WRS321SDHB01 Whirlpool Refrigerator - Overview

(111)

Part #EDR1RXD1

The EDR1RXD1 water filter provides clean, fresh-tasting water by reducing contaminants such as lead, chlorine, and particulates. Designed for easy installation, this filter ensures your refrigerator water and ice are safe and refreshing with every use

$30.53

Refrigerator Door Switch

(95)

Part #W11384469

Door switch turns the light off when you close the door.

$53.20

Refrigerator Ice Bin Auger Drum

(30)

Part #4388736

This white ice bin auger drum comes with a washer.

$30.53

Door Switch

(40)

Part #W11396033

This light switch may also be known as a refrigerator door switch or a light switch kit, and is compatible with your refrigerator. The function of the refrigerator door switch is to turn on the light when your fridge door is open, and to make sure it is off when your refrigerator door is closed. The reason you would need to replace this p...Read more

Read less

$120.54

Door Shelf Bin

(38)

Part #W11239961

This is a door shelf bin made for use within some models of refrigerators. This shelf bin is used to hold food items and containers, but if it is cracked or damaged and no longer able to hold any items, it needs to be replaced immediately. This shelf measures 15-inches wide at its widest point, and 13-inches wide where it would be install...Read more

Read less

$111.56

Crisper Drawer

(26)

Part #W11162443

This is a manufacturer-made crisper drawer for your refrigerator. Crisper drawers are used to store fruits and vegetables at different humidity levels than the rest of your fridge. If your current crisper drawer is cracked or broken, it will need replacing immediately to ensure your food lasts as long as possible. This crisper drawer is m...Read more

Read less

$11.77

Refrigerator Screw

(3)

Part #WPW10661886

This mounting screw is a genuine OEM replacement part for the door handle in your refrigerator. If you are having trouble shutting the refrigerator door, or opening it, replacing this screw can help solve the issue. Replacing this part is easy and requires minimal disassembly of the refrigerator end cap handle. Your will need a screwdriver to complete this repair.

$27.36

Water Tube Kit

(8)

Part #W10823511

This is the replacement water tube kit for your refrigerator. This tubing is made of plastic, is 1/4 inch in diameter, and comes with 2 inserts. This tube may be longer than the original tube, and may need to be cut. This water tube transports water to the ice and water dispensers. If your refrigerator is leaking, or if the ice and water ...Read more

Read less

$62.60

Door Shelf

(22)

Part #WP2309941

This authentic Whirlpool refrigerator part is a door shelf rail. It snaps into your refrigerator door and prevents items from sliding or falling out when your open the door. It is made of plastic and is approximately 17 inches in length by 5 inches in width. To replace this part, simply snap out the old door shelf rail and install the new one.

Touch-Up Paint - White

(7)

Part #72017

This touch-up paint can be used on a wide variety of household appliances. It is most often used on washers, dryer, refrigerators, dishwashers, ranges, freezers, trash compactors, or microwaves. It is an 18 ml, or.6 fluid ounces, bottle of touch-up paint. It also features a brush for easy application. This quick-drying, long-lasting paint...Read more

Read less

$11.77

Refrigerator Screw

(1)

Part #WP489497

Sold individually.

$11.77

Screw

(1)

Part #WP489483

This screw is sold individually.

Questions And Answers for WRS321SDHB01

Ask our experts a question about this model and we'll get back to you as soon as possible!

Sort by:

Richard - For model number WRS321SDHB01

February 6, 2023

H2O error no water being dispensed

Hello Richard, thank you for reaching us. We have researched your model and found that the error code H2O indicates that the filter is faulty, and the water filter needs to be replaced. The compatible water filter to your model is part number PS11701542. Resetting the Filter Status After changing the filter: 1. Press and hold the LIGHT and ICE TYPE button for 3 seconds. 2.The status light will turn off when the system is reset. We hope this information helps!

$84.45

Refrigerator Ice and Water Filter

1 person found this instruction helpful.

Was this helpful?

Ronald - For model number WRS321SDHB01

March 1, 2024

IM LOOKING FOR THE REFRIGERATOR SIDE DRAWER LAYOUT

Hi Ronald, thank you for getting in touch. If you are looking for the schematic diagram of the fresh food section drawers, then we have attached a relevant link for the schematic diagram. Glad to be of help!

1 person found this instruction helpful.

Was this helpful?

Additional Links:

https://partselectcom-gtcdcddbene3cpes.z01.azurefd.net/Schematics/Whirlpool...

Barbara - For model number WRS321SDHB01

March 27, 2023

I need the back bar holding bottom shelf of freezer

Hello Barbara, thank you for contacting us. The selves are supported and moved on track, part number PS11768812. We hope this is what you were looking for!

$66.77

TRACK

Was this helpful?

Barbara - For model number WRS321SDHB01

March 28, 2023

What I’m asking about is the freezer bottom SHELF that is above the freezer drawer. I need the back bar that holds the shelf up Model # WRS321SDHB01

Hi Barbara, thank you for contacting us again. The shelf support, part number PS11748719, holds and supports the shelves. We hope this helps!

$21.45

Refrigerator Shelf Mounting Cup

Was this helpful?

Christina - For model number WRS321SDHB01

June 28, 2024

White latch has come off the water filter door. Tried to reattach, but then the water filter can’t fit in. Is there a part that I’m missing that may be missing and have fallen off when the door popped off?

Hello Christina, thanks for your question. The water filter door appears to be part of the water filter housing assembly and is not sold separately. The white housing is PS12347901, black is PS12348209, and gray is PS12347902. If your filter is not fitting properly or the door isn't closing, this part may need to be replaced. If you would like assistance placing an order, please contact customer service. Good luck with your repair!

$101.79

Water Filter Housing - White

$101.79

Water Filter Housing - Grey

$101.79

Water Filter Housing - Black

Was this helpful?

Common Symptoms of the WRS321SDHB01

How this model fails, and the parts that fix it.

Light not working

Ice maker won’t dispense ice

Leaking

Ice maker not making ice

Door won’t open or close

Fridge and Freezer are too warm

Ice maker dispenses too little ice
