Range Surface Element Control Switch - 6 Inch - 1560 W Specifications
This switch controls the small burner on a range/stove top.
How Buying OEM Parts Can Save You Time and Money
Troubleshooting
This part fixes the following symptoms:
Element will not heat | Will Not Start
This part works with the following products:
Range, Cooktop.
This part works with the following products:
General Electric, Hotpoint, Kenmore.
Part# WB24T10029 replaces these:
AP2024076, 769696, WB24T10029-100PK
Questions and Answers
