Model Number Locations
1Select Category Type
Select Category Type
2Select Product Type
Select Product Type
3Select {MODEL} Type
Select {MODEL} Type
Sample Model Number Tags
Model numbers can be made up of numbers (1005400, for example) or a combination of letters and numbers (LAT1000AAE). The model number will most likely appear on either a paper sticker or a metal plate. Your appliance's model number tag may look similar to the sample model number tags shown here (model number highlighted in yellow):
Model has been saved to My Models. If you're not signed in, your lists are available on this device and will expire within 30 days.
Model has been saved to My Models.
This dishwasher door hinge cable assembly connects the door to the spring. The door hinge cable and the door spring apply tension to the door to prevent it from dropping open too quickly. This part co...
$16.69
In Stock
Order now and your part arrives in 2-3 business days!
The dishwasher roller assembly connects to the dishrack, and is located in the lower level of the dishwasher. It allows the dishrack to easily slide in and out. If the lower rack keeps falling off the...
$13.71
In Stock
Order now and your part arrives in 2-3 business days!
The rack roller and axle in your dishwasher allows the dish rack to slide in and out effectively.If you notice that your dish rack is not performing this function, or if one or more of your rack rolle...
$12.53
In Stock
Order now and your part arrives in 2-3 business days!
The door spring, used in dishwashers, adds tension to the door through the door hinge to keep it from opening too fast. If you have a door latch failure or your washer door drops too quickly when open...
$28.63
In Stock
Order now and your part arrives in 2-3 business days!
This dishwasher door gasket is designed to form a secure, watertight seal around the tub, preventing leaks and enhancing overall wash efficiency. Constructed from flexible, heat-resistant black rubber...
$62.98
In Stock
Order now and your part arrives in 2-3 business days!
This nozzle assembly, commonly referred to as a sprayer head or spray arm, is an authentic replacement part supplied directly by LG for use in LG dishwashers. The nozzle assembly can be found at the b...
$63.04
In Stock
Order now and your part arrives in 2-3 business days!
Presenting the LG Silverware Basket Assembly for some dishwasher models. This product is a genuine LG item, specially constructed for accommodating small utensils in the lower dishrack during the dish...
$41.84
In Stock
Order now and your part arrives in 2-3 business days!
This diverter motor, or stepper motor, controls the movement of the spray arms in your dishwasher. It directs water between the drain pump and the spray arms by turning a check valve inside the pump, ...
$51.57
In Stock
Order now and your part arrives in 2-3 business days!
This is the lower dishrack assembly for various models of LG dishwashers. This dishrack is an OEM part that is designed to hold dishes and cutlery during the wash cycle of the dishwasher. This dishrac...
Discover excellence in dishwashers parts with this Dishrack Roller Bracket from LG. Expertly engineered, this genuine OEM item securely attaches the roller wheels of your dishwasher to the dishrack, e...
$13.71
In Stock
Order now and your part arrives in 2-3 business days!
Improve the efficiency of your LG dishwasher with this Middle Spray Arm Manifold Guide Assembly. This genuine LG part is designed to hold the spray arm and facilitates its connection to the water feed...
$51.57
In Stock
Order now and your part arrives in 2-3 business days!
This corrugated drain hose assembly directs wastewater from your dishwasher to the household drainage system. Positioned at the rear of the unit, it connects the pump to the sink drain or garbage disp...
$78.50
In Stock
Order now and your part arrives in 2-3 business days!
Questions And Answers for LDF7774ST
Ask our experts a question about this model and we'll get back to you as soon as possible!
21 questions answered by our experts.
Sort by:
< Prev
1
2
3
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Ken
January 28, 2020
The rotating arm (that sprays water) under the top drinking glass rack keeps falling off. I reattach it by snapping back in place but it eventually falls off again. I don't know the specific part name to order a new one
For model number LDF7774ST
Hi Ken, thank you for your question. That part would be called your nozzle, part number: PS3527665. You may also need to replace the guide it clips into as well: PS12075961. Good luck with your repair.
6 people found this helpful.
Was this helpful?
Thank you for voting!
Kevin
March 9, 2020
Looking for upper dishwasher rack replacement tines. Both right side folding tines are badly rusted and unsightly.
For model number LDF7774ST
Hello Kevin,
Thank you for your question. The folding tine on the right side is under part PS7796046 for your model. We hope this helps.
The buttons on the select panel only work when the door is about 6 inches away from closed or fully closed. If the door is open any more than this, you cannot select the cycle and no buttons light up.
For model number LDF7774ST
Hello Becky, thank you for your inquiry. We have narrowed the issue down to the following parts: the control panel, part number PS10066436, and the door latch, part number PS5574492. Check both the parts and replace the defective one. We hope this is what you were looking for!
The dishwasher continues to cycle until the door is open or the breaker is turned off. Do you know what part I would order to fix this problem
For model number LDF7774ST
Hello and thank you for writing.
Your dishwasher runs on a cycle of cleaning and drying. When the washer will not switch over from one cycle to the next, it may run continuously until you either unplug the unit or open the door of the unit. A dishwasher that continues to cycle may have a bad heating element PS7788065 or control panel PS10066436. We hope this helps. Please contact us anytime if you require further assistance.
Simple, removed screws securing machine in the cabinet, then pull the unit out of the cabinet space about 10 inches. Springs are accessible within this extension. You need strong hands to extend the springs and attach them. Once attached, push machine back in place and re-install the anchor screws. In my situation, only one spring was bro
... Read moreken, so the attached side revealed the correct slot to place the hook on the top position, the bottom position has a plastic lead for the spring, and that lead is attached to a rope to the door hinge. Note: Replace BOTH springs, even if only one is broken.
The inside gasket deteriorates over time - However replacement is easy. the main thing you have to remember is after you remove the old gasket, install the new one starting at the middle top of the tub and work your way down both sides. Also, don't push the gasket all the way in...only enough to hold in place. When you close the door the
... Read moregasket will form a better seal around the door.
