RGB745DEP3WH Hotpoint Range - Overview

Sections of the RGB745DEP3WH

[Viewing 4 of 4]

Manuals & Care Guides for RGB745DEP3WH

Click to download
Keep searches simple, eg. "belt" or "pump".
Flat Style Oven Igniter Kit – Part Number: WB13K21
Flat Style Oven Igniter Kit
★★★★★
★★★★★
(112)
PartSelect #: PS231280
Manufacturer #: WB13K21
The flat style oven igniter kit comes with a mounting bracket and a wire connector with a plug. The igniter kit is used to light the oven burner. If you notice that your oven will not heat up properly...
$56.65
  In Stock
Light Bulb - 40W – Part Number: 40A15
Light Bulb - 40W
★★★★★
★★★★★
(8)
PartSelect #: PS217532
Manufacturer #: 40A15
This 40-Watt light bulb is sold individually and is a genuine OEM replacement option for your home appliances. It is specially designed to withstand extreme temperatures, so this bulb is compatible wi...
$11.01
  In Stock
Oven Rack – Part Number: WB48T10095
Oven Rack
★★★★★
★★★★★
(17)
PartSelect #: PS6447646
Manufacturer #: WB48T10095
The oven rack is sold individually. It is chrome in color and measures approximately 24 inches wide by 17-1/2 inches deep. The rack is used to hold cookware in the oven and slides back and forth for e...
$67.36
  In Stock
Burner Head - Medium - 9500 – Part Number: WB16K10055
Burner Head - Medium - 9500
★★★★★
★★★★★
(9)
PartSelect #: PS1020327
Manufacturer #: WB16K10055
This burner head, or surface burner, is used in ranges and ovens. The burner sends gas through the holes and slots to create an equal flame across the cooking area. If the gas igniter glows but will n...
$39.74
  In Stock
Grate – Part Number: WB31K10016
Grate
★★★★★
★★★★★
(7)
PartSelect #: PS244182
Manufacturer #: WB31K10016
Sold individually. Must order quantity needed.
$43.83
  In Stock
Burner Head - Large - 12K – Part Number: WB16T10046
Burner Head - Large - 12K
★★★★★
★★★★★
(14)
PartSelect #: PS1480992
Manufacturer #: WB16T10046
This part is the replacement surface burner head for your gas range. It is silver in color and is approximately 3.5 inches in diameter. This burner is sold individually. The burner head distributes ga...
$39.01
  In Stock
Drawer Support – Part Number: WB02K10158
Drawer Support
★★★★★
★★★★★
(5)
PartSelect #: PS2320972
Manufacturer #: WB02K10158
This is a replacement drawer support for your oven. The drawer support provides stability to the drawer unit as it opens and closes. If your oven drawer is hanging or will not slide in or out efficien...
$11.06
  In Stock
Small Burner - 5K – Part Number: WB16K10070
Small Burner - 5K
★★★★★
★★★★★
(8)
PartSelect #: PS3486550
Manufacturer #: WB16K10070
Sold individually.
$39.76
  In Stock
Ignitor Mounting Screw – Part Number: WB1X1293
Ignitor Mounting Screw
★★★★★
★★★★★
(2)
PartSelect #: PS234519
Manufacturer #: WB1X1293
Sold Individually.
$9.63
  In Stock
Top Electrode Mounting Clip – Part Number: WB01K10112
Top Electrode Mounting Clip
PartSelect #: PS3510420
Manufacturer #: WB01K10112
Sold individually.
$13.70
  In Stock
RECEPTACLE PUSH-IN – Part Number: WB08T10026
RECEPTACLE PUSH-IN
★★★★★
★★★★★
(7)
PartSelect #: PS752188
Manufacturer #: WB08T10026
This part is the replacement light socket for your oven. The oven light socket provides power to the light, and at the same time holds the light bulb in place.
$8.54
  In Stock
Left Front Orifice – Part Number: WB28K10190
Left Front Orifice
★★★★★
★★★★★
(7)
PartSelect #: PS954084
Manufacturer #: WB28K10190
This is the replacement left front orifice for your gas range. When your range is operating, gas flows through the orifice to the igniter. This part is the orifice itself as well as the metal holder t...
$24.86
  In Stock

Questions And Answers for RGB745DEP3WH

Ask our experts a question about this model and we'll get back to you as soon as possible!

2 questions answered by our experts.
Sort by:
  • 1
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Jenny
December 21, 2022
My oven is not getting hot??
For model number RGB745DEP3WH
PartSelect logo
Hi Jenny, thank you for reaching out. If your oven is not getting hot, we suggest that you check the oven igniter, part number PS231280 and the temperature sensor, part number PS2374070. If you require assistance to place an order, please contact customer service. We hope that helps!

Was this helpful?
Thank you for voting!
Related Parts:
Cheryl
August 15, 2023
What all is needed to convert this model from natural gas to propane?
For model number RGB745DEP3WH
PartSelect logo
Hi Cheryl, thank you for your inquiry. You will need the LP conversion kit, part number PS2345630, to convert from natural gas to propane. We hope that helps!

Was this helpful?
Thank you for voting!
Related Parts:
  • 1

Common Symptoms of the RGB745DEP3WH

[Viewing 10 of 10]
Gas igniter glows, but will not light
Fixed by
these parts
Fixing Fixing Fixing
Show All
Little to no heat when baking
Fixed by
these parts
Fixing Fixing Fixing
Show All
Will Not Start
Fixed by
these parts
Fixing Fixing Fixing
Show All
Element will not heat
Fixed by
these parts
Fixing Fixing
Show All
Oven not heating evenly
Fixed by
these parts
Fixing Fixing Fixing
Show All
Gas smell
Fixed by
these parts
Fixing Fixing Fixing
Show All
Door won’t close
Fixed by
these parts
Fixing Fixing Fixing
Show All
Touchpad does not respond
Fixed by
these parts
Fixing
Show All
Little to no heat when broiling
Fixed by
these parts
Fixing
Show All
Will not program
Fixed by
these parts
Fixing
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
The igniter glowed, but never got hot enough to ignite the propane, so I did smell propane.
First, I removed the two screws that held the heat shield in place. Second, I removed the one screw that held a small wire covering. That covering kept the wires inside the back wall of the range. Third, I removed the two screws that held the Igniter Kit, and unplugged it from the back of the range. I then carefully put the new igniter in, and reassembled everything in reverse order. It only took about 30 minutes to do the repair, and 30 minutes of cleaning and wiping of the broiler area. (It is amazing what you see when you take things apart). I should have been wiping things up over the past few months. Overall, a very easy repair. I ordered the part at 12:30 in the afternoon, and FedEx delivered it the next morning at 11:30, all for the regular shipping price of $6.95. VERY HAPPY.....
Parts Used:
Flat Style Oven Igniter Kit
  • Sidney from Marysville, CA
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Nutdriver
673 of 720 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
oven would not light or keep temp.
first I thought it was a faulty gas valve, so I pulled it out, started researching for a replacement part, found your site and started research. I discovered thhat the igniter was the culprit, that info. saved me about a week of time and a 100 bucks, so I installed the gas safety valve back in the oven, patience is the word for the day, you cross thread this and you are done! any way ordered ignighter and it shipped to my house in about 4 days, New York to Calif. had it installed in about 15 minutes fired off the oven and ...IT worked hurray...10-9-2010,
Parts Used:
Flat Style Oven Igniter Kit
  • zack from corning, CA
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver, Screw drivers, Socket set, Wrench set
448 of 461 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Oven wouldn't heat. This degraded over several weeks.
1. Pulled the 110V power plug. It was not necessary to turn off the gas; just be careful not to stretch or pinch the flexhose behind the stove.
2. Removed the oven door by opening a couple of inches then lifting upward.
3. Removed the warming drawer by pulling out to the stop, then pushing the small levers on the side of the track to release.
4. Removed two flathead screws at the back of the oven to free up the oven bottom panel.
5. Removed the bottom panel by lifting up the pack until the front edge clears the overhang.
6. Removed the two screws on the side that hold the igniter to the burner tube. Be sure not to let the screws drop into the gaps in the oven floor. Note the position of the bent tab with the holes to ease aligning the new part.
7. Reached through the warming drawer to release the plug by squeezing the tabs on the end.
8. Pulled the plug up through the gap in the oven floor (where the wires went through) and connected it to the other connector.
9. Ran the new wire down through the oven floor.
10. Aligned the new igniter and tightened them. Had trouble getting the screws started so I used a toothpick to align one hole while starting the other screw.
11. Replaced the oven bottom panel. It needed a little jockeying to get the screws and holes aligned.
12. Replaced the door.
13. Replaced the oven drawer.

This turned out to be a good time to clean all those dusty places that don't get cleaned that often.
Parts Used:
Flat Style Oven Igniter Kit
  • Durwood from Suffield, CT
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver, Screw drivers
307 of 403 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
