Broil Element WPW10310249

I checked out Maytag.com - found the parts page on my computer - found the top oven element - ordered it from Part Select - it arrived just a few days later......

Before it arrived, I removed the damaged electric element from top of oven - easy.

Oven was ready for me to install new element - the video on your website was perfect - it helped me remove the old & install the new element from Part Select. It took me about an hour.

Thank you for your fast service, good instructions & the video!

I'm an 84 year old female. Did this by myself! Thank you!

My daughter repaired it without any problems.

I've been trying to remove the bracket at the roof of upper oven so I can get to the broiler element itself. The screws are in place so tight, the won't move. I've used regular as well as ratchet screwdrivers and the screws still won't move. I don't want to spray WD 40 in oven because of a possible fire hazard, so I haven't changed out element yet. Tried calling customer service for advise, but to no avail. All other screws loosen easily. What should I do next.

I just bought my first condo and sure enough something broke in my oven. I thought "Oh great - I'll need to buy a new one..." After some research and a friend's advice - I was assured that I only needed to replace the broiler element. After researching the issue I googled replacement parts which led me to this web-site. I was amazed how easy and inexpensive it was for me to replace the part. The directions were easy, simple, and spot-on! The instructions that were provided were easy to follow. I also utilized YouTube instructions as well for additional visual guidance. The shipping was super fast and the element was packaged very well. Thank you so much!

Shipped on timely manner,I will order again from Part Select, installing was a 15 minute job, that what I did, 1 unplugged stove, 2) removed 4 screws, (2 on top bracket and 2 on back) , 3) slide unit out couple inches enough to disconnected the wires from each end of unit and removed old part, installed new unit by reconnecting end wires, pushing unit slowly toward back of oven until wires find it's right position, set it back in place with the 2 screws on top bracket and 2 screws on back, done!!

Power turned off. Door of the oven lifted off. Four screws removed, old element pulled out to reveal electrical connectors. Wires easily removed, and element discarded. New element connected to the two conductors, four screws installed and the job was completed.
Very easy. Took about 10 minutes.

The toughest part was seeing the two screws in the dark rear of the oven, so a good flashlight with adjustable beam is helpful. After removing the pots and pan drawer from it's tracks, take the opportunity to clean out that space underneath the drawer when you unplug the oven. Once that was done, I removed the bracket screws holding the broken broiler element on the roof of the oven and the two screws holding the element in the rear of the oven. It's an uncomfortable reach so, setting a flashlight on the open over door helped me see what I was doing. The element slides right out of the holes from with in the insulation behind the oven's rear panel. Each side is connected to a wire pin that may need a good tug with pliers to slip the wire clip off the old element end. The new element connected right to the old wire clips with ease. You may have to jiggle the element end as you poke it back through the hole into the insulation where it came from. The element ends screwed right back into it's original position with the old screws. I slipped the roof bracket over the new element and reattached to the oven roof. I plugged the oven back in, replaced the drawer on it's tracks, tested the broiler and it works like a charm. Total time 35 minutes.

FIgured it was either a bad heating element or a realy expensive repair so I purchased a replacement element to rule out the simple and inexpensive possibility. Pulled oven out from wall and disconnected power supply. Removed retaining bracket from top of oven, two screws that held in heating element, disconnected from fittings, replaced with new element, and reattached screws and retaining bracket. Plugged in power supply, tested lower oven (it worked just fine) pushed oven back against the wall. Threw away the old element and packaging. Job done.

not to offend anybody but what i learned on prior posts helped alot..
1. remove unit and unplug.
2. remove door by opening to 45 degree angle and lifting door face towards you.
3. remove back panel to unit.e.
4.unscrew burner element from back inside of oven.
5.gently pry clip off each off burner element from rear of unit. Pull gently towards you.
6.unscrew support from inside oven.
7. remove old element and just reverse directions to reinstall.

removed screws and disconnected the wires removed element and did the replacement less than 15 minutes, and cost less than locally by 25.00 and received part the next day. EXCELLENT
