PartSelect Number PS733947
This kit includes the module motor, ejector arm, and ice stripper arm. The complete icemaker is sold separately.
This part works with the following brands: Whirlpool, Admiral, Estate, Inglis, Kenmore, KitchenAid, Roper, Maytag, Crosley, Jenn-Air, Hardwick, Magic Chef, Amana, Caloric & Glenwood.
This part fixes the following symptoms:
This icemaker can be used with 25-27 cubic feet refrigerators that have a vertical auger dispenser located on the freezer door. Reuse bottom bracket from the original icemaker and attach to the new.
Changing the KITCHENAID MOTOR ASSEMBLY TO THE ICE-MAKER was fairly straightforward. The hardest part was figuring out WHAT was broken and how to fix it. I was determined to save myself hundreds of dollars by doing it myself and avoiding a visit by the 'repairman'. 1.) Went to KitchenAid website to look at Parts List for my side-by-side refrigerator and ice maker assembly (a PDF file, easily downloadable) . The illustrations helped me visualize the assembly and various parts involved. 2.) Removed cover on front of ice maker.3.) Removed hex-head screw on undersurface of icemaker on the right, which stablilizes a plastic cover for the electrical connector to the ice maker. Once this is off, it's then possible to slide the ice maker out.4.) Slide the ice maker out from it's 'shelf' in the freezer. You won't be able to completely remove it until you disconnect the power supply. 5.) Disconnect the multi-pin power connector. (It's probably safest to unplug the refrigerator altogether before doing this, but I did not. No exposed metal wiring or connectors. No problems when I did it this way.)6.) Once the ice-maker was out, remove the white cover from the motor assembly (on the left side of the unit). 7.) Remove the three screws from the black housing of the motor assembly. (This is where I discovered that the connector between the motor and drive-train was broken and needed to be replaced.)8.) Remove and replace the drive system for the ice cube ejector. 9.) Then reverse the steps to reassemble. This may seem a bit vague, but it's really quite straightforward once the ice maker is out of the freezer. The replacement motor assembly includes the motor, the motor housing, the drive-train, and the ice-cube ejector. Very easy to re-asemble.Shopping for and ordering the part took some time since there are so many different after-market parts dealers. In all honesty, I'm glad I decided on PartSelect.com. They had a decent price, safe checkout, and timely delivery. All the essentials of a good online store.Thanks, and good luck to the next guy who has to deal with a KitchenAid snafu.
Help other customers find the most helpful instructions.
Were these instructions helpful?
First I removed the icemaker from the freezer by removing two horizontal screws holding it to the side wall, and one vertical screw holding the front to a bracket coming off the side wall. Then I used a flat screwdriver to unlock the electrical plug. (After doing this, I realized that this wasn't necessary at all, and this part could have been changed just as easily without removing the icemaker.) On the front, there is a white cover with Ice Maker Plus. Use a flat screwdriver to unlock the tangs and remove the cover. There are three screws in the corners that once removed, will allow the motor assy. to be gently pulled straight out. On the back of the part, you will see many gold lands that the timer touches. I don't think there was anything wrong with my motor. I had two spots where the gold plating was worn off, so I suspect it was not making contact, and the whole process would stop. Slide the new part in place making sure the teeth on the gears line up (not a big deal), and secure with the screws. Install cover and you're done. Mine has been making ice like it was brand new.
Removed the icemaker to see if I could determine problem; motor was seized; got part numbers and ordered from you; parts arrived next day (even though overnight delivery wasnt' requested - so THANK YOU!); compared new parts to original to be sure of fit; reassembled unit; reinstalled in freezer, and waited for the sound of water filling the tray. Producing like brand new again! Cancelled the service call w/ Sears for the following week (when it was convenient for them) Loved your service!
Removed the three motor screws pulled off old motor put new motor in place replaced screws and re-installed. It was producing ice three hours later. I originally tried to obtian these parts directly from Whirlpool in which twice they shipped me the wrong parts. Finally gave up on them and entered the whilrpool part number which crossreferenced to new part number which was correct the first try. Thank you!
Repair was easy and producing ice within five hours.
After lots of internet exploring and diagnosis, the icemaker comes right out, and with three screws out and in, the job is all but done. Don't pay anyone for this repair!!!!!
Not being a professional repair tech, I looked at this sites provided schematics of the ice-maker. I assumed due to the problem I had which parts to order. the parts arrived within 3 days and after I took the icemaker apart I quickly realized I ordered the wrong parts. I called and asked what to do. since I did not open the packaging for the "wrong" parts I was able to make a return. I then called back because I discoverd the part I really needed wasn't shown in the sketch. I was told that I needed to order a new motor and it would have the part I needed. I ordered the part and within 3 days it arrived. Once I had the new part I was able to quickly install. Now I have a icemaker that works better than new since ,now it does not seem to jam either.To make the repair:First remove the 1/4" nut head screw on the under side of the ice maker.Remove the shroud covering the electrical connection.Slide out the maker and depress the locking clip.Disconect the electrical wires.Pull off the motor cover (no screws).Remove the three philips head screws from the motor housing. Gently remove the motor.Next loosen the screws and pull the "black motor-mounting harness" untill enough clearance to remove the ejector arm and deflector tray. The new kit will have a new ejector arm and deflector tray. Insallation is the reverse.The schematics were very helpfull.It was very simple and I saved a $150 service fee to have someone else do it for me. PS. When I called I was able to speak to real live Americans who were able to help me, were pleasant, polite, and professional, AND they did not treat me like I was stupid because I am not a professional repair man. I will definately use this service again. and recommend to all my DIY friends!!
The troubleshooting time takes about 20 to 30 minutes. After checking out the solenoid (valve water), the water line, and the electronic board (emitter/receiver) are working fine. The only thing left is the ice module. I called Partselect and talked to a sale rep to make sure I get the right part, and the lady was so helpful by sendind the picture of the part so I can review before ordering it. I received the part in 3 days ( normal shipping) and did the folowings:1) Unplugged the power cord from refrigerator.2) Removed the ice module by removed a 1/4" screw from under the right side of the icemaker that retains the icemaker and a “U” plastic clamp and then pull out the whole unit it from the track.3) Unplugged the cable connected to the ice maker.4) Using the phillips screw driver to remove the 3 screws. Carefully pulled out the ice module and installed the new ice module.5) Put the ice maker back to the freezer, plug the cable back to the ice maker and put the clamp and tighten the nut.6) Plugged the power cable back to the wall.The first ice I got in an hour and a full bucket of ice in less than 24 hours. I spent less than $80 for the whole thing. Thank you so much Partselect for the great service and the stories posted, it really helped me to get it done.
Unlug refrig or turn off refrig from its control panel On/OFF switch.For ease of work remove freezer shelve directly below the ice maker. Remove four screws from the bottom of the ice maker assembly, three that secure the ice maker and the other that holds a plastice shroud in place over the ice maker's power plug.The ice maker is now ready to be removed; it will slide forward by pushing up on left and right side of the ice maker's mounting slide rails. Once the ice maker is moved forward it is easier to disconnect its power plug (depress a locking tab on the side of the connector and pull connector apart and remove ice maker assembly.Remove and replace motor module by removing three screws and and replace with new unit. Reverse ice maker removal proceure for installation. Once installation is completed turn on Power to Refrig, Ice making should begin after a few hours.
Contacted sears home service to perform repair. Quote for repair was $307. 43. ( $196. 90 For labor ,$102. 58 For part) plus $75. 00 For service call. Based on the charge, I refused the repair and ordered the appropriate part from "part select" (733947) (wpl 8201515) motor module for a cost of $81. 84. To my surprise, the part arrived the next day and in 15 minutes the icemaker was in a position to make ice, and has been producing ice ever since. To perform the module replacement, I had to remove one screw with a nutdriver, pull the icemaker out, disconnect a wire harness, replace the module and do the reverse procedure to complete the installation. I saved a total of $225. 59 By doing this repair myself. A lesson learned. . . . . I will always investigate doing a repair myself with the help from the people at part select. Very professional and they sent the correct part the first time.
Repair was replacing motor kit. I did not use the plastic parts - ejector arm and separator. Went same as others described. I had removed ice maker from refrigerator although this was not necessary to replace motor unit(Please unplug refrigerator whether or not you remove the entire ice maker). Removed three screws, removed old motor unit, inserted new unit making sure the ice level wire arm end was in slot. Ejector is D shaped so can't go in wrong. Replaced screws and replaced ice maker in freezer. Note - be sure the water tube is in the trough before trying to refasten ice maker. Added note: If for whatever reason you need to remove ice maker note that there are three mounting screws (others have mentioned this) Completely remove one under middle of ice maker. For the two at top of ice maker - just loosen a few turns. The ice maker can be lifted and pulled away from the wall without removing these screws. Also there is a tab on the electrical wire connector for ice maker at back wall of freezer. Tab must be depressed with a flat tip screw driver while pulling out to remove wire connector. Tab is on wide side of connector facing inside of freezer. Repair worked. Have lots of ice again.
Open the refirigerator door and push and hold the On/Off button at the top to turn off internal power. Open the freezer door and move the icemaker switch on the right side freezer wall to "off".To get access to the icemaker, first remove a hinged plastic door that mounts to the ceiling of the freezer compartment by two hex screws. Remove the screws and the door so you can work with the icemaker without interference.The icemaker assembly will slide out once the wireharness has been disconnected. To disconnet the wire harness, a while plastic shield has to be removed from the right side of the icemaker, just behind the water inlet.Locate a hex screw on the bottom right rear of the icemaker and remove it with a socket wrench. Then the plastic cover can be pulled off. Slide the icemaker out enough so you can get your fingers on the plug connector. It takes some effort to pull the plug connectors apart. Once unplugged the whole icemaker assembly can be removed.The motor module is located on the left side and is protected by a white cover. This cover is not attached so it can be pulled off to reveal the motor module.Remove 3 screws from the outside of the motor module and the module can be pulled out of the housing. Insert the new motor module. The module turns the shaft of the ice srapper arm. the shaft has a D shape which mates with the hole in the motor module so you may have to roatate the scrapper arm until the shaft shape matches up with the hole shape in the motor module.Once the motor module is seated, replace the 3 screws and push the white cover back on.Position the icemaker so you can reconnect the wireharness plug connectors. Once connected you can push the icemaker asembly back into the grooves of shelf rail. Reattach the while protector shield which covers up the wire harness plugs.Open the refirigerator door and push and hold the power button to turn internal power back on. Move the icemaker switch on the right wall of the freezer to the "on" position and close the door.The icemaker should start making ice within 2 hours.
Originally I took the module off and found that a small plastic part had broken. Both pieces were still there, so I super glued them together and reassembled the unit. It worked great for a couple months. I realized it needed a more permanent fix, so I found the model # and looked up the part. That was very easy on your website. I ordered the part expecting it to take 4-7 days. It was at my house in two days! 15 minutes later I was makin' ice, and makin' my wife happy. Thank you for an all around great experience. I'll definitely buy from you again.
Unplug power to refridg/freezer. Removed the screw in rt. rear bottom of ice maker to remove. After removing slightly, unplug pigtail. Remove ice maker completely. Remove large square cover from left side to expose motor. Remove screws to remove motor. Replce with new. Replace ice maker to freezer, plug pigtail back in, put screw back in rt rear bottom, plug refridg/freezer back into power source. Ice was making in about 2 1/2 hours.
First I unplugged the unit, then I popped off the cover to the icemaker electronics. Removed 4 screws, pulled out the broken electronic panel, and replaced with the new one. Returned the screws and cover. The next moring the ice bin was full.This must have saved me $300, and the inconvernience of waiting around for the repair man. He would have made two trips since he would never have had this part with him.
