10060305-1-M-Frigidaire-5304496284-Defrost Heater
Part Location Diagram of 5304496284 Frigidaire Defrost Heater
See part F14 in the diagram
( Grid squares measure 1x1 inch )
10060305-1-S-Frigidaire-5304496284-Defrost Heater Part Location Diagram of 5304496284 Frigidaire Defrost Heater
Customer Service Representative

Get in touch, we're here to help!

Open until 12am EST

customerservice@partselect.com

Defrost Heater

Rated by 1 customer

Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

$ 80.21
  In Stock

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

PartSelect Number PS10060305
Manufacturer Part Number 5304496284
Manufactured by Frigidaire
Customer Service Representative

Get in touch, we're here to help!

Open until 12am EST

customerservice@partselect.com

Check if this fits your product and find model diagrams

Need help finding your model number?
Troubleshooting
This part fixes the following symptoms:
Frost buildup
This part works with the following products:
Freezer.
This part works with the following products:
Frigidaire, Kenmore, Crosley, Westinghouse.
Part# 5304496284 replaces these:
AP5952328, 297348700, A00958703
Back to Top
Questions and Answers

Ask our experts a question about this part and we'll get back to you as soon as possible!

2 questions answered by our experts.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Simon
August 27, 2021
Ice buildup on the coils
For model number Fffh20f2qwc
PartSelect logo
Hello Simon, thank you for writing. We have researched the model you have provided and have found the part you are looking for is Number PS12585793. We hope this helps.

1 person found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
DEFROST TIMER
$40.43

  In Stock
Grace
May 24, 2022
upright frost free freezer is icing up in the inside and once the water was on the floor? What do you think is the cause? I currently have an extended warranty on the product but the company does not want to repair the freezer as they have deemed the product non repairable and the cause is Lack of insulation or a crooked frame. Have you ever heard this before? I want to keep my freezer and want to see how much it would cost for me to fix it (no freezers available, not same dimensions, only bigger size and more money).
For model number FFFH17F4QW0
PartSelect logo
Hello Grace, Thank you for your inquiry. We have researched the model number that you have provided and it could be the defrost heater, the defrost timer, the evaporator fan or the temperature control thermostat. You can test the parts with a multimeter. If you are unfamiliar with how a multimeter functions, we have videos available to assist you. Check the door gasket as well to make sure it is sealing properly. We hope this helps and if you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
Door Gasket - White
$199.65

  In Stock
FAN MOTOR EVAP 115V
$91.09

  In Stock
DEFROST TIMER
$40.43

  In Stock
Temperature Control Thermostat
$62.64

  In Stock
  • 1
Back to Top
Customer Repair Stories
 Average Repair Rating: 3.9 / 5.0, 1 reviews. What's this?
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Defroster and thermostat
Unplug freezer.
Open freezer and Remove the bottom 2 shelves and drawers.
Remove 6 screws (Phillips) securing the inside access panel located in the back of the unit.
Locate the defroster bar which is secured to the bottom of the condenser radiator. Trace the cable to the thermostat that is clipped into the condenser coil.
Unplug thermostat power cable located at the top left of the condenser coil, and the defroster bar cable on the upper right.
Release metal band that secures bar to the coil at the bottom where the coil and bar are secured.
Reverse for installation.
  • Mel from LAKE CHARLES, LA
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
1 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
Back to Top
You May Also Need?
DEFROST TIMER
$40.43
$40.43
  In Stock
Back to Top
Model Cross Reference
This part works with the following models:
PartSelect Number: PS10060305
Manufacturer Part Number: 5304496284
Brand
Model Number
Description
Kenmore
25322040510
Freezer - UPRIGHT FREEZER
Kenmore
25322042410
Freezer - FREEZER
Kenmore
25322042411
Freezer - Upright Freezer
Kenmore
25322042412
Freezer - Upright Freezer
Kenmore
25322742410
Freezer - FREEZER
Kenmore
25322742411
Freezer - Upright Freezer
Kenmore
25322742412
Freezer - Upright Freezer
Kenmore
25327002410
Freezer - FREEZER
Kenmore
25327002411
Freezer - FREEZER
Kenmore
25327003410
Freezer - UPRIGHT FREEZER
Kenmore
25327003411
Freezer - FREEZER
Kenmore
25327009410
Freezer - FREEZER
Kenmore
25327009411
Freezer - FREEZER
Kenmore
25327702411
Freezer - FREEZER
Kenmore
253280528010
Freezer - FREEZER
Kenmore
253280528011
Freezer - FREEZER
Kenmore
253280528012
Freezer - FREEZER
Kenmore
253280528013
Freezer - FREEZER
Kenmore
253280528014
Freezer - FREEZER
Kenmore
253280528015
Freezer - FREEZER
Kenmore
253280528016
Freezer - FREEZER
Kenmore
25328052808
Freezer
Kenmore
25328052809
Freezer - FREEZER
Kenmore
25328092805
Freezer
Kenmore
25328099805
Freezer
Kenmore
25328712808
Freezer
Kenmore
25328732C0
Freezer - FREEZER
Kenmore
25328732C1
Freezer - FREEZER
Kenmore
25328732C2
Freezer - UPRIGHT FREEZER
Kenmore
25328782804
Freezer
