PartSelect Number PS2058491
This part works with the following brands: Whirlpool, Admiral, Estate, Inglis, Kenmore, KitchenAid, Roper, Maytag, Crosley, Jenn-Air, Hardwick, Magic Chef, Amana, Caloric & Glenwood.
I removed the back lower panel within the freezer compartment. The cooling fan which draws cold air from the evaporator unit was functioning fine. I then unplugged the unit.The evaporator unit was frozen in a block of ice. I removed all food contents from both the freezer and the refrigerator, moving them to a back-up refrigerator. I then allowed the radiator to thaw completely overnight. Upon restarting the unit it became cold within an hour thus I new the compressor was fine. I surmised it must be a defrost issue. I then unconnected the defrost heater and thermostat assembly. The device was easy to remove. I then routed the wire of the new assembly on the side of the evaporator unit and clipped the thermostat back onto the cooper feed, plugged the unit into the connection. Next I turned my attention to replacing the adaptive defrost timer. In the top of the refrigerator compartment, I removed the plastic shroud, by sliding back and pushing the plastic clips in. I took out 4 screws holding the unit to the ceiling of the refrigerator. Slowly lowering this, I could see the adaptive defrost timer in the right rear corner. I simply unplugged the unit and replaced with a new unit. I replaced both items although I am unsure which was not working. Refrigerator is working fine now.
Help other customers find the most helpful instructions.
Were these instructions helpful?
Replaced the pins.
Followed advice from online forums and replaced the adaptive defrost timer. Simple unplug/plug of a circuit board buried in ceiling of fresh food compartment. Once it was replaced waited a couple of days to ensure defrost heater was turning on, success was the result. Used the little plastic parts ordered to replace lost parts. This time I glued them in with epoxy so they would not pop off in the future. Overall an extremely simple repair, I am happy that our Maytag offers streamlined troubleshooting!
