Agitator Kit 285565
Official part for Whirlpool, Inglis, Roper, Estate
About This Part
What it does. Why it matters. Everything you need to know for an easy fix.
Agitator Kit Specifications
This agitator kit does NOT include the fabric softener dispenser (part 8575076A). That must be ordered separately.
Part #285565
Manufactured by
Whirlpool
for Whirlpool, Inglis, Roper, Estate
You May Also Need
Because heroes deserve fewer surprise re-installs.
$6.40
In Stock
$18.22
In Stock
$20.36
Special Order
Affresh Dishwasher Cleaner Tablets - 6
Part #W10549851
$22.52
In Stock
Affresh Washing Machine Cleaner Tablets – 6 Count
Part #W10501250
$28.42
In Stock
$18.22
On Order
$27.36
In Stock
Refrigerator Deodorizer
Part #MCS62101805
$31.58
In Stock
Genuine OEM: Original Parts. Lasting Repairs.
Because quality isn't optional.
OEM stands for Original Equipment Manufacturer. This means that the company who made your appliance is also supplying the replacement part.
| Features | OEM | Generic |
|---|---|---|
| Genuine brand name | ||
| Guaranteed to fit | ||
| Superior Quality | ||
| Long term value |
Part Videos
Watch our pros, then fix it yourself.
Replacing your Whirlpool Washer Agitator Kit
Replacing your Whirlpool Washer Agitator Kit
Repair Tips
See how others fixed this model. Time, tools, difficulty, and steps that lead to victory!
Sort by:
- Prev
- 1
- 2
- 3
- Next
Search repair tips from other customers using simple keywords like "replace", "fit", "remove", "inspect". DIY doesn't mean you have to do it alone!
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Sorry, we couldn't find any existing installation instruction that matched.
Splines on lower agitator bad, worn.
9 of 10 people
found this instruction helpful.
Had to clean debris on metal drive shaft splines in orderv forvnew lower agiitator to seat properly. Install upper agitator and parts then reinsert bolt in upper agitator. Install cap and o-ring, fabric softner dispenser and test for proper operation.
Other Parts Used:
Was this helpful?
Thank you for voting!
Agitator broke & plug missing
3 of 4 people
found this instruction helpful.
Removed top of agitator and undid the bolt with 7/16ths extended socket wrench. Took out the full agitator. Three plugs had to be removed one was missing. They were in ruff shape. You have to push in the plugs until they snap in. Put in the new agitator and put the bolt back in.
Other Parts Used:
Was this helpful?
Thank you for voting!
Worn out agitator directional clogs.
3 of 3 people
found this instruction helpful.
I just ordered the complete agitator kit since I didn't know for sure what I all needed, and it made my repair so easy replacing since it was all complete. I followed video which was a great help. Got it all done in 25 minutes. Very easy. Thank you...
Other Parts Used:
Was this helpful?
Thank you for voting!
- Prev
- 1
- 2
- 3
- Next
DIY Questions and Expert Answers
14 questions answered by our Repair Experts.
Ask our experts a question about this part and we'll get back to you as soon as possible!
We may have answered a similar question already! Search questions and answers left by others using simple keywords like "fit", "broken", "easy", or "quality" to find questions that match.
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Sort by:
- Prev
- 1
- 2
- Next
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Chris
- For model number NTW4516FW2
August 3, 2018
What is the part number for liquid fabric dispencer? All i see is that part has to be ordered. I need the part number please.
Hello Chris, Thank you for contacting us. I have researched the model you have provided and have found the part you’re looking for is PartSelect #: PS1488027. Hope this helps!
8 people
found this instruction helpful.
Was this helpful?
Thank you for voting!
Tom
- For model number NTW4516FW3
August 2, 2021
The bucket of the dog's harness is bought under the agitator of the washer. How do i loosen the agitator to lift it up to remove the harness buckle from under the agitator?
Hello Tom, Thank you for your inquiry. You need to start by removing the cap, the cap barrier, and use a socket wrench to remove the bolt from the agitator. You should then be able to pull the agitator out. We have included a link to our video for a similar agitator to assist you with removing the agitator. Hope this helps.
8 people
found this instruction helpful.
Was this helpful?
Thank you for voting!
Eric
January 21, 2018
What's all in the agitator kit 285565?
Hi Eric,
Thank you for your question. The kit includes the bottom base, the agitator dogs, the cap and the agitator mover. I hope this helps. Thank you and have a great day!
3 people
found this instruction helpful.
Was this helpful?
Thank you for voting!
Jamal
- For model number ETW4400WQ0
November 20, 2018
My washer is not agitating . I replaced the agitator dog & motor drive coupling. Still is not agitating & make noise during the regular wash. Please help
Hi Jamal, thank you for your question. There are a few parts that you will have to check to see if they need to be replaced. You should check your thrust spacer and agitator cam bearing. Both of those parts are in the agitator repair kit. You may also want to take a look at your agitator cams, your gearcase, and then finally your motor itself. I hope that helps. Good luck with your repair.
$158.35
In Stock
$38.96
In Stock
$21.45
In Stock
$299.77
In Stock
$19.30
In Stock
$158.79
In Stock
3 people
found this instruction helpful.
Was this helpful?
Thank you for voting!
Chris
August 3, 2018
I just need the fabric softener dispenser not the entire agitator. This is a new washer. Do you have a part number for just the dispenser
Hello Chris, Thank you for contacting us. I have researched the model you have provided and have found the part you’re looking for is PartSelect #: PS1488027. Hope this helps!
2 people
found this instruction helpful.
Was this helpful?
Thank you for voting!
Robert
- For model number ITW4871FW2
December 22, 2019
Good day. Could you please tell me the part number for the softener dispenser accessory for this model washer? Thank you.
Hello Robert and thank you for writing.
Softener dispenser. This part is discontinued for your model and is no longer available. We have no known replacement information in our system. We recommend you contact the manufacturer of the part to see if they have recently released a new substitute. We do carry related parts for units just like yours. For example, part number PS11749935 Good luck with your repair.
$9.62
In Stock
1 person
found this instruction helpful.
Was this helpful?
Thank you for voting!
Leroy
- For model number LSR8433KQO
December 15, 2022
The agitate won't turn while washing but the bottom section is turning. Would the agitator kit would be all I should need for this. Washer runs fine does a great job just now the the top agitator won't turn?
Hello Leroy, thank you for reaching out. We have researched your model and would recommend checking the following parts to fix your issue: agitator directional cogs, part number PS388034, agitator repair kit, part number PS334650, drive motor coupling, part number PS1485646, and upper agitator, part number PS11741159. Please reach out to customer service if you need help placing an order. Glad to be of help!
$21.45
In Stock
$6.40
In Stock
$21.45
In Stock
$106.36
In Stock
1 person
found this instruction helpful.
Was this helpful?
Thank you for voting!
Heidi
- For model number NTW4516FW3
May 29, 2023
Just wanted to know if this would work for an Amana washer.
Serial number
C91630105
Hello Heidi, Thank you for your inquiry. We confirm that this part will fit your model. We hope this helps.
Was this helpful?
Thank you for voting!
David
- For model number 110.25852400
May 31, 2023
Looking for ‘dust cover’ part number in agitator assembly. Exploded parts diagram it’s items 2 and 3
Hi David, thank you for contacting us. According to our research, your model does not include a separate agitator cap barrier and seal. These parts come with the fabric softener dispenser, part number PS11746095, that is present on the top of the agitator. We look forward to hearing from you if you need assistance with placing an order through our 7-day-a-week customer service!
$16.07
In Stock
Was this helpful?
Thank you for voting!
Ruby
- For model number Wtw5100v02
September 9, 2023
Agitator is real lose and wobblie
Hi Ruby, thank you for getting in touch. Based on our understanding of the issue, we would suggest you tighten the bolt at the bottom of the agitator. When the bolt is loose, it causes the agitator to wobble. If this still does not resolve the issue, then we would suggest checking the directional cogs, part number PS388034, to fix the issue. We hope this solves your problem!
$6.40
In Stock
Was this helpful?
Thank you for voting!
