Lower Front Felt Seal with Adhesive 5303937183

Followed instructions for removal and installation.

Took the top dryer cabinet apart to replace all the above parts plus the dryer belt. Because of its age decide to replace all the parts from the above list.
Three major problems: none of the video reviews showed this type of dryer. Some parts were practically impossible to get back together. Difficult getting the top square. The top of the cabinet picture did not indicate how the top was to be installed.
After 23 hours finally got it back together. Then it would not start. Discovered a wire had come loose. The dryer works fine now.

Followed directions of another website...had to replace ball and socket joint that attached the drum to the back frame of the dryer...removed top outside metal cover of dryer to facilitate attaching ball/socket kit to the drum...this allowed us to secure the ball/socket kit to the drum without cross threading the screws...with the top of dryer removed this allows you to lift the drum to fit into the plastic bracket...dryer had been in use for over ten years before repair...extreme amount of lint debris throughout internal area of dryer...lint was everywhere...spent a large amount of time vacuuming lint...duct connection from lint trap to lint fan/impeller was very loose and over the years lint seeped out from connection...suggest using duct tape or wood/composite shims to hold the lint duct to the fan/impeller...make sure you remove lint from the back of drum crevice and around the area of the heating element for electric dryers...for sanity's sake this should be a two person job...for this repair we replaced the upper and lower drum felt strip, installed a complete and new ball/socket kit, replaced drum belt, and vacuumed and damp wiped the entire interior of the dryer...

Followed the video as my unit was exact model( Front Loader) Thank You for your quick ship to me here in Iowa as my repair was made in St. Louis. Parts came with in 2 days then drove to St. Louis with confidence. We purchased this set in 2003 and it is first repair on dryer. This in my rental unit. Thx

The repair requires the front panel to be removed. First remove the top by removing two screws in the back of the top panel. Once the top is removed, you have access to all of fasteners for the front panel. I removed the control panel to give myself more room. Simply remove the wire connectors on the panel and two connectors in the upper right of the cabinet. There are four screws that hold the front panel on, two on the inside about a third from the top and two more on the outside at the very bottom. Once the screws are removed, pry the front panel from the machine since there are spring clips holding the panel to the machine. Once the front panel is removed, you have access to the guides and the felts.

1) pulled Dryer out from wall and removed top panel

pulled appliance away from wall and unplugged the electrical cord and then used putty knife to pop up the top. Then removed the screws that held the front in place. Disconnected the wire to the switch on the door and then front on a rug and used acetone and scraper to remove the old glue and felt. Cleaned the area thoroughly and apply the glue that come with the kit an give it a couple of seconds to get tacky and then applied the felt and used clothes pins to hold in place for about an hour and then put back together and let it set over night before using. Had good success and it solved my problem.

I've always been a "do it yourselfer". If I can fix it, I save money. I took the dryer apart by lifting the top up like car hood. Then I removed the front panel. The front drum glide snapped into place easily where the other one had broken off. The felt strip that you sent was much shorter than the one on the dryer, so once I used the wire wheel to remove the old glue, I cut off the section of the felt that was bad and replaced it with the new felt. The turns much quieter and clothing doesnt get caught behind the drum anymore.

Previous comments on line were so helpful.

My husband and son took the dryer apart by removing the top in order to get to the drum. Part of silver rim that the Drum Glide is attached to was broken,it had been cut somehow. They had to soder it back in place so they could attach the Drum Glide and so far it's working.

Felt- I just ordered one with the adhesive and removed the damaged section used a wire brush, applied the adhesive ( which was more than enough) waited a few minutes for the adhesive to set, applied the felt, attached binder clips to hold it in place while working on the Drum Glide. Really easy.

For the glide, I want to advise people that to replace the entire glide you need to order two front drum glide parts as each is only half.

First, unplug the dryer. Then, open the top so that you can get access to the work area. On each side of the inside front, there is a screw that connects the front panel to the side panels. Unscrew those screws and pull the front panel until it disconnects from the side panels. Be careful as there are wires that are secured to the bottom of the top inside lip of the front panel. One set of wires goes to the light bulb in the dryer door. You don't need to disconnect the wires, but be sure you don't damage the wires by pulling the front panel too far away from the dryer.

Once you have the front panel out of the way, you can see the front drum glide. In my case, one half was loose as the plastic plugs that pop into recesses to hold the glide in place had broken off. Remove the damaged glide section and replace it with the new section, popping the plastic plugs into the recesses. Don't be afraid to slap the glide to lock the plugs in place.

For the felt, I cut the part of the old felt that was pulling away from the front panel. I then used a flat-head screwdriver and wire brush to remove as much of the old adhesive as I could. Then, using the high-heat adhesive that came with the new felt, I put a generous amount on the front panel where the felt needed to go. I used a toothpick to spread the adhesive to get maximum area coverage. I let it set for a minute or two, and then placed the new felt. I used small clamps to keep the felt in place until the adhesive had time to bond. I only kept the clamps in place for 10 minutes.

Once I removed the clamps, I let the felt continue to adhere to the front panel for 24 hours before reassembling the dryer. Again, be careful of the wires connected to the front panel as it appears very easy for them to be pinched or cut when putting the front panel back in place.

When the dryer was reassembled, I plugged it back in and have had no more troubles.
