Sample Model Number Tags
Model numbers can be made up of numbers (1005400, for example) or a combination of letters and numbers (LAT1000AAE). The model number will most likely appear on either a paper sticker or a metal plate. Your appliance's model number tag may look similar to the sample model number tags shown here (model number highlighted in yellow):
Introducing the FAN (W10846539) for your Whirlpool appliance. This genuine ice box fan is designed for specific models of Whirlpool, enhancing performance and improving cooling efficiency. The evaporator fan blade seamlessly circulates air through the evaporator fins and interior compartment. Before installing this sturdy OEM part, unplug your refrigerator and remove any food items that might deteriorate. Wearing work gloves during installation can help protect your hands. Please ensure the part number matches your model before purchasing.
How Buying OEM Parts Can Save You Time and Money
Why buy the real thing?
OEM stands for Original Equipment Manufacturer. Simply put, this means that the company who made your appliance is also supplying the replacement part for it.
Ask our experts a question about this part and we'll get back to you as soon as possible!
5 questions answered by our experts.
Sort by:
< Prev
1
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Maja
March 11, 2023
Freezer works. Fresh food are is warm. Appliance repair man came out and said it was the fan in the freezer not working to blow air up to refrigerator. He hasn't called back for a week now, so I am thinking to replace the fan myself. I need to know for sure which part to order. Also, reading questions below, will I need to order blades separately or use the blades on the motor in the frig now. Thank you for your assistance!
For model number WRX986SIHZ00
Hello Maja, Thank you for your inquiry. Researching the model number that you have provided, this model actually has an evaporator fan in both the refrigerator and freezer. The refrigerator fan (which cools the refrigerator evaporator) is PS11731053 and there is a second fan motor as well, part# PS12070640. Both of these contain the blades. There is also a damper control assembly, which controls the air flow in the refrigerator. You can test these parts with a multimeter to see which one is faulty. If you are unfamiliar with how a multimeter functions, we have videos available to assist you. Good luck with your repair.
Is the fresh food fan part replacement w108 46539 compatible with my refrigerator model number above?
For model number WRF990SLAM02
Hello Jeanie, Thank you for contacting us. I have researched the model you have provided and have found the part you are looking for is PartSelect Number PS11731053. Hope this helps!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Jeanie
July 1, 2019
What part number do i need to replace the gentle typhoon servo w10395278b?
For model number WRF990SLAM02
Hi Jeanie, thank you for your question. If you are looking to replace your evaporator fan motor or fan blade, I have listed those two parts below for you. Good luck with your repair.
The frig doesn't get cold. Freezer is cold. Local repairman says we need fan assembly. Is your number ps11731053 the complete fan assembly? And do you think that is what we need?
For model number WRF767SDHZ00
Hello Chauncy, Thank you for contacting us. We have researched the model you have provided and have found the part you are looking for is Part #: PS12349521 for the Evaporator Fan in the Freezer that circulates the Cold Air. This is just the Motor. The blades are Part #: PS11743683. If you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!
Does this refrigerator have 2 fan motors on the inside? I know it had a condenser fan motor.
For model number WRF767SDEM01
Hello Robert, Thank you for the question. There is also a Evaporator Fan Motor in the Freezer, PartSelect Number PS11770336. If you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!
