249247-1-S-GE-WB44K5012 -Bake Element
249247-1-S-GE-WB44K5012 -Bake Element 249247-2-S-GE-WB44K5012 -Bake Element https://www.partselect.com/Schematics/GE/00010095i03.gif

Bake Element

Your Price

$37.57
In Stock
Get this part fast. Average delivery time via standard shipping: 1.8 days.

PartSelect Number PS249247
Manufacturer Part Number WB44K5012
Manufactured by GE

At the floor of your electric oven is the bake element. This partially open-style element comes with push-on terminals. The bake element will likely provide most of the heat for baking. Therefore, if the oven is not heating properly, or if food is burnt on top and undercooked below, your bake element may be at fault. If you can see that the element has been separated or blistered, you should replace the part immediately. If there is no visible damage, turn the oven on and check to see if the element heats evenly. If the element is not heating evenly, or if it is not heating at all, use a multi-meter to test for electrical continuity to see if the element needs replacing.

This part works with the following brands: Kenmore, General Electric, Hotpoint.

This part works with the following products: Range, Microwave Oven Combo.

This part fixes the following symptoms:

  • Little to no heat when baking.
  • Element will not heat.
  • Oven not heating evenly.
  • Oven is too hot.
  • Will Not Start.
  • Little to no heat when broiling.

Videos For installing this part.

Questions & Answers

Ask our experts a question on this part and we'll respond as soon as we can.

Most Recent

Question:

What is the width between the prongs that fit into the oven. My old one is three inches

Dorothy Moore for model number JSC26GP
Answer:

Hi Dorothy, Thank you for your inquiry. The bake element on our website sits on a one inch grid square. The width between the 2 prongs is approximately 2 1/2 inches. I hope this helps. Thank you and have a great day!

1 person found this helpful.

Installation Instructions Provided by PartSelect customers like you.

Average Repair Rating: 4.4 / 5.0, 152 reviews What's this?
< PREV 1 2 3 4 5 6 ... 11
1-15 of 152


595 of 600 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: 15 - 30 mins
Tools: Nutdriver
Customer: Timothy from Cordova, TN

Bake element cracked on its own

Flipped the breaker. Removed shelf, Find the right size nut socket, unscrew the two screws, pull the element out a little bit, disconnect the wires (on pretty tight), pull out element, clean out any mess in the oven, compare element with new one to make sure its the same size and such, connect wires to new element, replace screws, flip breaker back, turn on for a few minutes to make sure it works. Piece of cake.

Help other customers find the most helpful instructions.

Were these instructions helpful?

379 of 382 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Screw drivers
Customer: Sandra from Hayward, CA

Oven took 30 minutes to get to 380 degrees-no hotter

First I searched this site and read about the repairs - which made me feel like my husband could do it with ease. Then he removed two screws inside the oven, removed the broken element (didn't know it was broken til removed) and replaced the new one - just like that! The real key was being able to read how it was for other people who had already done it. That's the only reason I'm submitting my storey. Thanks

Help other customers find the most helpful instructions.

Were these instructions helpful?

201 of 268 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Screw drivers
Customer: Laura from N. Little Rock, AR

Bake element burned out

I turned off the power to the oven at the breaker. Then I removed the two screws from the old element, pulled the old element out about 3 inches and disconnected the wires from the element and installed the new one.

Help other customers find the most helpful instructions.

Were these instructions helpful?

106 of 168 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Nutdriver, Pliers
Customer: David from Nye, MT

Lower bake element broken

Removed 2 screws that hold element and pulled old element out about 2 inches to disconnect the wires from the old element. Connected the new element and remounted to rear oven wall. Very simple and saved a visit from the appliance repairman.

Help other customers find the most helpful instructions.

Were these instructions helpful?

72 of 74 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Easy
Time to do repair: 15 - 30 mins
Tools: Nutdriver, Pliers, Screw drivers
Customer: Danny from Trinity, NC

Daughter dropped dish on element......broke it!

First I removed the two screws that hold the element in place. I then pulled the element out about 3 inches and disconnected the two wires
the repeated the process to complete the installation.
Relly easy.

Help other customers find the most helpful instructions.

Were these instructions helpful?

89 of 151 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Socket set
Customer: Betty from Athelstane, WI

Bake element burnt in half

TURNED OFF CIRCUIT BREAKER. Removed nut, washer and screw, pulled out electric burner about three inches, disconnected electric terminals and removed damaged element. Inserted new element into oven, connected electric terminals, pushed electric prongs back in, screwed element to back wall of oven....DONE Easy as 123

Help other customers find the most helpful instructions.

Were these instructions helpful?

10 of 11 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Screw drivers
Customer: Tim from Mt Juliet, TN

Oven would not preheat - took over 1 hr to get to 350 degrees

Turned the range/oven off at the breaker box. Pulled all the racks out. Unscrewed two screws holding lower heating element in. Pulled the heating element out to expose connections. Unhooked connections, plugged in new element. Replaced the screws. Turned breaker back one. Pretty simple!

Help other customers find the most helpful instructions.

Were these instructions helpful?

10 of 11 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Nutdriver, Pliers
Customer: Steve from Clarksville, OH

Lower heating element out

First I removed the two screws that hold the element in place. I then pulled the element out about 3 inches and disconnected the two wires...) discovering a burnt spot in the element sent me searching for a new one. I couldn't find any locally, so I continued my search to the internet. This is when I came in contact with PartsSelect.com .
They made identifing the part and ordering so easy it was unbelievable. Super fast deliverey astounded me as well. The installation of the new element was reverse of the old. All of the dimensions and info for the part were right there on this site. Thanks

Help other customers find the most helpful instructions.

Were these instructions helpful?

8 of 9 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Nutdriver
Customer: NICHOLAS from BALTIMORE, MD

Broken oven element.

DO NOT ATTEMPT THIS REPAIR UNTIL THE RANGE IS UNPLUGGED AND THE CIRCUIT BREAKER IS OFF!!!!!!

Very easy repair, but, either there is a minor amount of current flowing through the element at all times, or the off switch wasn't working when I started. didn't turn the breaker off, after I removed the nuts, as I was pulling the element to reveal the terminals, the terminals arc'd on the oven wall. BIG SPARKS!

After I turned the breaker off and started again. No problems.

Help other customers find the most helpful instructions.

Were these instructions helpful?

8 of 9 people found this instruction helpful

Parts Used:
Level of Difficulty: Really Easy
Time to do repair: 15 - 30 mins
Tools: Nutdriver, Pliers, Screw drivers
Customer: Stanley from Sulphur, OK

Bake element bad

Inside oven, remove two screws that hold element to back wall, pull element out three or so inches to get to wire clip connections, unclip wires, remove bad element, put new element in in reverse order of taking out bad element, just that simple. Also this site was so easy to use, plus the shipping time was unbelieveably short, even a company service man couldn't have been that quick, or as reasonable. Thanks a bunch!!

Help other customers find the most helpful instructions.

Were these instructions helpful?

7 of 7 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Pliers, Socket set
Customer: Steve from Surprise, AZ

The bake element split

This was so easy I should be a repairman! Turned off power at the breaker, used socket to unscrew two hex head screws, pulled out element slowly from the back of oven wall - enough to expose the wires about 3". Used pliers to remove clips from terminals, put new element in, pushed on new terminal clips, fed wires and terminals back through the two holes, replaced the hex head screws, turned breaker on and wallah! My wife was happy! That's a good thing.

Help other customers find the most helpful instructions.

Were these instructions helpful?

6 of 7 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Easy
Time to do repair: Less than 15 mins
Tools: Screw drivers
Customer: Curtis from Oxon Hill, MD

Bottom element burnt out

remove two screws slide out. slide new one in. put two screws back. done.

Help other customers find the most helpful instructions.

Were these instructions helpful?

5 of 6 people found this instruction helpful

Parts Used:
Level of Difficulty: Really Easy
Time to do repair: 15 - 30 mins
Tools: Nutdriver
Customer: Grady from Myrtle Beach, SC

Broiler element melted

pulled range out, unplugged unit, took out 7 screws, unplugged the elements, reinstalled elements, replugged, and completed with the 7 screws back in place. The 30 minute time was replacing both the broiler and bake elements. The parts were also delivered in a very timely manner. Could not have been more pleased and was very cost effective.

Help other customers find the most helpful instructions.

Were these instructions helpful?

5 of 6 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: Less than 15 mins
Tools: Nutdriver
Customer: lorita from bend, OR

My lower oven heater went out

i was really pleased getting the order from partselect. i had torn my oven appart and knew i needed just this one part i came home and ordered it from parts select and actually got the part the next day.... very nice.... so pleased

Help other customers find the most helpful instructions.

Were these instructions helpful?

4 of 4 people found this instruction helpful

Parts Used:
  • Bake Element
Level of Difficulty: Really Easy
Time to do repair: 15 - 30 mins
Tools: Nutdriver, Screw drivers, Wrench set
Customer: Jeanette from Vergennes, VT

Bake element did not get hot.

I was able to remove the heating element but in the process one of the wires fell behind the back wall of the oven so I needed a little help getting it out. It was my first time working with electricity. If this didn't happen the repair would have been quit easy. The instructions were great.

Help other customers find the most helpful instructions.

Were these instructions helpful?

< PREV 1 2 3 4 5 6 ... 11
1-15 of 152

Model Cross Reference

This part works with the following models:

PartSelect Number: PS249247
Manufacturer Part Number: WB44K5012
Brand Model Number Description
Kenmore1034688610Range
Kenmore1036208511Range
Kenmore1036268412Range
Kenmore1036348412Range
Kenmore1036408412Range
Kenmore1036408413Range
Kenmore1036408710Range
Kenmore1036428412Range
Kenmore1036428413Range
Kenmore1039278412Range
Kenmore1039368410Range
Kenmore1039378410Range
General Electric22388L0Range
General Electric22388W0Range
General Electric24488L0Range
General Electric24488W0Range
General Electric24588B0Range
General Electric24588L0Range
General Electric24588W0Range
General Electric24688B0Range
General Electric24688L0Range
General Electric24688W0Range
Kenmore3634672994Range
Kenmore3636204190Range
Kenmore3636244190Range
Kenmore3636424190Range
Kenmore3639114190Range
Kenmore3639144190Range
Kenmore3639164190Range
Kenmore3639321191Range
