This high limit thermostat is used in a dryer and monitors the temperature to make sure it does not exceed 260 degrees Fahrenheit. When your dryer temperature reaches 260 it will cut it out and only comes back when it drops by at least 70 degrees Fahrenheit. If your dryer is overheating, taking too long to dry clothes, or is not producing...Read more enough heat, replacing the thermostat could be the solution to your problem. The tools needed for this part are a Phillips screwdriver, putty knife, and needle nose pliers. Refer to the manual provided by the manufacturer for installation instructions and guidance.
This part is a heater, but may also be known as a heating element, and it is meant for your dryer. This is where the heat is generated during your machine cycle in order to properly dry your clothing. This model is a 5500 watt, and has three coils. If your heater is broken, that usually means there is a break in the coil element.If you ar...Read moree having trouble drying your clothes, you may want to check for a thermal cut out or a blown thermal fuse. For this repair you will need a number two square bit, a Phillips screwdriver, and a flat-head screwdriver.
Located at the front of the washing machine, this dryer lint filter traps lint and debris from the exhaust air flowing out of the dryer drum. This part measures approximately 14 inches long x 11 inches high. It has a plastic frame and a mesh body to catch debris. If your filter needs cleaning, the dryer cycle will take longer due to a bui...Read moreldup or lint or fabric softener affecting the air flow through the filter. If there is a buildup, try scrubbing the filter with hot water and soap. But if the filter is damaged, worn, or torn, it should be replaced. Cleaning the lint filter before starting the drying cycle is a great way to ensure your dryer performs properly.
This part could be found underneath a fridge, dryer, or freezer. The original foot may be cracked, broken, or perhaps missing altogether. If you notice the appliance is uneven to the floor or wobbling, it may indicate that the levelling foot needs to be replaced. You will need pliers and a block of wood to perform this task. There will be...Read more one adjustable foot found in the package. Lift the dryer and place the wood to keep it propped up. You may need to use the pliers to remove the old foot. Screw the new foot into place using your hand. Once the new leveling foot is in place, lift the appliance and remove the block. Test the machine out to ensure it is now sitting level.
This is a replacement screw for your washer or dryer. The screw is approximately half an inch in length and is a Phillips-head screw. It screws in from the outside of the drum, into the vane/baffle. The main reason you would replace this screw is if the old screw is missing or damaged. This part is sold individually and is an OEM part sourced directly from the manufacturer.
This dryer belt is one of the most important parts in a dryer and is what allows the dryer drum to spin/rotate. If the dryer belt is damaged or broken, the drum will not spin or will have difficulty in doing so, and your clothes will still be damp after a cycle as a result. This belt is made of durable material and can wear down over time...Read more and extended use of the dryer. Replacing a dryer belt will require some disassembly of your dryer, so a screwdriver and wrench will be needed to access and replace it. This belt is an individual OEM part.
This high temperature adhesive is used for installing felt and rubber seals on dryers. The tube contains 1 ounce of product. This adhesive is made to withstand extremely hot temperatures. Before applying the adhesive, ensure that the area is completely clean from any debris and is dry. You may wish to use small clamps to hold the material...Read more in place while it dries. If the felt has come loose or broken apart, this may cause your dryer to make loud noise, indicating that new felt or rubber needs to be glued into place. Use gloves to apply glue.
Discover the quality and reliability of genuine Frigidaire parts with this Thermal Limiter. Specially designed to protect from overheating, this non-resetable thermal fuse shuts off your dryer's heater if an overheating scenario occurs. A perfect fit for some models of Frigidaire, Electrolux, White Westinghouse, and Tappan, we encourage y...Read moreou to ensure this part fits your model appropriately, as size and shape can slightly vary. Prioritize safety by unplugging your dryer and wearing work gloves during installation. Elevate the performance of your Frigidaire appliance with this trusted, high-quality part.
This replacement drum support roller helps keep your dryer drum turning smoothly and quietly during operation. Designed for reliable performance, it supports the drum as it rotates to help reduce excess noise, vibration, and wear. Replacing a worn roller can help restore proper drum movement and improve dryer performance. For installation...Read more, unplug the dryer, access the drum support area, and replace the old roller with the new component. Always wear work gloves for added safety during repairs.
This dryer thermal fuse is a critical safety component designed to protect the appliance from overheating. It automatically shuts off power to the motor or heating system if excessive temperatures are detected, helping prevent damage or potential fire hazards. Once the fuse is triggered, it cannot be reset and must be replaced. A faulty t...Read morehermal fuse may cause the dryer not to start, run without heat, shut off prematurely, or operate at unsafe temperatures. Replacing this component helps restore safe and proper dryer operation.
This moisture sensor assembly ensures your dryer delivers optimal performance by detecting the moisture level in each load. By accurately measuring dampness, it allows the appliance to adjust cycle times automatically, preventing over-drying or under-drying and improving energy efficiency. Ideal for resolving issues such as clothes coming...Read more out damp, overly dry, or cycles ending too soon or running too long, this durable component restores precision and reliability. Installation is simple—disconnect power, remove the old sensor, and secure the new one in place.
Ask our experts a question about this model and we'll get back to you as soon as possible!
We may have answered a similar question already! Search questions and answers left by others using simple keywords like "fit", "broken", "easy", or "quality" to find questions that match.
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Sort by:
Prev
1
Next
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Dean - For model number EIMED55IIW0
December 19, 2019
Will not dry completely, before stopping and showing E-64 code.
Hi Dean,
Thank you for your question. The E64 error code refers to an open heating element circuit. You will need to unplug the dryer and check the wire harness connections between the electronic control board and the heating element. Reconnect any loose wires and replace the wire harness if damaged. Inspect the heating element for damage and replace the element if broken. If you see no visible damage to the heating element, test it for continuity using a multi-meter. If the heating element is electrically open, replace it. We hope this helps. Thank you and have a great day!
2 peoplefound this instruction helpful.
Was this helpful?
Thank you for voting!
Jim - For model number EIMED55IIW0
December 17, 2021
The rotating knob on the control panel does not allow us to set the dryer to the type of clothes in the dryer drum. With repeating the rotation many times we can reach the right setting. I think i need a new control panel.
Hello Jim, Thank you for your inquiry. The knob actually attaches to the electronic control board and if it is now allowing you to set the dryer settings, it could be the control board. Good luck with your repair.
I have a EF1 code on my dryer and the vents and screens are all clean/ not clogged. Google says I need a thermistor but I'm having trouble finding that part for my specific model. Is it another part that I need?
Hello Nora, thank you for your inquiry. According to our research, this error code indicates that the temperature regulation in the dryer is not correct. You may need to replace the thermistor, part number PS2349280, to solve the problem. We hope that helps!
Hello Donna, thank you for your query. Based on our research, the E51 error indicates a short circuit detected in the motor power triac due to a faulty motor, defective wiring, or the electronic board not functioning properly. You may need to check the electronic control board, part number PS10057456, to fix the issue. We hope this solves your problem!
Grinding type noise at start of cycle and goes away a few seconds later but cycle doesn’t sound smooth as usual
Hello Justin, thank you for your inquiry. Based on our understanding of the issue, we would recommend checking the drum support roller and axle, part number PS12746506. The dryer drum roller holds the drum in place while it rotates on the dryer support wheels. If rollers are worn out, the dryer will be noisy. Glad to be of help!
See how others fixed this model. Time, tools, difficulty, and steps that lead to victory!View More
Search repair tips from other customers using simple keywords like "replace", "fit", "remove", "inspect". DIY doesn't mean you have to do it alone!
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Noisy Dryer
57 of 69 peoplefound this instruction helpful.
Philip from Oakland, CA
A Bit Difficult
1- 2 hours
Pliers, Screw drivers, Wrench (Adjustable)
When I described the noise to a YouTube appliance diagnostician, I was directed to check the felt seals front and back of the rotating drum for wear, tears, or foreign objects. As it happens the felt seals looked find and there were foreign objects so, not wanting to disassemble and reassemble the dryer more than I had, I ended up replac
... Read moreing all the replaceable moving parts that I considered possible culprits: The idler tension spring, the idler tension bracket (which includes a nylon pulley wheel), the drum belt, the five rubber-tipped bearings that support the drum and keep it in place, and the foam seal on the blower housing which seemed a little brittle and old, as well as high-temperature adhesive for the latter. The instructional videos here and on YouTube were extremely helpful (I doubt that I would have attempted this job at all, had I not watched these ahead of time). The most time-consuming aspect was waiting for the arrival of the parts as I didn't order them all at the same time or all from the same place (I ordered from whomever could ship me a given part the fastest. Disassembly took less than an hour. Re-assembly with the new parts in place took about the same but was a little more awkward because this appliance sits in a very narrow closet and it's difficult to ensure that the 4" flexible duct stays in place when sliding the appliance back into the closet. No regrets. Now I know the basics if this dryer needs attention in future and I also know all the parts that I can eliminate as suspects in any future maintenance (the parts that I replaced)
Dryer wasn't heating properly, drying took too long.
24 of 28 peoplefound this instruction helpful.
Steven from MARIETTA, GA
Easy
30 - 60 mins
Nutdriver, Pliers, Screw drivers
Removed back of dryer with electric nut driver. Lots of screws. Removed old heating element to better access wires and thermostats. Removed baffle at end and transferred to new heater element. Transferred thermostats to new element, reconnected wiring in correct order. Installed new heater element in correct position using tab to loca
... Read morete. Replaced back of dryer. Reconnected dryer vent. Toughest part was squeezing out of space after reconnecting dryer vent. Unfortunately, too short for my weight.
Read less
Was this helpful?
Thank you for voting!
Internal vent inside the drum was coated in black (plastics from use)
11 of 13 peoplefound this instruction helpful.
Rich from New Albany, OH
Easy
30 - 60 mins
Screw drivers
1. Loosened the 3 screws inside of the drum 2. Removed the entire back of the dryer (lots of screws) 3. Removed the old vent (there are 2 screws at the bottom that hold it in) 4. Install new vent (put the screws back in) 5. Close up back and proceed to put all of the screws back
