429808-1-M-Frigidaire-240328404 -Upper Hinge Bearing
Part Location Diagram of 240328404 Frigidaire Upper Hinge Bearing
See part 22C in the diagram
Replacing your Frigidaire Refrigerator Upper Hinge Bearing
( Grid squares measure 1x1 inch )
429808-1-S-Frigidaire-240328404 -Upper Hinge Bearing Part Location Diagram of 240328404 Frigidaire Upper Hinge Bearing Replacing your Frigidaire Refrigerator Upper Hinge Bearing
Customer Service Representative

Get in touch, we're here to help!

Open until 12am EST

customerservice@partselect.com

Upper Hinge Bearing

★★★★★
★★★★★
1 Review

Rated by 2 customers

Really Easy

30 - 60 mins

Ratings submitted by customers like you who bought this part.

$ 28.07
  In Stock

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

PartSelect Number PS429808
Manufacturer Part Number 240328404
Manufactured by Frigidaire
Customer Service Representative

Get in touch, we're here to help!

Open until 12am EST

customerservice@partselect.com

Check if this fits your product and find model diagrams

Need help finding your model number?
Product Description

Upper Hinge Bearing Specifications

Can be used on either Fresh Food or Freezer side of the refrigerator.
How Buying OEM Parts Can Save You Time and Money

How Buying OEM Parts Can Save You Time and Money

Troubleshooting
This part fixes the following symptoms:
Clicking sound | Door won’t open or close
This part works with the following products:
Refrigerator.
This part works with the following products:
Frigidaire, Kenmore, Crosley, Electrolux.
Part# 240328404 replaces these:
AP2115813, 891006, 7240328404
Back to Top
Questions and Answers

Ask our experts a question about this part and we'll get back to you as soon as possible!

2 questions answered by our experts.
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Steve
April 25, 2018
How do you remove the upper hinge bearing from a Frigidaire refrigerator door? It has spurs on the bottom that are not accessible preventing its removal. Thanks.
PartSelect logo
Hi Steve, Thank you for your question. You have to break the rim off of the bearing and then push in the upper edges of inside your bushing. Then with a pair of pliers you just pull the part out of the door. You will have to use quite a bit of strength to pull the part out. Make sure to be careful of your wiring as well. I hope that helps. Good luck with your repair.

Was this helpful?
Thank you for voting!
Alvin
April 21, 2018
My door does not close by itself like it used to. Will this upper hinge bearing replacement solve the problem?
PartSelect logo
Hi Alvin, Thank you for your question. It could be the part you would need to change. You might also have to look at any cams you might have an your hinge itself. I hope that helps. Good luck with your repair.

Was this helpful?
Thank you for voting!
  • 1
Back to Top
Part Videos

Replacing your Frigidaire Refrigerator Upper Hinge Bearing

Replacing your Frigidaire Refrigerator Upper Hinge Bearing
Back to Top
Customer Repair Stories
 Average Repair Rating: 4.0 / 5.0, 2 reviews. What's this?
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Door had a poping sound when opening and closing
Removed the trim screw on top of the door then removed the two hinge bracket bolts. lifted the door
off placed on the table. Remove the two screws on
holding the bearing bracket on the bottom of the door.
removed the bearing and replace with the new one.
Reinstalled in reverse order.
Other Parts Used:
Hinge Bearing
  • Ivan from Mountain Home, AR
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver, Screw drivers
17 of 19 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Refridgerator door would not 'self close' anymore and made a clicking sound
-Analyzed the symptoms, consulted your website
-Found where a clicking sound could be symptomatic of the problem
-Consulted the diagrams of the refrigerator for possible parts
-Ordered the parts listed as probable problem causes
-Received parts in a few days
-Removed door as your website recommended
-Installed upper door bearing as a preventative action as it was OK.
-Installed the lower hinge bearing and door closing cam.
-Lubricated both upper and lower bearings w/ silicone grease.
-Reinstalled fridge door & tested the door closing action
-Worked like a champ and only took about 1/2 hour! Thanks!
Other Parts Used:
Door Closing Cam Hinge Bearing
  • Richard from HUMBOLDT, AZ
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Pliers, Screw drivers, Socket set
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
Back to Top
Customer Reviews
Average Rating:
★★★★★
★★★★★
1 Review
5.0
Filter By Rating:
  • 5 Stars
    1
  • 4 Stars
    0
  • 3 Stars
    0
  • 2 Stars
    0
  • 1 Star
    0
  • 1
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
★★★★★
★★★★★
Nidiana V - April 27, 2018
  Verified Purchase
Hinge
I didn't need it
