LFX28978ST (02) LG Refrigerator - Overview

Diagrams for LFX28978ST

See every part. Know exactly what you need.

Parts for the LFX28978ST

$24.67

Refrigerator Door Switch

★★★★★

(98)

Part #6600JB1010A

The interior light in your refrigerator is controlled by a switch that is activated when the door is opened and closed. If your refrigerator light will not turn on, or stays on when the door is closed, you could have a faulty switch. The switch is spring-loaded and is a generally closed type of switch meaning there should be no continuity...Read more

Read less

$46.34

Door Bin - White/Clear

★★★★★

(39)

Part #AAP73631501

This bin is white in color with a clear front insert. Sold individually.

$72.73

Refrigerator Water Filter LT700P

★★★★★

(22)

Part #AGF80300702

This refrigerator water filter replacement is for 2010 LG refrigerators that have either forward French doors or are the four-door dispensing models. This filter is designed to minimize impurities that can cause ill-tasting water or an unpleasant smell. It reduces sediment, dirt, rust, limescale, sand, and many other contaminants that can...Read more

Read less

$15.00

Mullion Spring

★★★★★

(50)

Part #MHY62044103

This spring is located on the mullion, or door flap, of your fridge. This spring is sourced from the genuine OEM manufacturer for various refrigerator models. It measures about 1.5 inches in total length, and is made entirely out of metal.

$164.47

Refrigerator Front Plate Assembly

★★★★★

(102)

Part #AGU75188619

This front plate assembly, also known as a mullion or flipper, is a genuine replacement part designed for select LG and Kenmore French-door refrigerators. It serves a critical function by sealing the gap between the doors, preventing cold air from escaping and helping maintain consistent internal temperatures. Constructed from durable pla...Read more

Read less

$18.22

Plastic Tube - 5/16 Inch

★★★★★

(24)

Part #MJU62070602

This water tube, or plastic tube, is used in refrigerators and freezers. The tube ensures water is directed to parts of the refrigerator that need it, such as the water dispenser and ice maker. If you find that your current one is leaking or broken in any way, replacing the tube can fix this problem. Make sure to unplug the appliance from...Read more

Read less

$15.00

Handle Screw

★★★★★

(8)

Part #MJB63190001

This handle screw, also known as a mounting bolt, is a mounting screw to help secure the door handle to your refrigerator door. If your handle is loose, you may just need to tighten the screw. If your screw is missing or broken, it may need to be replaced. There are multiple handle screws on your fridge, please consider ordering extra as ...Read more

Read less

$56.33

Door Gasket - Gray - Right Side

★★★★★

(41)

Part #ADX73550624

This door gasket is used to make an air-tight seal for the cabinet when the door is closed

$23.60

Roller Assembly

★★★★★

(11)

Part #AHJ72909001

This is a drawer roller for the freezer compartment of your LG refrigerator. This roller is made of white plastic, and acts as a wheel to allow the drawer to glide smoothly back and forth when you open and close the freezer compartment. Over time and with further frequent use, this roller can crack, break, or stop rolling smoothly, at whi...Read more

Read less

$51.61

Glass Shelf

★★★★★

(26)

Part #MHL62691504

This is the replacement shelf glass for your refrigerator. It is made of glass and is approximately 31 inches wide and 16 inches long. The shelf glass for your refrigerator slides over the crisper cover and acts as a sort of lid. It also creates a shelf that you can place food and beverages on. If your current shelf insert glass is broken...Read more

Read less

$122.57

Water Inlet Valve Assembly

★★★★★

(16)

Part #AJU72992601

This includes the primary and secondary valves along with the wire harness.

Bottom Door Bin

★★★★★

(4)

Part #AAP72909204

The door bin is attached to the inside of the refrigerator door, and typically holds condiments, jars, and bottles. This OEM basket assembly is made of white and clear plastic. Measures approximately 16 inches long x 4 1/2 inches high x 5 inches deep. These parts should fit tightly to the door of your refrigerator, if yours is loose you ...Read more

Read less

Questions And Answers for LFX28978ST

Ask our experts a question about this model and we'll get back to you as soon as possible!

Sort by:

Joseph - For model number LFX28978ST

April 25, 2022

I removed the old water filter, install a new water filter back in, pushed firmly to make sure the filter was seated, and the filter will not pivot back up. I tried to reinstall the old filter and it will not pivot up either.

Hello Joseph, thank you for your inquiry. For the Water filter PS12724833, we hope our instructions will help you. To remove your unwanted filter, press the push button to open the filter cover (water may spill from the hole), pull out the old cartridge in a downward motion. To install the new filter, make it so the ears are in the horizontal position and push the new cartridge into the housing until it stops. Push the filter upward until it is secure. Click the cover to lock it in place. If you need help placing an order, customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you.

$72.73

Refrigerator Water Filter LT700P

Was this helpful?

John - For model number LFX28978ST

May 25, 2022

Seems like refrigerator is running constantly day and night. Been told by a couple of repairman that Choice Home Warranty that this is NORMAL, which I don't believe!

Hello John, Thank you for the question. No it is not normal. Depending on how frequently the refrigerator door is opened, the compressor should cycle four or five times a day. We suggest cleaning the coils at the back of the appliance and around the compressor. We hope this helps, good luck with this repair!

Was this helpful?

Paul - For model number LFX28978ST

November 1, 2024

Need freezer gasket in gray

Hello Paul, Thank you for writing in. Our research has found, part number PS8752589 should be what you are looking for. We hope this helps.

$73.04

Freezer Door Gasket - Gray

Was this helpful?

Common Symptoms of the LFX28978ST

How this model fails, and the parts that fix it.

Door won’t open or close

Fixed by
these parts

Show All

Leaking

Fixed by
these parts

Ice maker won’t dispense ice

Fixed by
these parts

Show All

Ice maker not making ice

Fridge and Freezer are too warm

Fixed by
these parts

Show All

Videos related to models starting with LFX28978ST

Watch our pros, then fix it yourself.

Replacing the Refrigerator Front Plate Assembly

Replacing the Water Inlet Valve Assembly

Replacing the Thermistor Assembly

Repair Tips From Fixers Like You

See how others fixed this model. Time, tools, difficulty, and steps that lead to victory! View More

replace leaking water inlet valve assembly

42 of 75 people found this instruction helpful.

Richard from JACKSONVILLE, FL
Really Easy
15 - 30 mins
Screw drivers

1. Shut off water to refrigerator. 2. Removed bottom sheet metal cover (6 screws). 3. Removed leaking water inlet valve assembly from refrigerator (1 screw). 4. Remove water inlet tube (loosen nut) and tube back to refrigerator (pull from water valve after remove cotter pin washer). 5. Detach two electrical wire harnesses. 6. Install new ... Read more

Read less

Was this helpful?

Remove and replace light switch

45 of 89 people found this instruction helpful.

Debbie from Waltham, MA
A Bit Difficult
30 - 60 mins
Pliers, Screw drivers

Video makes it look easy. Kenmore refrigerator does not have "groove" along the right hand side of switch that allows for pushing down on release. Used a thin screwdriver to get under to push while holding switch edge with pliers. Kept slipping. Tape sides to avoid scratching inside of refrigerator.

Was this helpful?

The factory door gasket was split and needed replacing

22 of 36 people found this instruction helpful.

Carl from LAKE WYLIE, SC
Very Easy
Less than 15 mins

I pulled the gasket off and installed the new one. It was very easy. All I had to do was to push the new gasket in place in the grooves in the door. The gasket I received was identical to the one I replaced.
