See part 21 in the diagram
Replacing your Maytag Dryer Timer, 60 Hz. play video
( Grid squares measure 1x1 inch )

Get in touch, we're here to help!

Open until 12am EST

customerservice@partselect.com

Timer, 60 Hz.

★★★★★
★★★★★
3 Reviews
$174.35   In Stock

Get this part fast. Average delivery time via standard shipping: 1.8 days.

PartSelect Number PS11742197
Manufacturer Part Number WP3979617
Manufactured by Whirlpool
Product Description

Timer, 60 Hz. Specifications

This dryer timer is used to control the unit's cycles by regulating the length of time that power is directed to each setting.
How Buying OEM Parts Can Save You Time and Money play video

How Buying OEM Parts Can Save You Time and Money

Troubleshooting
This part fixes the following symptoms:
Will Not Start | Timer will not advance | Will not shut off | Shuts off too soon
This part works with the following products:
Dryer.
This part works with the following products:
Maytag, Whirlpool, Roper, Amana.
Part# WP3979617 replaces these:
AP6009055, 3979617, 8299782
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

2 questions answered by our experts.
    Sort by:
    Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
    Matt
    January 11, 2018
    Whirlpool dryer model wed5200vq0, wife complains clothes taking too long to dry. Cleaned out dryer vent and all venting all the way out of the house. Removed back panel from dryer and checked the temperature selection switch with a mulitmeter. Temp selector switch working correctly. Low heat= 910 ohms medium heat= 5100 ohms high heat= open. Running a normal timed cycle on high heat, element comes on for 2 minutes, then off for 3 minutes. Runs this cycle fine. On low heat the element is on for 1 minute 45 seconds then off for almost 5 minutes. I think the dryer is operating correctly. Do these times sound consistent with how a dryer should work? Thanks
    For model number WED5200VQ0
    Hi Matt, Thank you for your question. It does sound like it is working normally, but if the clothes are not drying you will need to check the thermal fuse, the thermal cut-off, the high limit thermostat, the belt, the door catch, the drum felt seal and the heating connection wire. I hope this helps. Thank you and have a great day!

    1 person found this helpful.

    Was this helpful?
    Thank you for voting!
    Jason
    February 11, 2018
    I checked all my thermostat fuses, all of them are good along with my start button. My timer is running - I can hear it ticking and moving. I can play with and let it sit there, it will start by itself in a few minutes and stop. It will run all the way to off. Then it will start back up. I can only get it to to start around cool down position, but I got it to run for three loads last night before it messed up again . Please tell me what it could be?
    For model number NED5500TQ0
    Hello Jason, Thanks for your question. There are a few parts you will want to test with a multimeter to see if they have continuity. Replace them if they show no continuity. Check the internal-bias thermostat, the thermal cut-off kit, the high-limit thermostat, the door switch, and the drive motor. Only if all of those parts are all testing properly should you then consider the timer itself. I hope this helps.

    Was this helpful?
    Thank you for voting!
    Related Parts:
      Part Videos

      Replacing your Maytag Dryer Timer, 60 Hz.

      Replacing your Maytag Dryer Timer, 60 Hz. play video
      Customer Repair Stories
       Average Repair Rating: 4.3 / 5.0, 6 reviews. What's this?
        Sort by:
        Sorry, we couldn't find any existing installation instruction that matched.
        Timer stopped working
        Well I unplugged the dryer, then I removed all the screws off the back of the main console. After that I unscrewed the old timer. Then I one by one moved the wires from the old timer control to the new timer control. Then i screwed in the new timer control. After that I screwed the back plate for the main console back on. And finally I plugged the dryer back in. And there you go it was that easy.


        I also wanted to say that this experience with parts select was most amazing one too. I ordered the part one day with a 3 to 5 day delevery time. The following day I checked on the status and found out that the part would be here the next day so I was really amazed that it would be that quick. I would recommend and would come back to parts select for futuer needs for appliance parts.
        • Steven from Rantoul, IL
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          15 - 30 mins
        • Tools:
          Socket set
        • Parts Used:
          WP3979617
        22 of 30 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Dryer would not start
        I ordered the timer at 11pm on Thursday and had it in my hand Saturday morning at 11am. 36 hrs delivery time is FANTASTIC as I only asked for standard 3-5 business day delivery.

        Exchanged the wires from the old timer to the new timer and had everything up and running in minutes.

        Thanks partselect...To think I used to pay a guy $70 per hour to do this kind of service.
        AND
        My 16 year old can now fix a dryer...!!!
        • Florian from Saltsburg, PA
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          Less than 15 mins
        • Tools:
          Nutdriver
        • Parts Used:
          WP3979617
        12 of 19 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Dryer would not run unless I adjusted the timer switch manually
        I simply removed the back panel (6 screws), removed old switch, swapped wires and reinstalled. Varied repair. That easy
        • Steven from BELTON, MO
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          Less than 15 mins
        • Tools:
          Nutdriver, Pliers
        • Parts Used:
          WP3979617
        3 of 3 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Timer never advanced, kept ticking and stuck in the same spot, dryer DID heat
        Replace timer. Remove back panel and the two screws attaching the old timer. Remove each wire from the old timer one at a time, noting where the wire it attached, and attach it to the same place on the new timer. You may need pliers to gently grip the wire base and pull. Wires are labeled on the timer by color codes if needed. Seek additional reference if necessary. Replace the back panel and test dryer to ensure the new timer is working.
        • Brittney from HATTIESBURG, MS
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          15 - 30 mins
        • Tools:
          Pliers, Screw drivers, Socket set
        • Parts Used:
          WP3979617
        2 of 2 people found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Timer switch bad on 11 yr old dryer
        My switch part #3976197 has since been replaced by a different switch. The new switch had different and fewer terminals and no instructions on how to install with the 3 extra wires it left me hanging with. I had to return the switch. I also got one from another company and they sent the same replacement switch.
        I had to return that one.
        I could not find my exact switch anywhere.
        I bought a new dryer.
        The old dryer went to the recycle.
        The end.
        • Paul from ROYSE CITY, TX
        • Difficulty Level:
          Very Difficult
        • Total Repair Time:
          Less than 15 mins
        • Tools:
          Nutdriver, Screw drivers, Socket set
        • Parts Used:
          WP3979617
        1 person found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
        Timer quit working
        Pulled back plate off dryer control center (six screws). Removed old timer (two screws). Placed new timer along side old one. Switched wires from old to new timer. Reinstalled new timer. Cleaned dryer with vacuum cleaner before placing back panel on. Easy to accomplish.
        • William from BATH, NC
        • Difficulty Level:
          Really Easy
        • Total Repair Time:
          15 - 30 mins
        • Tools:
          Nutdriver
        • Parts Used:
          WP3979617
        1 person found this instruction helpful.
        Was this instruction helpful to you?
        Thank you for voting!
          Customer Reviews
          Average Rating:
          ★★★★★
          ★★★★★
          3 Reviews
          3.7
          Filter By Rating:
          • 5 Stars
            2
          • 4 Stars
            0
          • 3 Stars
            0
          • 2 Stars
            0
          • 1 Star
            1
            Sort by:
            Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
              Model Cross Reference
              This part works with the following models:
              PartSelect Number: PS11742197
              Manufacturer Part Number: WP3979617
              Brand
              Model Number
              Description
              Whirlpool
              1CWED5100VQ0
              Dryer - Residential
              Whirlpool
              1CWED5200VQ0
              Dryer - Residential
              Maytag
              4GMEDC300YW0
              Dryer - 29" ELECTRIC DRYER
              Maytag
              4GMEDC300YW1
              Dryer - 29" ELECTRIC DRYER
              Maytag
              4GMEDC300YW2
              Dryer - 29" ELECTRIC DRYER
              Maytag
              4KMED5700TQ0
              Dryer - RESIDENTIAL DRYER
              Maytag
              4KMED5700TQ1
              Dryer - 29" ELECTRIC DRYER
              Maytag
              4KMED5900TW0
              Dryer - RESIDENTIAL DRYER
              Maytag
              4KMEDC300BW0
              Dryer - ELECTRIC DRYER
              Maytag
              4KMEDX505BW0
              Dryer - ELECTRIC DRYER
              Amana
              4KNED5800TQ0
              Dryer - RESIDENTIAL DRYER
              Amana
              4KNED5800TQ1
              Dryer - 29" ELECTRIC DRYER
              Admiral
              AED4470TQ0
              Dryer - Residential
              Estate
              EED4400TQ0
              Dryer - Residential
              Magic Chef
              HED4400TQ0
              Dryer - Residential
              Inglis
              IED4400SQ0
              Dryer - 29" Electric
              Inglis
              IED4400TQ0
              Dryer - 29" Electric
              Inglis
              IES5000RQ0
              Dryer - Residential
              Inglis
              IES5000RQ1
              Dryer - Residential
              Inglis
              IS82000
              Dryer - Residential
              Inglis
              IV86000
              Dryer - Residential
              Inglis
              IV87000
              Dryer - Residential
              Maytag
              MED5600TQ0
              Dryer - Residential
              Maytag
              MED5600TQ1
              Dryer - Residential
              Maytag
              MED5620TQ0
              Dryer - Residential
              Maytag
              MED5620TQ1
              Dryer - Residential
              Maytag
              MED5621TQ0
              Dryer - Residential
              Maytag
              MED5630TQ0
              Dryer - Residential
              Maytag
              MED5630TQ1
              Dryer - Residential
              Amana
              NED5400TQ0
              Dryer - Residential
