Ball Hitch 131777700

First of all, the folks at Part Select have been terrific. I balled up my address and they were great in correcting my error and getting the parts promptly to me. They provide directions with the parts. And You Tube, is a wealth of information too. The process is to remove the drum and replace the nylon busihing that supports the drum at the back of the machine. Getting it out was no sweat. Getting the drum back in was a bit more challenging single handed. If I was going to make any suggestion it would be this is a good project for two sets of hands with the second set needed for about ten minutes. The You Tube video I watched said putting the front cover with the drum attached to the back of the unit would be the challenge and they were right. Otherwise, super easy and the results are it's back to "new" condition. Thanks again to Part Select!

Watched on-line video, then applied those steps.
1. Pop the front of the deck loose using putty knife to depress clips;
2. Disconnect wires from light and door switch;
(Before I disconnected wires from door switch and light, I made wiring sketches to make sure I reconnected in original manner.)
3. Remove lint filter mount screws and mount from bottom of door opening;
4. Cut drum belt with wire-cutters and removed it;
5. Remove drum support clip from top center of front panel;
6. Remove (1) screw from each side of dryer body that hold front to sidewalls, removed front panel;
7. Remove drum by lifting the rear out of the bearing, then moving it forward through the machine front;
[While I had the dryer disassembled, I thoroughly cleaned it of lint, dirt & metal filings. The metal filings were from the worn ball hitch and drum support bearing cup. I spent as much time cleaning it out as I did working on it.]
8. Stand drum on gallon paint bucket while removing ball hitch (Use a #2 drywall phillips apex to obtain sufficient seating & torque to remove and reinstall ball hitch screws at rear of drum.);
9. Have a second person hold the new ball hitch in position while starting screws, if necessary;
10. Use nut driver w/5/16" socket to remove bearing retainer & ground ball clip;
11. Install new bearing into retainer clip, insert attachment screws through the holes in both, stick grounding ball in depression on back of bearing as screws are fed through back panel;
12. Hold ground ball clip in place to start one screw, then the other & tighten with nut driver;
13. Start drum belt on motor shaft and position against tensioner pulley;
14. Feed drum through front of machine and loop belt over rear of drum;
15. Slide belt forward on drum as drum moves to rear to keep it aligned with position of tension pulley;
16. Lift rear of drum to place ball hitch on top of bearing, then press down to seat it into bearing;
17. Turn drum to ensure belt alignment, then re-accomplish steps 6 thru 1.

Took off front panel, removed drum and replaced parts listed. A bit tricky to keep small parts in place. However, masking tape helped. Best of all was the online diagram of how the parts were assembled. In addition, taking step by step phone pixs aided in replacing parts since there was some down time between diagnosis and installation.

From previous responses on this site. I just followed their lead. If I had not found these folks, and the responses, it would have been a nightmare. It looked like and I thought the dryer came apart from the back! But in reality it comes apart from the front!! Absolutely fantastic site and help. Fast shipping, I ordered on Wednesday before Labor Day, didn't expect the parts until the following Wednesday, but received the parts on Saturday morning, and had the dryer back running by Sunday AM. Never even ran out of clean clothes!!!!!

replaced bearing and shaft new belt and everything works just fine

we removed the top of the dryer which was clipped on. then removed the front, including the door, being careful to unhook the electrical elements. then we removed the screws that attached the dryer drum to the back of the shaft. then we took the shaft out of the bracket. then we removed the plate from the back of the dryer that held the ball, the bearing and the bracket together. then we waited for parts and thanked God that the weather was fair so we could hang our clean clothes out!!! the parts came ahead of the rain so it was reverse order. then try the dryer!!!fantastic!! to qoute my kids "you rock"

This unit is a stackable washer&dryer,so first pull unit away from wall atleast 4 foot. Unplug power cord,then take10 dagree front panel off then the control panel off and unplug the 5 connetors if your unit has that many,then lay panel asside. Take dryer door off,makes it easier when putting it all back together. Now take front panel off and the dryer lent tube,now just take the 3 center phillips head screws out and slide drum out. Pull upward on what they call the shaft which held drum on. Now these are the parts you should order. Belt,grounding ball clip,grounding ball,drum support bearing,bearing bracket,and most important part is the shaft. The shaft is ur insurance for the whole job. Use a good grease like white lithium grease and coat the shaft end and the drum support bearing. The grease will cut down on friction for a while,and re assemble the way you took apart. Reminder grounding ball goes behind drum support bearing not in front. Good luck and please vaccum.

removed drum & replaced bearing, belt & shaft - reassembled

I look up on the internet on how to disassemble dryer to get to the parts needed. Took off top, found screws to take off front. Removed existing drum riding seal and lower seal. Used laquer thinner to remove excess glue. Cleaned throughly with soap and water. Reapplied new seals.

At the same time removed drum and parts in the back of the dryer for ball bearing. great, expeditious help from your store. Thank you

Took off all controls and panel. Removed the top. Pulled out the drum. Unscrewed shaft and bearing holder. Replaced all parts and started it back up.
--The parts were shipped timely,
