See part 22 in the diagram
Replacing your Admiral Washer Drain Hose with Bend and Stay play video
( Grid squares measure 1x1 inch )

Get in touch, we're here to help!

Open until 10PM EST

customerservice@partselect.com

Drain Hose with Bend and Stay

$43.63   In Stock

Get this part fast. Average delivery time via standard shipping: 1.8 days.

PartSelect Number PS11738832
Manufacturer Part Number WP21001872
Manufactured by Whirlpool
Troubleshooting
This part fixes the following symptoms:
Leaking
This part works with the following products:
Washer.
This part works with the following products:
Admiral, Maytag, Norge, Magic Chef.
Part# WP21001872 replaces these:
21001512, 21001513, 21001872, 31001337, 31001338, 35-2803, 35-2804, 35-3538, 35-3539
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

Part Videos

Replacing your Admiral Washer Drain Hose with Bend and Stay

Replacing your Admiral Washer Drain Hose with Bend and Stay play video
Customer Repair Stories
 Average Repair Rating: 4.1 / 5.0, 3 reviews. What's this?
    Sort by:
    Sorry, we couldn't find any existing installation instruction that matched.
    Original drain hose (rubber) was kinking, piece of junk. I replaced it with a new corigated drain hose .
    Leaned washer forward, removed clamp and old hose, replaced with new hose, reinstalling clamp.
    • Edwin from Eagar, AZ
    • Difficulty Level:
      Easy
    • Total Repair Time:
      Less than 15 mins
    • Tools:
      Nutdriver
    • Parts Used:
      WP21001872
    6 of 11 people found this instruction helpful.
    Was this instruction helpful to you?
    Thank you for voting!
    Cracked hose AGAIN!
    Hired someone. Note: I purchased two (2) hoses and (2) clamps -- this is the third time I am replacing a cracked hose. The manufacturer needs to use better quality and more flexible material for hoses.
    • BLANCHE from OSSINING, NY
    • Difficulty Level:
      Easy
    • Total Repair Time:
      Less than 15 mins
    • Parts Used:
      WP21001872, WP285655
    5 of 15 people found this instruction helpful.
    Was this instruction helpful to you?
    Thank you for voting!
    Smell from washer
    Using nutdriver or screwdriver, remove metal panel from lower left side of back of washer to expose the pump. This is where the drain hose attaches to the washer. Use pliers to move the clamp off of the drain hose, then ease the hose off of the pump by wiggling it back and forth while pulling gently. Be careful to keep drain hose opening pointed upward until you can point it to a bucket, as there's likely to be quite a bit of water in it. Detach drain hose on other end as well (wiggling / pulling works well here; no clamp is used, so no pliers are required). Install new hose by reversing above steps.
    • Patrick from PALO ALTO, CA
    • Difficulty Level:
      Really Easy
    • Total Repair Time:
      30 - 60 mins
    • Tools:
      Nutdriver, Pliers, Screw drivers
    • Parts Used:
      WP21001872
    2 of 2 people found this instruction helpful.
    Was this instruction helpful to you?
    Thank you for voting!
      Model Cross Reference
      This part works with the following models:
      PartSelect Number: PS11738832
      Manufacturer Part Number: WP21001872
      Brand
      Model Number
      Description
      Norge
      6002A
      Washer - WASHER
      Norge
      6002A REV A
      Washer - Norge Washing Machine Model 6002A REV A (6002AREVA) Parts
      Norge
      6433A
      Washer - WASHER
      Norge
      6440A
      Washer - WASHER
      Norge
      6440A REV K
      Washer - Norge Washing Machine Model 6440A REV K (6440AREVK) Parts
      Norge
      6443A
      Washer - WASHER
      Norge
      6443A REV D
      Washer - Norge Washing Machine Model 6443A REV D (6443AREVD) Parts
      Norge
      6443B
      Washer - WASHER
      Norge
      6532A
      Washer - WASHER
      Norge
      6532A REV C
      Washer - Norge Washing Machine Model 6532A REV C (6532AREVC) Parts
      Norge
      6532A REV E
      Washer - Norge Washing Machine Model 6532A REV E (6532AREVE) Parts
      Norge
      6532A REV F
      Washer - Norge Washing Machine Model 6532A REV F (6532AREVF) Parts
      Norge
      6532A REV G
      Washer - Norge Washing Machine Model 6532A REV G (6532AREVG) Parts
      Norge
      6540A
      Washer - WASHER
      Norge
      6540A REV K
      Washer - Norge Washing Machine Model 6540A REV K (6540AREVK) Parts
      Norge
      6543
      Washer - WASHER
      Norge
      6543 REV D
      Washer - Norge Washing Machine Model 6543 REV D (6543REVD) Parts
      Norge
      6543A
      Washer - WASHER
      Norge
      6544A
      Washer - WASHER
      Norge
      6544A REV B
      Washer - Norge Washing Machine Model 6544A REV B (6544AREVB) Parts
      Norge
      6640A
      Washer - WASHER
      Norge
      6640A REV K
      Washer - Norge Washing Machine Model 6640A REV K (6640AREVK) Parts
      Norge
      6643A
      Washer - WASHER
      Norge
      6643A REV D
      Washer - Norge Washing Machine Model 6643A REV D (6643AREVD) Parts
      Norge
      6643B
      Washer - WASHER
      Norge
      6740A
      Washer - WASHER
      Norge
      6741A
      Washer - WASHER
      Norge
      6741A71
      Washer - WASHER
      Norge
      6742A
      Washer - WASHER
      Norge
      6742B
      Washer - WASHER
