Nancy
November 25, 2019
I have a grey oblong rubber piece that fell off the back of the center spray arm. It looks like it helps seal the water spray coming into the arm. It landed on the coils and burned up. I am trying to locate what part that is. It is about 2-3" long and fits onto the supply tube in the back of the top rack.
For model number FGHD2433KF1
Hello Nancy, Thank you for the question. Checking the model it shows the part needed is only sold as part of the Water Supply Tube for the Spray Arm. The Tube is only sold as part of the Upper Rack PartSelect Number PS10065024. Hope this helps!
Is it possible that this part could have traveled down to the bottom of dishwasher I found it twisted up in the drain pump. Or is there another seal this size that belongs in that part of dishwasher?
For model number FFCD2418US1A
Hi Rachel,
Thank you for your question. If the nozzle came loose then it is possible that this seal could have ended up on the bottom of the dishwasher. If you would like to place an order for it, customer service is open 7 days a week and anyone will be happy to assist you. Please feel free to give us a call. We look forward to hearing from you!
Was this helpful?
Thank you for voting!
< Prev
1
Next >
✖
Ask a Question
Ask our experts a question on this part and we'll respond as soon as we can.
Something went wrong. Please try again later.
Your Question Has Been Submitted!
Our experts will send you an email as soon as your question has been answered.
Part Videos
Replacing your Frigidaire Dishwasher Delivery Tube Gasket
Customer Repair Stories
Average Repair Rating: 4.4 / 5.0, 6 reviews.
What's this?
< Prev
1
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Upper spray arm had been "blowing off" during wash cycle.
Unscrewed retaining ring, replaced unit = piece of cake
I unscrewed and removed the old Arm-Control fixture. I had a little (very little) trouble figuring out how to fit the gasket. It didn't go on like i thought it should. There was no gasket on the original fixture. So I put it on the way I thought it should go. I then screwed the new Arm-Control fixture on to the outlet. That was it. No tools required.
Removed the bottom covering on dishwasher and then ran it to figure out where the leak was coming from. Noticed it was dripping off hose, but not actually leaking from hose.
Unplugged dishwasher and slid it out from cabinet area (be sure to turn off and disconnect water supply)
Followed delivery tube up side of dishwasher to top of tub and noticed reminents of where water ran down side of tub.
Loosened delivery tube by plastic nut inside of tube and removed. Noticed gasket was partially depleted.
Ordered new gasket, replaced and put everything back together. (Be sure to use teflon tape on water source fitting and tighten firmly). No leaks
Eric from Benton, KY
Difficulty Level:
Easy
Total Repair Time:
30 - 60 mins
Tools:
Pliers, Wrench (Adjustable)
9 of 11 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Stripped nozzle and leaky gasket
First I pulled out the dishwasher (this was the hardest part). Then I unscrewed the old nozzle. Next I replaced the old gasket and screwed in the new nozzle.
We moved into a new house to find the dishwasher was leaking due to missing parts
We looked at the diagrams for our Model number on Parts Select to find what was missing. We ordered the parts they arrived in two days. It took me 5 minutes to install the new parts. I left the dishwasher out from its locatation so that I could run a cycle and watch for leaks as it ran. After a full cycle, there were no leaks and I put the dishwasher back. Piece of Cake (or a lot of luck)!
