JCBP78SJ3SS General Electric Range - Overview

Sections of the JCBP78SJ3SS

[Viewing 5 of 5]
Keep searches simple, eg. "belt" or "pump".
Bake Element - Push On Terminals - 240V – Part Number: WB44T10011
Bake Element - Push On Terminals - 240V
★★★★★
★★★★★
(153)
PartSelect #: PS249286
Manufacturer #: WB44T10011
The bake element in your oven provides the cooking heat. This part can be found at the bottom of your oven, and attaches to the power source on the back wall. It has two terminals that fit into the po...
$88.02
  In Stock
Temperature Sensor – Part Number: WB21X22134
Temperature Sensor
★★★★★
★★★★★
(48)
PartSelect #: PS10059162
Manufacturer #: WB21X22134
The temperature sensor, also known as the oven temperature sensor assembly is usually found in the back of the oven. The function of the oven temperature sensor assembly is to measure the temperature ...
$26.89
  In Stock
Light Bulb - 40W – Part Number: 40A15
Light Bulb - 40W
★★★★★
★★★★★
(8)
PartSelect #: PS217532
Manufacturer #: 40A15
This 40-Watt light bulb is sold individually and is a genuine OEM replacement option for your home appliances. It is specially designed to withstand extreme temperatures, so this bulb is compatible wi...
$11.01
  In Stock
REAR SUPPORT – Part Number: WB02X33180
REAR SUPPORT
★★★★★
★★★★★
(20)
PartSelect #: PS12709839
Manufacturer #: WB02X33180
This rear drawer support comes with the installation screw. This part has been redesigned. The new support inserts towards the rear of the drawer as opposed to the side.
$13.03
  In Stock
CONTROL OVEN TO9 – Part Number: WB27X45466
CONTROL OVEN TO9
★★★★★
★★★★★
(53)
PartSelect #: PS16873547
Manufacturer #: WB27X45466
This part is also known as the "brains" of the appliance. ***NOTE: The wiring could be different than the original control. This part may need to be installed by an appliance repair person.
$146.89
  In Stock
Oven Rack – Part Number: WB48T10011
Oven Rack
★★★★★
★★★★★
(17)
PartSelect #: PS249581
Manufacturer #: WB48T10011
Sold individually.
$57.74
  In Stock
Broil Element – Part Number: WB44T10009
Broil Element
★★★★★
★★★★★
(25)
PartSelect #: PS249284
Manufacturer #: WB44T10009
This broil element is found on the upper part of the oven cavity.
$97.58
  In Stock
Range Surface Element Control Switch - 6 Inch - 1560 W – Part Number: WB24T10029
Range Surface Element Control Switch - 6 Inch - 1560 W
★★★★★
★★★★★
(18)
PartSelect #: PS236754
Manufacturer #: WB24T10029
This switch controls the small burner on a range/stove top.
$45.11
  In Stock
Dual Radiant Element - 9 Inch – Part Number: WB30T10099
Dual Radiant Element - 9 Inch
★★★★★
★★★★★
(13)
PartSelect #: PS1016539
Manufacturer #: WB30T10099
This is a large dual haliant element with a limiter or sensor for glass cooktops and freestanding ranges. It is a 2500-watt part. The inner diameter measures 9 inches, while the outer diameter measure...
$156.75
  In Stock
Foot - Leveller – Part Number: WB02X10521
Foot - Leveller
PartSelect #: PS223802
Manufacturer #: WB02X10521
Sold individually.
$23.43
  In Stock
RECEPTACLE PUSH-IN – Part Number: WB08T10026
RECEPTACLE PUSH-IN
★★★★★
★★★★★
(7)
PartSelect #: PS752188
Manufacturer #: WB08T10026
This part is the replacement light socket for your oven. The oven light socket provides power to the light, and at the same time holds the light bulb in place.
$8.54
  In Stock
Screw – Part Number: WH2X930
Screw
★★★★★
★★★★★
(1)
PartSelect #: PS271689
Manufacturer #: WH2X930
This screw is sold individually.
$12.21
  In Stock

Questions And Answers for JCBP78SJ3SS

Be the first to ask our experts a question about this model!

Common Symptoms of the JCBP78SJ3SS

[Viewing 10 of 10]
Little to no heat when baking
Fixed by
these parts
Fixing Fixing Fixing
Show All
Element will not heat
Fixed by
these parts
Fixing Fixing Fixing
Show All
Oven not heating evenly
Fixed by
these parts
Fixing Fixing Fixing
Show All
Little to no heat when broiling
Fixed by
these parts
Fixing Fixing
Show All
Will Not Start
Fixed by
these parts
Fixing Fixing Fixing
Show All
Touchpad does not respond
Fixed by
these parts
Fixing
Show All
Oven is too hot
Fixed by
these parts
Fixing Fixing Fixing
Show All
Door won’t close
Fixed by
these parts
Fixing Fixing Fixing
Show All
Will not program
Fixed by
these parts
Fixing
Show All
Timer will not advance
Fixed by
these parts
Fixing
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
oven element burned itself up
Turned off circuit breaker to range.
Removed the 2 oven racks. Removed two screws in back of oven compartment. Pulled element forward and the terminal connections get exposed.
The right terminal clip disconnected by itself and the wire went back into the stove and could not be retrieved.
Removed range draw under the oven and pulled entire range out from wall about 4 feet.. Removed metal backing with a socket wrench and exposed the oven element wires and terminals.
Reinstalled new element and metal backing.
Since range was out from wall, cleaned and vacuumed before pushing stove back in place.
Since range draw was out re-leveled by setting adjustable feet.
Reinstalled drawer and racks.
Turned on circuit breaker.
Tested element by setting bake cycle on.
Parts Used:
Bake Element - Push On Terminals - 240V
  • Dennis from Bondville, VT
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers, Socket set
263 of 286 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
The baking assembly in the oven burst into flames one day, then broke apart.
After the element cooled down, I pulled the racks out of the oven, turned off the oven at the breaker box, then, using a nut driver, loosened the screws that held the baking assembly in the back of the oven, and pulled the connecting wires off. I bent the wires to make sure they would stay out, because if they get back in the insulation, they are hard to find. I would recommend getting a pair of locking pliers and putting them on the ends of the wires just to keep them from getting back into the insulation. Then I attached the left connection wire and then the right one, pushed them back into the insulation, tightened the baking assembly to the back wall of the oven, turned it back on at the breaker box, then tested the oven to see if it heated up. It did. Total repair time 15 -20 minutes. Would have been less if I didn't have to chase one of the wires back in the insulation. Shamless plug for the company ...By paying extra for 2-day shipping to receive the part, I saved just over $20 from buying it at Sears, which would have had to order the part anyway.
Parts Used:
Bake Element - Push On Terminals - 240V
  • Theresa from Sherman, TX
  • Difficulty Level:
    Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver, Pliers
141 of 151 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Oven would go in to a F2 Error
Removed six 1/4" hex nuts on rear of oven. Then through front/inside removed a single 1/4" hex nut to actually remove sensor. Unplug sensor connector, remove. Reversed steps, push oven back in place and plugged in. Tested oven function.
Parts Used:
Temperature Sensor
  • Peter from stamford, CT
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver
146 of 215 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
