Part Location Diagram of W11291138 Whirlpool SWITCH
See part 3 in the diagram
Replacing your Maytag Refrigerator SWITCH
( Grid squares measure 1x1 inch )
Customer Service Representative

Get in touch, we're here to help!

Monday to Saturday
8am - 9pm EST

customerservice@partselect.com

SWITCH W11291138

 Fits your LSD2615HEW!
★★★★★
★★★★★
15 Reviews

Rated by 19 customers

Really Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

$ 28.72
  In Stock
Get FREE EconoShip on orders over $100! T&C apply

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

 Fits your LSD2615HEW!
PartSelect Number PS12584655
Manufacturer Part Number W11291138
Manufactured by Whirlpool for Maytag, Amana, Whirlpool, Kenmore
Product Description

SWITCH Specifications

This is a light switch for your refrigerator. It activates when the door of your appliance is opened, and it will turn the light inside on and off. You will need to replace this part is if your light is not working properly. In order to make this repair you will need a Phillips screwdriver, a pair of needle nose pliers, and a small flat blade screwdriver. This light switch is almost 2 inches long, 1.5 inches wide, and just over an inch thick.
How Buying OEM Parts Can Save You Time and Money

How Buying OEM Parts Can Save You Time and Money

Part Videos

Replacing your Maytag Refrigerator SWITCH

Replacing your Maytag Refrigerator SWITCH
Troubleshooting
This part fixes the following symptoms:
Light not working
This part works with the following products:
Refrigerator, Ice Maker.
Part# W11291138 replaces these:
12466104, 63001030, W10847852, WP12466104
Back to Top
Customer Reviews
Average Rating:
★★★★★
★★★★★
15 Reviews
4.5
Filter By Rating:
  • 5 Stars
    11
  • 4 Stars
    2
  • 3 Stars
    1
  • 2 Stars
    0
  • 1 Star
    1
Sort by:
  • 1
  • 2
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
  • 1
  • 2
Customer Repair Stories
 Average Repair Rating: 4.4 / 5.0, 19 reviews. What's this?
Sort by:
  • 1
  • 2
Sorry, we couldn't find any existing installation instruction that matched.
Refrigerator light stopped working
Followed the instructions in the video provided via email from Partselect
However, the part received was the opposite design of the part removed.
It appeared this could be left hand right hand choice of part. Moreover, the button on the switch that turns the light off/on when door is open/closed was not functional due to the part being the opposite of the part I was replacing. I tested the switch I was replacing and it appears this is not the problem. I think the light socket is the problem. I am 69 year old female and capable of doing small repairs, but limited knowledge of electrical so having to troubleshoot by trial and error. Thank you.
  • Linda from CORSICANA, TX
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Repaced the right-side door light switch
Killed the power to the fridge. Then, used a small, thin screwdriver to depress the clip on the bottom of the switch and wriggled the old switch out. The two wires easily came off the contacts with pliers. Connected the wires to the new switch and snapped it into the hole--clip facing down and contacts facing up. Turned the power back on and checked the switch. Worked perfectly! Easy job.
  • Charles from SEGUIN, TX
  • Difficulty Level:
    Very Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Pliers, Screw drivers
1 person found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
broken latch
follow instructions from youtube.
Other Parts Used:
SWITCH Door Latch Assembly
  • steven from CHURCHTON, MD
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    15 - 30 mins
  • Tools:
    Screw drivers
5 of 5 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Light switch that causes light to turn on when door is open was nroken.
Truth is, this took a couple hours of cursing, but that was due to poor information and no prior experience. I imagine the next one would take 20 minutes. The issues are these: videos tell you to use a putty knife to pry the old switch out. That is harder than it seems because each switch has a plastic spring that pops open to hold the switch on, and you can't access the spring when the switch is installed. So it is important to use the knife on the side of the switch (left or right of spring -- look at the new switch), and back and forth until the switch is worked out. Then it can get worse. The new switch has to plug in electrically before it can be installed mechanically. In my case, with the switch on the fridge wall rather than the top, the outlet for the plug was encased in foam insullation. That gives the appearance that the plug was fixed, immovable, which makes it impossible to plug it in electrically before the switch is in place, and of course once it is in place you can't then plug it in. The problem here was poor instructions. Just scrape out a lot of the foam around the plug and you find that the plug is really not fixed, but attached to reasonably long wires that allow you to plug it in with the switch a couple inches from the wall, and then insert the switch. None of the online instructions tell you this about the wires.
  • John from WASHINGTON, DC
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
4 of 5 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Light Switch Broken
Removed old light switch by prying up and out of housing...removed wires (carefully not to get shocked!) and taped to inside of refrigerator housing. Ordered best matching part and rec'd it in a couple of days. Took less than 5 minutes to remove taped wires from side of cabinet and connect to new switch (which was a perfect match to the original equipment) and snap switch back into refrigerator housing! Works perfectly! Thanks!
  • Christopher from Portland, OR
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Broken Door Light Switch
Pried out old Switch,Hooked wires to new switch Snapped in New Unit.
5 minutes Total Time
  • Ricky from Tempe, AZ
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Screw drivers
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Refrigerator light switch broke to pieces
Took knife and pried out the the damaged switch. Took wires off. Put the wires on the new switch and put it back in the hole. Job finished. The part shipment was very prompt and I am happy. The End!
  • Charlane from Harriman, TN
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Nutdriver
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Chaged out Door Light Switch
By sliding athin screwdriver blade down the side of the old switch the expasion prong that hold the switch in place was compressed enough to allow the switch to come out easlily. Plugged in new swithc and snapped in place. Plugged the refrigerator back in and light has worked great sense!
  • Scott from Kansas City, MO
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Screw drivers
7 of 10 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Door switch module wore out
Pull out old module...
Remove 2 wires...
Tape to inside wall [don't want them to fall down into side panel]..

Order new switch..

Fed Ex pkg came on 2nd day..

Install wires on switch...
Press into opening...
Check door light on..[OK]
.. Done
  • Fred from Oceanport, NJ
  • Difficulty Level:
    Easy
  • Total Repair Time:
    Less than 15 mins
  • Tools:
    Pliers
40 of 55 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
broken
part got here fast and I fixed it in no time. GREAT Thanks
  • James from Orlando, FL
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    Less than 15 mins
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
  • 2
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

1 question answered by our experts.
Sort by:
  • 1
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Gary
July 12, 2021
What causes the inside to flicker
For model number WRX735SDBM0R
PartSelect logo
Hello Gary, Thank you for the question. Normally this is an indication the LED Light Module is defective and should be replaced. We hope this helps!

1 person found this helpful.

Was this helpful?
Thank you for voting!
