Timer Knob Clip

Timer Knob with Clip

Mr Dennis from Twinsburg, OH
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins

230 of 270 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

Timer on the washing machine wasn't working properly. Just spinning around not catching to set wash cycle

I found Partselect and searched for what I needed. Wasn't quite sure I had the right timer, so I called and gave them the model number and they did a search and found the right one. I ordered the part online and a few days later the parts were delivered to me. The timer fit right in and looked just like the origninal. Within 30 mins. washer was back in service.
Another washer we have on the property wasn't agitating correctly. After taking off the agitator ( by pulling straight up from the bottom ) I found that the coggs on the agitator hub were all worn out. I removed the center screw from the shaft and pulled the old hub off. Installed the new one ordered from Partselect and washwer was back up and running in no time.

Other Parts Used:

Kristina from Pasadena, CA
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Pliers, Screw drivers

60 of 65 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

knob and timer di not work

remove back screws to control panel. unplug timer. pull bad timer out. snap new timer in plug in connector. reattach screws to control panel. put knob on timer

Other Parts Used:

Timer

RICHARD from NEWARK, DE
Difficulty Level:
Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver

48 of 84 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

Timer knob broke off where the dial compression ring fits.

All I had to do was pull out the broken timer dial assembly and push in the new one.

Other Parts Used:

Timer Knob with Clip

Timer Dial

Gordon from BLUE DIAMOND, NV
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins

43 of 58 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

Gear teeth stripped out on both timer knob & timer.

Super EZ repair. The replacement parts were spot on perfect. I removed 3 screws, slid the panel off, removed a wiring harness, the reversed the procedure. I used a set of needle nose pliers to slip the locking ring on the knob, and Bob's your uncle, all done.

Other Parts Used:

Timer

William from Hillsboro, OR
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins

30 of 38 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

Teeth on Timer Knob broke off

Removed timer knob clip and installed new dial and timer knob

Other Parts Used:

Timer Knob with Clip

Clifford from Sun Valley, NV
Difficulty Level:
Easy
Total Repair Time:
Less than 15 mins
Tools:
Screw drivers

30 of 42 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

Dial Spins Too Freely

The grooves on the bottom of the control knob were worn away. I just pushed the timer knob clip off of the underside of the knob, removed it from the washer and put the new knob on and put the clip back on. It was a piece of cake!

Other Parts Used:

STEPHANIE from Bluefield, VA
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins

12 of 15 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

the control knob plastic gear was stripped

took the needle nose pliers and removed the timer knob clip from the back of the control knob. Removed the control knob and the dial with compression ring. Installed the new dial compression ring and pushed the control knob on. Note: the new control knob comes with the clip allready on the back of the control knob. Took me about 3 minutes to replace.

Other Parts Used:

David L. from London, OH
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins

12 of 18 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

Spinning Control Knob

I watched the video, used a needle nosed pliers to pull the clip off the knob and just pushed the new knob and clip on.

Other Parts Used:

Susan from Keyport, NJ
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Tools:
Pliers

12 of 20 people found this instruction helpful.

Was this instruction helpful to you?

Thank you for voting!

It appears the machine came with the wrong washer control knob.

I damaged the timer gears trying to figure out the washer control knob. I ordered all necessary parts. It now appears the knob that came on the machine had different gear hobs than the timer. I replaced the timer. The dial then easily slipped on. Then the control knob with the clip attached pushed on to the timer. I had an extra timer knob clip. It was just 93cents so I may need it later. It works better now than it did new.

Other Parts Used:

Timer
