Part Location Diagram of WH01X10310 GE Timer Knob
See part 8 in the diagram
Replacing your General Electric Washer Timer Knob
( Grid squares measure 1x1 inch )
Customer Service Representative

Get in touch, we're here to help!

Daily 8am - 9pm EST

customerservice@partselect.com

Timer Knob WH01X10310

★★★★★
★★★★★
56 Reviews

Rated by 55 customers

Really Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

$ 8.69
  In Stock
Get FREE EconoShip on orders over $100! T&C apply

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

PartSelect Number PS1482286
Manufacturer Part Number WH01X10310
Manufactured by GE
Product Description

Timer Knob Specifications

This is a replacement timer knob for your washing machine. To complete this repair you will need a pair of needle nose pliers. Turn off power to the washer before you start. Pull off the timer knob and use your pliers to remove the retaining clip. The new knob will already have a clip in place. Line up the knob opening with the shaft and slide it on.
How Buying OEM Parts Can Save You Time and Money

How Buying OEM Parts Can Save You Time and Money

Part Videos

Replacing your General Electric Washer Timer Knob

Replacing your General Electric Washer Timer Knob
Troubleshooting
This part fixes the following symptoms:
Will Not Start | Touchpad does not respond
This part works with the following products:
Washer.
This part works with the following products:
General Electric.
Part# WH01X10310 replaces these:
AP3994965, 1264403, WH01X10310
Back to Top
Customer Reviews
Average Rating:
★★★★★
★★★★★
56 Reviews
4.8
Filter By Rating:
  • 5 Stars
    50
  • 4 Stars
    4
  • 3 Stars
    1
  • 2 Stars
    0
  • 1 Star
    1
Sort by:
  • 1
  • 2
  • 3
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
  • 1
  • 2
  • 3
Customer Repair Stories
 Average Repair Rating: 4.5 / 5.0, 55 reviews. What's this?
Sort by:
  • 1
  • 2
  • 3
Sorry, we couldn't find any existing installation instruction that matched.
Timer knob failed to engage and rotate dial
This is a very easy repair. I followed the video instructions for the timer and knob. The basic steps are:
1. Unplug appliance and move it away from wall for access to back.
2. Remove three hex head screws behind control panel/
3. Tilt control panel forward and slide it sideways to free it from the washing machine. ... Read more >4. Remove knob using a flat head screw driver to slide retaining clip
5. Disconnect electrical harness from timer assembly.
6. Remove one screw holding timer to control panel and rotate the timer assembly to remove it.
7. Install and connect new timer.
8. Complete installation by re-installing knob, panel screws, etc.
Very easy.
Other Parts Used:
Timer Timer Knob
  • Gary from AVON, CO
  • Difficulty Level:
    Very Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver, Pliers, Screw drivers
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Timer gears stripped, need to replace timer.
Took out the 3 screws holding the back on and removed the back. Unplugged the timer, took off the knob and dial. Removed the old timer. Replaced with the new timer, replaced the screws holding the timer in. Put the new dial and timer knob. Replaced the back tightened the screws and started the washer up. Yeah!
Other Parts Used:
Control Knob and Clip - White Timer Dial with Compression Ring Timer Knob
  • Jerry from ALBEMARLE, NC
  • Difficulty Level:
    Very Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Pliers, Screw drivers, Socket set
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Bad timer and belt
Removed screws from the back removed screw from timer replaced timer. Removed front panel and replaced belt videos were extremely helpful
Other Parts Used:
Belt Installation Tool Timer Dial with Compression Ring Timer Knob 6-Rib Drive Belt Compression Ring
  • Dean from MINEOLA, TX
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Nutdriver
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Knob wouldn't turn timer got timer to turn but it would not advance to next cycle
Watched video online when I ordered the parts very helpful
Other Parts Used:
Timer Dial with Compression Ring Timer Knob
  • Bob from ALLIANCE, OH
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Nutdriver, Pliers
4 of 4 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Noisey during spin cycles
Followed videos on partselect.com for changing tub bearing. Video does very good job of showing steps required. Repair would be easy if washer was new. First problem was conical tub nut could not be loosened even applying penetrating oil and heat. Finally resorted to 1/2" drive pneumatic impact gun (wrench) which hammered about 10 seconds before the nut came loose. Had to purchase 1-11/16 deep well 6 point impact socket at cost of about $30 for this task. Second difficulty was removing tub seal whose exterior rubber coating had apparently failed and the seal internal metal parts corroded causing it to expand. The tub seal had to be beat out from the bottom side using a drift. The next difficulty was removing the tub bearing which had corroded from minor leakage through the tub seal. Corrosion made the tub bearing outside diameter (OD) larger so it could not be removed using the method in the video. The outer tub bottom side was supported as close to the center as best possible and a socket just smaller than the tub bearing OD was placed on top of the bearing and was used to drive (hammer) the tub bearing out. There was a lot of cleaning necessary especially on the inner tub conical fit areas where tub rides on the split ring and hub nut. During reassembly the tub seal did not have a press fit into the tub; it was barely finger tight. I suspect the tub had permanently distorted in the seal area because the old tub seal had corroded and expanded. So silicone sealant was applied to the outside diameter of the tub seal to assure no leakage around the seal. I allowed that to cure overnight to be certain the seal would not move when inserting the shaft and mode shifter through the seal. A very light oil was applied inside the tub bearing. The last problem found was when tightening the bolts holding the base frame to the outer tub the base frame was pulled to one side so the mode shifter was not concentric with the base frame. This would place a side load on the mode shifter shaft and tub bearing. This was resolved by placing a 1/16" thick washer between one leg of the tub and base frame which maintained the base frame concentric to the mode shifter as the tub to base frame bolts were tightened. The repair is conceptually easy to perform but was challenging due to corrosion and detergent residue from 11 years operation. Now the washer rotating parts are essentially new, the repaired assembly is probably better than the original factory assembly, and the washer should operate for another ten years before the mode shifter bearing goes out again. A longer repair than anticipated but time and money well spent. Being retired helps.
Other Parts Used:
Tub Seal Shaft and Mode Shifter Assembly Split Ring Dial with Compression Ring Timer Knob 6-Rib Drive Belt Hub Washer Tub Bearing Tub Bearing Washer Hub Nut
  • Daryll from MURRYSVILLE, PA
  • Difficulty Level:
    Difficult
  • Total Repair Time:
    More than 2 hours
  • Tools:
    Nutdriver, Pliers, Screw drivers, Socket set, Wrench (Adjustable), Wrench set
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
multiple parts were needed to repair my washer
Initially I thought just the timer knob would take care of my washer not working, but that was too naive of me, lol.
I had to replace the timer knob & clip, the compression dial and the agitator and the agitator coupling.
In other words I rebuilt my washer using the installation video's provided here.
I now have a "brand new" washing machine for a total of less than$100 and it is working perfectly!
Other Parts Used:
Timer Knob Timer Knob Clip
  • Sherry from PHOENIX, AZ
  • Difficulty Level:
    Very Easy
  • Total Repair Time:
    30 - 60 mins
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Agitator Coupling Replacement..
Pry the cap off of the top of the agitator, then one 7/16 bolt to remove the agitator (takes around 15" of extensions to reach the bolt and there is a small o-ring under the bolt that you don't want to miss).
The hard part is getting the old coupler out of the agitator. Four lock tabs need to be held back while the coupler is pulled out. I warmed it all up with a heat gun, pried the tabs back with screw drivers, and pulled the coupler out with a pair of Channel Locks. Kinda like pulling a very big tooth. After that, all was easy. Line the new coupler up with the locator splines in the agitator, knock it in with a rubber mallet. Slide the agitator back on the shaft, run the bolt back in and tighten (don't forget the o-ring), pop the cap back on. Done.
Other Parts Used:
Agitator Coupling Dial with Compression Ring Timer Knob Timer Knob Clip
  • Tom from Republic, MO
  • Difficulty Level:
    Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Pliers, Screw drivers, Socket set
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
knobs were broken
put the knobs where they belong
Other Parts Used:
Control Knob and Clip - White Dial with Compression Ring Timer Knob
  • MARIE from Nicholson, PA
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Timer knob was broken AND it was falling down from center
First I unplugged the washer and removed the old knob and compression ring hoping that the new ones would be centered. Everything still dropped, so I opened up the panel from the back and found that a very thin plastic piece which held the knob and associated timer behind it in place was broken on one side. I taped the timer in place with duct tape, then made a little support out of some stiff cardboard and taped that underneath the time to support it from below. Then I closed the panel back up and applied the new ring, knob, and clip. So far, everything is working fine! The new knob came with a clip, so I have an extra clip... This was not really very hard, but I had to figure out the additional steps to take because of the broken plastic inside.
Other Parts Used:
Dial with Compression Ring Timer Knob Timer Knob Clip
  • Helen from PALM BCH GDNS, FL
  • Difficulty Level:
    A Bit Difficult
  • Total Repair Time:
    1- 2 hours
  • Tools:
    Pliers, Screw drivers, Socket set
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Knob kept spinning
Used needle nose pliers
Other Parts Used:
Dial with Compression Ring Timer Knob
  • Frank from PARMA, OH
  • Difficulty Level:
    Very Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Pliers
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
  • 2
  • 3
Questions and Answers

Ask our experts a question about this part and we'll get back to you as soon as possible!

6 questions answered by our experts.
Sort by:
  • 1
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Rebecca
January 31, 2019
Hello!! the outer knob will not spin the dial to start the machine. i have to manually turn the dial ring then push down the timer knob to get the washing machine to start. do i need to replace the knob or could it just be the clip? thanks!!!
For model number WLSR2200JW33
PartSelect logo
Hello Rebecca, thank you for your question. You can check the clip to see if it is loose or broken. However, the best thing to do would be to replace the timer knob PartSelect Number PS1482286 which comes with a new clip. I hope this helps!

19 people found this helpful.

Was this helpful?
Thank you for voting!
Ron
May 1, 2019
When I push in timer knob it doesn’t engage. It just spins around when you turn it. Could you tell me what part or parts i need? Thank you.
For model number GHWP1000M2WW
PartSelect logo
Hello Ron, Thank you for the question. If there is no visible damage to the knob or dial, I suggest replacing the Timer Switch, PartSelect Number PS3506805. Thank you for your inquiry, good luck with this repair!

3 people found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
James
January 15, 2019
Does this replace eno20a 175d 3296?
PartSelect logo
Hello James, Thank you for the question. Very sorry but the eno20a 175d 3296 is not a valid number. In order for us to locate the correct parts and repair information we will require the model number of the unit. Once you have located the model number please feel free to resubmit the question and we will be happy to help you. Look forward to hearing from you!

3 people found this helpful.

Was this helpful?
Thank you for voting!
Clark
December 2, 2019
When i removed the broken timer control knob, the spindle it attaches to came out in the knob. How is the spindle replaced or re-attached? Thanks.
For model number WJRR4170GWW
PartSelect logo
Hello Clark, Thank you for your question. The spindle cannot be reattached, you would need to replace it by replacing the timer switch for your model under part PS1482380 to fix the issue. Hope this helps!

2 people found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
Maribel
December 9, 2019
GE washing machines works but i have to advance the cycles myself. How will i know if it's the entire timer or just the knob that needs to be replaced?
For model number WDRR2500K4WW
PartSelect logo
Hello Maribel, thank you for your question. If you have to advance the cycles yourself, the timer should be replaced. That is PartSelect Number: PS3406192. Please enter the part number into the site for current price and availability. Good luck with your repair!

2 people found this helpful.

Was this helpful?
Thank you for voting!
Delois
June 27, 2023
my washer want come on plus it stop in the middle of a wash what you think that is
For model number GCWP1800D1WW
PartSelect logo
Hi Delois, thank you for reaching out. Based on our understanding of the issue, we would suggest you replace the timer, part number PS4704240, to fix the issue. We hope this solves your problem.

Was this helpful?
Thank you for voting!
Related Parts:
  • 1
You May Also Need ?
Model Cross Reference
This part works with the following models:
PartSelect Number: PS1482286
Manufacturer Part Number: WH01X10310
Brand
Model Number
Description
General Electric
57731H0WW
Washer
General Electric
57731H2WW
Washer
General Electric
57731H3WW
Washer
General Electric
57731H5WW
Washer
General Electric
57731H6WW
Washer
General Electric
57731H7WW
Washer
General Electric
57731H8WW
Washer
General Electric
57731H9WW
Washer
General Electric
GBAN2800F0WW
Washer - WASHER
General Electric
GBSR3140H1WW
Washer
General Electric
GBSR3140H2WW
Washer
General Electric
GBSR3140H3WW
Washer
General Electric
GBSR3140H4WW
Washer
General Electric
GBSR3140H5WW
Washer
General Electric
GBSR3140H6WW
Washer
General Electric
GBSR3140H7WW
Washer
General Electric
GBSR3140H8WW
Washer
General Electric
GCAP1000M0WW
Washer
General Electric
GCAP1000M1WW
Washer
General Electric
GCAP1000M2WW
Washer
General Electric
GCAP1800D0WW
Washer
General Electric
GCAP1800D1WW
Washer
General Electric
GCSR2090H0WW
Washer
General Electric
GCSR2090H2WW
Washer
General Electric
GCSR2090H3WW
Washer
General Electric
GCSR2090H5WW
Washer
General Electric
GCSR2090H6WW
Washer
General Electric
GCSR2090H7WW
Washer
General Electric
GCSR2090H8WW
Washer
General Electric
GCSR2090H9WW
Washer
