Maytag/Maytag_Thumb/57859.gif
See part 14 in the diagram
Replacing your Maytag Refrigerator Facade Insert - Black play video
( Grid squares measure 1x1 inch )

Get in touch, we're here to help!

Open until 10PM EST

customerservice@partselect.com

Facade Insert - Black

★★★★★
★★★★★
11 Reviews
$33.26   In Stock

Get this part fast. Average delivery time via standard shipping: 1.8 days.

PartSelect Number PS11743579
Manufacturer Part Number WP67004151
Manufactured by Whirlpool
Product Description

Facade Insert - Black Specifications

This is the replacement façade insert for your refrigerator. It is essentially the control panel that allows you to choose between water and ice, select different types of ice, turn on the light, and lock the control panel. If your refrigerator will not dispense ice, or if you are not able to select from the above options, you may need to replace the insert. This insert is black in color and is oval shaped. Be sure to check that this insert matches the damaged insert on your refrigerator. This part is sold individually.
How Buying OEM Parts Can Save You Time and Money play video

How Buying OEM Parts Can Save You Time and Money

Troubleshooting
This part fixes the following symptoms:
Not dispensing water
This part works with the following products:
Refrigerator.
This part works with the following products:
Maytag, Amana.
Part# WP67004151 replaces these:
AP6010400, 67004121, 67004151, 67004152, 67004901, WP67004121, WP67004152
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

5 questions answered by our experts.
    Sort by:
    Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
    NANCY ELAINE
    January 3, 2018
    No water no ice no light on the part
    For model number MSD2651KES
    Hi Nancy, Thank you for your question. Based on what you described, you will need to check the dispenser electronic control board, the touchpad and the wiring between them to see what is going on. You will need to use a multimeter to test the continuity of each part. I hope this helps. Thank you and have a great day!

    3 people found this helpful.

    Was this helpful?
    Thank you for voting!
    Jackson
    September 16, 2019
    Does this fountain push button overlay come in white for my Maytag refrigerator msd264rhew? All i see is black on your website.
    For model number Maytag part 67004121
    Hello Jackson, thank you for your question. This part for your model is only available in black. You may want to reach out to Maytag directly for an alternate and compatible part number and get back in touch with us. We look forward to hearing back from you!

    3 people found this helpful.

    Was this helpful?
    Thank you for voting!
    Khatoon
    May 22, 2019
    My question is is it easy to replace on your own or do you need a technician
    For model number Msd2651hes
    Hi Khatoon, thank you for your question. We have a customer, Tom from Kansas who wrote in with a very good example of instructions on how this part is installed: "The repair was very simple. Turn off power to unit. Remove the spill plate, it just pulls out. Then remove the two screws that are seen when the spill plate is pulled out. The cover slides down and comes out. Disconnect the two wires to the operator switch, they just pull off. Take two small screw drivers and gently raise the tabs that latch in the circuit board jack and pull the jack down to remove it. Remove the one screw that secures the circuit board and use a small screw driver to gently raise the tabs that hold the circuit board in place on the bottom side and remove the circuit board. Install the circuit board on the new cover and intall the holding screw. Plug in the jack that connects the circuit board to the unit. The plug in the two wires to the microswitch. Install the cover and install the two holding screws. Slide in the spill plate. Finally install the face plate, it just sticks on and is very easy because the cover is resessed where it is to be installed. In all I think it took me longer to wright this than it did to do the repair. ". I hope that helps. Good luck with your repair.

    2 people found this helpful.

    Was this helpful?
    Thank you for voting!
    Greg
    March 4, 2020
    I installed my new ice maker by following your video, but it’s been a day and a half and still no ice cubes have been made. I checked the electrical connection and it was fine. I’m at a loss and could use some help.
    For model number MSD2651HEW
    Hello Greg, thank you for your question. We would recommend testing the icemaker. It is possible the part is defective. It is also imperative that you check the valve to be sure it is opening to allow water to the icemaker. Here is a link for testing the valve. https://www.partselect.com/Refrigerator+test-water-valve+repair.htm And testing instructions for the icemaker. Behind the cover is a series of electrical test points that can be used to diagnose the ice maker. The unit can be manually operated by inserting an insulated jumper wire into test points “T” and “H” to initiate a “test harvest”. The jumper should be insulated 14 gauge solid wire that has the insulation stripped back about 3/4 of an inch on both ends, and bent into a “U” shape. When inserted into the test points for 5 to 10 seconds, the motor should start and the cycle will continue on its own. You may have to manually close the freezer door switch for this to operate. This test will simulate a real harvest cycle and will operate the ejector blades, shut off arm and the fill valve in the proper sequence, and will allow you to do a proper diagnosis. This is a live voltage test and should only be performed by a qualified person. If the motor does not start, you can verify that you have power to the ice maker at test points “L” and “N”. If the ice maker is getting power and does not perform a cycle, then the icemaker would have to be replaced.

    1 person found this helpful.

    Was this helpful?
    Thank you for voting!
    Jake
    October 15, 2019
    The thin control cover has cracked through in the area you push for water dispensing. So now we can't switch from water dispensing to ice dispensing. What would need to be fixed?
    For model number MSD2351HES
    Hello Jake, thank you for your question. If just the outside button is cracked enough to prevent you from pressing the button, then you will just need to replace this Facade Insert, part number PS11743579 for your model refrigerator. If the electronic part underneath the Facade Insert is also damaged, then you will need to replace it as well. It is the Dispenser Electronic Control Board, part number PS11743557. Good luck with your repair!

    Was this helpful?
    Thank you for voting!
      Part Videos

      Replacing your Maytag Refrigerator Facade Insert - Black

      Replacing your Maytag Refrigerator Facade Insert - Black play video
      Customer Repair Stories
       Average Repair Rating: 4.6 / 5.0, 9 reviews. What's this?
        Sort by:
        Sorry, we couldn't find any existing installation instruction that matched.
        the touch pad cover was cracked
        I ordered the cover and the face plate because I was unsure of the condition of the cover and because the face plate is stuck on the cover. The repair was very simple. Turn off power to unit. Remove the spill plate, it just pulls out. Then remove the two screws that are seen when the spill plate is pulled out. The cover slides down and comes out. Disconnect the two wires to the operator switch, they just pull off. Take two small screw drivers and gently raise the tabs that latch in the circuit board jack and pull the jack down to remove it. Remove the one screw that secures the circuit board and use a small screw driver to gently raise the tabs that hold the circuit board in place on the bottom side and remove the circuit board. Install the circuit board on the new cover and intall the holding screw. Plug in the jack that connects the circuit board to the unit. The plug in the two wires to the microswitch. Install the cover and install the two holding screws. Slide in the spill plate. Finally install the face plate, it just sticks on and is very easy because the cover is resessed where it is to be installed. In all I think it took me longer to wright this than it did to do the repair.
        • tom from lawrence, KS
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          15 - 30 mins
        • Tools:
          Nutdriver, Screw drivers
        • Parts Used:
          WP67004284, WP67004151
        43 of 48 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        The facade plate had worn places due to age & Use
        The facade plate is attached to the ice/water dispenser panel with an adhesive. I used a hair dryer to warm and soften the adhesive. Peeled off the old facade and attached the new facade. Never even had to unplug the old. Fun project!!
        • David from Pensacola, FL
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          Less than 15 mins
        • Parts Used:
          WP67004151
        32 of 36 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        The "Ice Dispense" button broke.
        Unplugged refrigerator; removed two screws with a nut driver; removed front panel; removed circuit board; disconnected two electric connectors.
        Reversed process to install new panel.
        • David from Pensacola, FL
        • Difficulty Level:
          Easy
        • Total Repair Time:
          Less than 15 mins
        • Tools:
          Nutdriver, Pliers
        • Parts Used:
          WP67004284, WP67004151
        24 of 34 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        The water/Ice fountain buttons wore out
        Thanks to parts.com showing the schematic the repair was very easy. Note if the buttons fro dispensing water/ice break you need to order two parts. 1. dispenser Facade and 2. Dispenser facade Insert. To replace do the following. remove the catch tray at the bottom of facade. remove the two screws on the bottom and gently pull bottom of insert out and down. Next unsnap the two wires on the selonoid switch. Next pull down on the harness connector from the printed ckt. Next remove small phillips screw that secures the ckt to the insert and gently pry the six plastic clips that hold the ckt to the insert and remove. Next, install the ckt into the new insert and reconnect the selonoid switch. Next, install the insert back on the door. Next, install the Dispensor Facade sticker over the switch buttons taking care that it is aligned properly. Thats it ready to use.
        • Ronald from Townsend, DE
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          Less than 15 mins
        • Tools:
          Nutdriver, Screw drivers
        • Parts Used:
          WP67004151
        16 of 20 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Water - Ice Dispenser not working
        Took lower plate out then removed two screws. Unhooked electronic control board and remove board by removing two small screws. Disconnected wires and replaced with new board. Front cover plate was replaced as the "water - crush - cube buttons on face plate had cracked. Replaced front cover with new plate - used a little glue to keep the small buttons in place. Now we can select all three items and it is working fine.
        • Jose from Floresville, TX
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          30 - 60 mins
        • Tools:
          Screw drivers
        • Parts Used:
          WP67004151, WP67003817
        13 of 16 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Dispenser buttons for water and ice wouldn't cycle
        1.Unplug refrigerator and remove dispenser cup floor plate. 2.Remove two hex head screws.
        3.Remove electronics board phillips head screw.
        4.disconnect actuator switch from dispenser.
        5.Remove electronics board.
        6.Reverse the order on the new Facade and attach Facade insert-black
        • David from Pensacola, FL
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          Less than 15 mins
        • Tools:
          Nutdriver, Screw drivers
        • Parts Used:
          WP67004284, WP67004151
        12 of 17 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Facade face plate was broken.
        This was a fairly easy and straightforward repair that simply involved removal of the old facade face plate by pealing it off and sticking the new one in it's place. The worst part was removing the adhesive from the old facade before I could stick the new one on in its place. Perhaps you could include some advice on how to remove the adhesive. I used Goof-off, but was concerned about it attacking the plastic surface. It seemed to work OK.
        • Robert from East Providence, RI
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          15 - 30 mins
        • Parts Used:
          WP67004151
        7 of 8 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Old facade was cracked from use.
        I checked previous installation instructions posted on your website. Since the facade is a peel and stick, I used a hair dryer to soften the old facade and was then able to just peel it off. I applied heat to one side for about 5 minutes. I then applied the new facade.
        • Harry from KNOXVILLE, TN
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          Less than 15 mins
        • Parts Used:
          WP67004151
        2 of 2 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        The low voltage transformer to under the counter lighting failed.
        The first step in making any repair is finding the right replacement part. It took me about 5 minutes in the internet to locate the correct part at PartSelect. Another 5 minutes to order the correct part and receive a confirming email. Replacement installation of the defective part was 5 minutes to install the new part and verify that the problem was solved. The under-the-counter lighting worked once again which made my wife happy, which as you know make everybody's life better.
        Thanks for the fast shipping.
        • David from Pensacola, FL
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          Less than 15 mins
        • Parts Used:
          WP67004151
        2 of 5 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
          Customer Reviews
          Average Rating:
          ★★★★★
          ★★★★★
          11 Reviews
          5.0
          Filter By Rating:
          • 5 Stars
            11
          • 4 Stars
            0
          • 3 Stars
            0
          • 2 Stars
            0
          • 1 Star
            0
          Sort by:
          Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
          Model Cross Reference
          This part works with the following models:
          PartSelect Number: PS11743579
          Manufacturer Part Number: WP67004151
          Brand
          Model Number
          Description
          Maytag
          GC2223GEKB
          Refrigerator
          Maytag
          GC2224GEKB
          Refrigerator
          Maytag
          GC2225GEK5
          Refrigerator
          Maytag
          GC2225GEK9
          Refrigerator
          Maytag
          GC2225GEKB
          Refrigerator
          Maytag
          GC2225GEKS
          Refrigerator
          Maytag
          GS2325GEKB
          Refrigerator
          Maytag
          GS2625GEKB
          Refrigerator
          Maytag
          GS2625GEKS
          Refrigerator
          Maytag
          GSD2657HEB
          Refrigerator
          Amana
          GZ2626GEKB
          Refrigerator
          Maytag
          GZ2626GEKB13
          Refrigerator - Side-by-side
          Maytag
          GZ2626GEKS
          Refrigerator
          Maytag
          GZ2626GEKS13
          Refrigerator - Side-by-side
          Maytag
          GZ2626GEKW13
          Refrigerator - Side-by-side
          Maytag
          MCD2257HEB
          Refrigerator - Side-by-side
          Maytag
          MCD2257HEQ
          Refrigerator - Side-by-side
          Maytag
          MCD2257HES
          Refrigerator - Side-by-side
          Maytag
          MCD2257HEW
          Refrigerator - Side-by-side
          Maytag
          MCD2257KES
          Refrigerator - Side-by-side
          Maytag
          MSD2351HEB
          Refrigerator - Side-by-side
          Maytag
          MSD2351HEQ
          Refrigerator - Side-by-side
          Maytag
          MSD2351HES
          Refrigerator - Side-by-side
          Maytag
          MSD2351HEW
          Refrigerator - Side-by-side
          Maytag
          MSD2351KES
          Refrigerator - Side-by-side
          Maytag
          MSD2352KEB
          Refrigerator - Side-by-side
          Maytag
          MSD2352KES
          Refrigerator - Side-by-side
          Maytag
          MSD2352KEW
          Refrigerator - Side-by-side
          Maytag
          MSD2355HEB
          Refrigerator - Side-by-side
          Maytag
          MSD2355HEQ
          Refrigerator - Side-by-side
