The tub dampening straps support the wash tub and reduce vibration by keeping the tub at the center of the cabinet. If your washer shakes and moves, or is making a loud banging noise during the wash cycle, the washing machine tub could be off-balance, meaning one or more of these straps may be loose, or broken. Other symptoms include: the...Read more washer leaking, not agitating, or pumping but not spinning. These straps are sold individually. However, we recommend that you replace all 4 straps at the same time. It is also recommended that you check the tub for cracks where these straps mount.
This clip ensures that the knob is securely fastened to the control shaft, allowing you to properly select the correct time and setting for your dryer. If your dryer will not start or shut off, the timer will not advance, or the dryer shuts off too soon, the issue may be the control knob itself. This clip is sold individually. Although th...Read moreis part fits with some different brands, be sure to check the list of brands below to make sure it fits with your dryer unit. Refer to the manual provided by the manufacturer for further installation instructions.
The drain hose is black in color and made of flexible material. This is a part for your top-load washer. The hose measures 57 inches long. This part moves the water out of the washer and into the drain. If this parts cracks or becomes damaged it will leak during the drain cycle of your wash and you may find water on the floor. To access t...Read morehe hose, you will need to move the washer away from the wall to get to the back of the appliance. There will be two screws holding it in place that will need to be removed.
This is a dual-action agitator for a washer. It is an OEM replacement part that is sourced from the manufacturer. The agitator tosses your clothes to clean them efficiently. This plastic dual-action agitator is white in color. It is approximately 18 inches tall with a base diameter of about 12 1/4 inches. No tools are required for this re...Read morepair. Your agitator has eight tabs that fasten on the drive block of your washer, which is driven by the transmission. This part does not include the agitator coupling kit, which is frequently purchased at the same time as the agitator.
The main tub seal is located between the transmission and the outer tub. Its the primary water seal in the outer tub for the transmission-shaft. If your washer is leaking during the fill cycle, or at agitation time, your tub seal may need to be replaced. You can check if the tub seal needs to be replaced by watching that area during an ac...Read moretual fill cycle. Take off the front panel, or if it is a front-loading washer, the rear panel. Without touching the washing machine, observe the place where the shaft of the transmission comes into the tub and the weep holes at the housing of the rear bearing. If there is water leaking, the tub seal is at fault.
NOTE: This seal is difficult to replace and should probably be installed by a qualified technician.
This knob accepts a D shaped shaft. Sold individually. This control knob is for dryers.
Control knob lets you control cycle settings.
Remove the knob by pulling it straight off its post.
This is a tub bearing and it is meant to work in conjunction with your washing machine. The purpose of this part is to aid in keeping the inner tub of your washing machine spinning smoothly during a wash cycle. The most common reasons for needing to change your tub bearing is if your appliance is noisy or shaking/moving during the wash cy...Read morecle, another common symptom is leaking water. This part is sold individually and measures to have an inner diameter of roughly 1 inch, and an outer diameter of roughly 2 inches.
This split ring is supplied by the original equipment manufacturer, and it is designed to secure the tub bearing in washing machines. It is a circular metal ring, with an outer diameter of 2 inches. The ring has a split or gap, which allows it to expand and contract for easy installation and removal. It is typically located on the inner s...Read moreide of the washing machine outer tub, where it provides stability and prevents the washer from excessively shaking during use. It is normal for the split ring to become worn, corroded, or damaged due to age, exposure to moisture, and excessive stress. A faulty split ring will lead to a noisy, unstable washer and eventually cause the tub assembly to fall out of alignment. Remove the washer panels to access the outer tub and split ring. Carefully detach the damaged split ring from the tub and position the new split ring in its place. Ensure that it is properly aligned and securely fastened before reattaching the panels.
This tub bearing goes in your washing machine. You will find it on the bottom of the outer tub, where the transmission goes through the tub. If you hear metal on metal when the washer is spinning, you may need to replace the tub bearing. This bearing is made of metal, and is approximately 3 inches wide and 2 inches tall.
Ask our experts a question about this model and we'll get back to you as soon as possible!
We may have answered a similar question already! Search questions and answers left by others using simple keywords like "fit", "broken", "easy", or "quality" to find questions that match.
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Sort by:
Prev
1
2
Next
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Nancy - For model number GLWN2800D1WS
February 14, 2023
The rinse cycle is only filling with a small amount of water. Then it starts to agitate. The wash cycle works fine.
Hello Nancy, thank you for reaching out. The problem seems to be with the Pressure Switch and you may need to replace it, the part number is PS3487295. The Pressure Switch senses and controls the water level in the washer. If that does not take care of the issue, we would suggest checking the Water Fill Nozzle, part number PS756806, and Water Inlet Valve, part number PS11721803. We hope this sorts out your problem!
I think one stabilizer is broken. It isn't level.
Thank you.
Hello Linda, thank you for contacting us. You may need to replace the leveling leg, part number PS271500, to fix the issue. We have attached a relevant video that will help you in replacing leveling legs. We hope this solves your problem!
Hi Diana, thank you for reaching out. We have concluded that the issue is with the lid switch assembly, part number PS1482372. You may also need to replace the water inlet valve, part number PS11721803. We hope this helps!
When the washing machine is in spin cycle it is extremely loud and sounds like it will explode. This started happening less than 2 months ago but is LOUD.
Hello Kelli, thank you for reaching out. Based on the description that you have provided, we would recommend checking the tub bearing, part number PS271510, to fix the issue. We hope this helps!
what part do i need? Tub overflows only when on hot water and large or above water level.
Hi Ingrid, thank you for the question. We have concluded that the issue is probably with the water inlet valve, part number PS11721803. It controls the water flow into the washer. You may need to replace the inlet valve to fix the issue. Good luck with your repair!
See how others fixed this model. Time, tools, difficulty, and steps that lead to victory!View More
Search repair tips from other customers using simple keywords like "replace", "fit", "remove", "inspect". DIY doesn't mean you have to do it alone!
Search filter:
Clear Filter
Your search term must have 3 or more characters.
washing machine would not go through all cycles or agitate
230 of 294 peoplefound this instruction helpful.
Brian from Millerplace, NY
Easy
15 - 30 mins
After removing frt panel which prys off I checked for anything obvious like a loose belt. Then I jiggled the magnet switch located on the inside of the loading cover. I saw the machine start agitating the it stopped again when I stopped touching it. I ordered the new part and spliced it in with the wire crip tool. Now the machine is A ok.
Was this helpful?
Thank you for voting!
broken drive belt
96 of 120 peoplefound this instruction helpful.
jon from barry, IL
A Bit Difficult
15 - 30 mins
Nutdriver
To diagnose, first I unhooked the washer: power, water supply, and drain pipe. I then slid the washer out, laying it on its front. With nutdriver, I unscrewed two screws that held the other end of the drain tube and removed it completely. Then, again with the nutdriver removed 4 screws from the back near the legs, two in between the leg
... Read mores in the middle, and approx. 4 to 6 on the bottom. This let me pull the bottom off partially to access the motor area. (I did did not take the bottom completely off, only about 2/3 off and let it bend over, as it was flexible tin) The belt was broken. After receiving the new belt, I positioned it between the pulley and the motor and between the drum and the big pulley. Then I rotated the big pulley, pulling the belt onto it as I rotated. At the same time, as I rotated, I pulled the other end of the belt on to the little pulley. Once it was on, I would put pressure on it as I turned the pulley, to jump the belt to the appropriate grooves on the little pulley. Note: the replacement belt had been modified, so it had one less groove than the pulley. I would have known this if I had read the insert that came with the belt first! Anyway, this was not a problem, only a design change. Also it was important to start the belt on the inside, so if it slipped, you didnt loose your bite. Total diagnostic, repair, and reassembly time: 30 minutes plus or minus. I had read other online forums that said you had to loosen the motor, etc. And I do know some type of a belt installation tool was offered on line, but I got along fine with my installation method. An extra set of hands would have been helpful, but not necessary.
Read less
Was this helpful?
Thank you for voting!
Blades broken off agitator
73 of 90 peoplefound this instruction helpful.
Michael from Itasca, IL
Really Easy
Less than 15 mins
Simply put hands, one under each side of the agitaror and pulled up. The part snapped off very easily. I then placed the new part in the tub and pressed down. Extremely easy, should have done it sooner!
