This oven door gasket prevents heat from escaping the oven cavity when in use. This is a very easy repair that should only take a few minutes. The door gasket may damage or rip over time due to repeated use. If you notice that hot air is escaping from your oven, it is likely that the gasket needs to be replaced. You will need to open the oven door and remove the old seal by pulling it out of place with your hands. The old gasket will be secured with clips that will come out when you pull the entire piece out. The new gasket will have hooks all along the rim, which will line up with the oven door. Simply line up the hooks and push into place outlining the door of the inside of the oven. No tools required.
How Buying OEM Parts Can Save You Time and Money
Troubleshooting
This part fixes the following symptoms:
Door won’t close | Oven not heating evenly
This part works with the following products:
Wall Oven, Microwave Oven Combo, Range.
This part works with the following products:
Jenn-Air, Maytag, Amana, Kenmore.
Part# WP71001841 replaces these:
AP6010675, 71001841, 7212P061-60
Questions and Answers
Ask our experts a question about this part and we'll get back to you as soon as possible!
3 questions answered by our experts.
< Prev
1
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Jim
December 13, 2017
What is the length of this gasket.?
For model number part # Wp710011841
Hi Jim,
Thank you for your question. The length of this gasket is 73 inches. I hope this helps. Thank you and have a great day!
2 people found this helpful.
Was this helpful?
Thank you for voting!
Joan
February 26, 2018
Will this gasket fit the Jenn air model number above?
For model number SVE47500B
Hi Joan, Thank you for the question. Yes, the PS11743859 is the correct Door Seal for the model number provided. Hope this helps!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Woody
January 7, 2020
How do we remove the ends of the old seal to install the new one on our Maytag wall oven doors?
Hello Woody and thank you for writing.
You will need to open the oven door and remove the old seal by pulling it out of place with your hands. The old gasket will be secured with clips that will come out when you pull the entire piece out. The new gasket will have hooks all along the rim, which will line up with the oven door. Simply line up the hooks and push into place outlining the door of the inside of the oven. No tools required. We hope this helps. Please contact us anytime if you require further assistance.
1 person found this helpful.
Was this helpful?
Thank you for voting!
< Prev
1
Next >
✖
Ask a Question
Ask our experts a question on this part and we'll respond as soon as we can.
Something went wrong. Please try again later.
Your Question Has Been Submitted!
Our experts will send you an email as soon as your question has been answered.
Part Videos
Replacing your Jenn-Air Wall Oven SEAL- DOOR
Customer Repair Stories
Average Repair Rating: 5.0 / 5.0, 3 reviews.
What's this?
< Prev
1
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
oven door gasket was no longer flexible, but stiff
pulled out the old door gasket, it had little diamond-shaped clips, pulled out really easily, replaced with the new gasket. All the clips fit into the proper holes, stuffed the new ends where the old ones were. Perfect. less than 10 minutes. Thanks....
cheryl from dolores, CO
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
16 of 18 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
My daughter tipped a large dish of lasagna onto the oven door and the seal.
The door seal was an exact fit for the factory one. There are little clips that hold the seal to the door. The clips are already installed in the seal. To remove just grasp the seal at each clip and pull up. The seal comes off easily. The ends of the seal are tucked into holes at the bottom of the door so you can just pull them out. For the installation of the new seal grasp the seal at each clip and push them into the littles holes. I used a flat blade screwdriver to tuck the seal ends into the two larger holes at the door bottom. The whole process took about 10 minutes.
I wouldn't have changed the seal but the hot lasagna made the seal sort of hard after it cooled off.
Thomas from LK HAVASU CTY, AZ
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Screw drivers
3 of 3 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Faded electronic clock/worn oven seal
My husband would not relinquish the tools:(. It took him 15 min or less to change the electronic clock and maybe 2-3 min to change the seal. Niyyah, Scottsdale, AZ
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
★★★★★
★★★★★
Sandy S - January 27, 2022
Verified Purchase
EASY to replace ! perfect fit
Excellent experience. I actually purchased the wrong one and tried to cancel it, but they said it was too late. their return process was very good, but lost part of the cost to restock fee.
purchased the right one. it arrived in a timely manner, was easy to install...I couldn't be happier.
★★★★★
★★★★★
Terry D - April 14, 2021
Verified Purchase
Great part
Fit my 20 year old oven perfectly! Arrived in a timely manner. Will order from here again.
★★★★★
★★★★★
James G - December 12, 2020
Verified Purchase
Perfect Fit, Easy Replacement
This was an exact fit with all the clips in the right places and was easy to install. The only change I had to make was to cut about an inch of extra length off each end but better for it to be too long than too short.
★★★★★
★★★★★
Dennis O - December 13, 2019
Verified Purchase
easy and fast installation
fast delivery and easy installation
★★★★★
★★★★★
Charles G - November 20, 2018
Verified Purchase
Jenn-Air Door Seal
Great price, quick shipping and very easy to install, thank you.
< Prev
1
Next >
Model Cross Reference
This part works with the following models:
PartSelect Number: PS11743859
Manufacturer Part Number: WP71001841
