer. The cam is located on the underside of the washer lid, near the hinge. The cam actuates the lid switch, so your washer knows the lid is ...
$9.40
In Stock
Hose Clamp
PartSelect #: PS11740613
Manufacturer #: WP285655
The hose clamp is used to hold the water hose in place which will prevent the hose from leaking water. Sometimes the clamp may lose its ability to latch on, causing a leaking washer. For the installat...
$9.40
In Stock
Washer Lid Switch
PartSelect #: PS11739463
Manufacturer #: WP22003804
The pin on the lid pushes on the lever of the lid switch to tell the machine that the lid is closed.
$56.38
Special Order
Washer Lid Hinge Pin
PartSelect #: PS11739380
Manufacturer #: WP22002751
This lid hinge pin is almost two inches long. It is all white in color and is made of plastic.
$9.40
In Stock
Questions And Answers for MAV7600AGW
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
Common Symptoms of the MAV7600AGW
[Viewing 11 of 11]Leaking
Fixed by
these parts
these parts
Show All
Will Not Start
Fixed by
these parts
these parts
Show All
Will not agitate
Fixed by
these parts
these parts
Show All
Will not drain
Fixed by
these parts
these parts
Show All
Burning smell
Fixed by
these parts
these parts
Show All
Spins slowly
Fixed by
these parts
these parts
Show All
Shaking and Moving
Fixed by
these parts
these parts
Show All
Spinning Issues
Fixed by
these parts
these parts
Show All
Lid or door won’t close
Fixed by
these parts
these parts
Show All
Draining Issues
Fixed by
these parts
these parts
Show All
Noisy
Fixed by
these parts
these parts
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
washing machine was making alot of noise
I found the water pump bearings were going bad from humidity. I replaced the pump with a new one and it runs quiet again.
Parts Used:
-
David from Boca Raton, FL
-
Difficulty Level:Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers, Wrench set
562 of 574 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Washer jumping in spin cycle (white flakes under the washer)
Unlug the AC cord,open the top from the front it snaps open with a little force and hinges on the back, remove the 2 screws on the front cover and take it off, tip the washer and remove the belt, take off the pump hose from the back (I removed the back cover also) and the little hose going to the basket. Remove the 6 springs and lift the
... Read more
complete drum out of the waser and turn it upside down. You can see the plastic snubber ring that is worn, loosen the 6 screws just enough to get the old ring out and the new one in. WARNING (DO NOT TAKE THE SCREWS ALL THE WAY OUT OR THE BRAKE ASSEMBLY WILL RELEASE AND A SPECIAL TOOL IS NEEDED TO PUT IT BACK) Install the new ring, tighten the screws and put the tub back in connecting everything back up and use the 6 new springs. It really isn't that hard to do.
Read less
Parts Used:
-
David from Butler, PA
-
Difficulty Level:A Bit Difficult
-
Total Repair Time:1- 2 hours
-
Tools:Pliers, Screw drivers, Wrench set
291 of 305 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
The belt and pulley on the drive motor broke
unplug the washer. Removed the top of the washer by removing the hold scews and tabs on the upper back. Place a scew drive under the front and pry up to release the snap tabs. Then the front panel by removing the two screws on top and lift the panel up to expose the motor at bottom front. Remove the motor cover (plastic)and motor from the
... Read more
base, replace the pulley on the shaft (you may need to break or pry the old pulley off) install the new pulley making sure it is all the way up the shaft locking the tabs into the shat groove. Reinstallmotor to the base. To replace the belt, tilted the unit backwards to access the pulleys from the bottom and installed.
Note: it ios easier to install the belt fully on the two smaller puleys attcahed to the drive motor and pump and then wrap as much as you can around the larger drum pulley. Hold the belt in one hand and turn the drum pulley clockwise with the other and the belt will follow and install. reverse steps to reassemble.
Note: it ios easier to install the belt fully on the two smaller puleys attcahed to the drive motor and pump and then wrap as much as you can around the larger drum pulley. Hold the belt in one hand and turn the drum pulley clockwise with the other and the belt will follow and install. reverse steps to reassemble.
Read less
Parts Used:
-
Michael from Warminster, PA
-
Difficulty Level:Really Easy
-
Total Repair Time:30 - 60 mins
-
Tools:Screw drivers, Wrench (Adjustable)
153 of 192 people
found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
