Faucet Adapter WPW10254672

Took old one off , installed new one!!

Purchased and installed new faucet attachment. It arrived quickly and very easy to attach. Thank you !

So I decided to stick in some CLR to see if it would clean it up. Well it got considerably worse. So ordered the new faucet adapter, threaded adapter and the two washers, due to not knowing what i would need. It came like unbelievably fast considering it was Christmas time. Unscrewed the old one from the faucet, screwed on the new one. hooked up the dishwasher, watched it for a bit for any leaks at the connection, and it worked great! I seem to have more water pressure too coming from the sink faucet. Thank you so much for the quickness in sending out my order! -- Scott

Very easy,take off the old faucet screen and screw on the adapter. What I really liked was the ease of ordering the part. In less than 5 minutes I had located the part and ordered it. Less than 3 days later, I had the part. Way to go PartSelect.

I removed all the cabinet screws (be careful, they use a special star bit and mine broke so I replaced all the screws with hex head sheet metal screws which was OK).
I then removed the top-very easy, 3 screws.
Disconnected two hoses at bottom of machine, one with a clamp that needed to be unscrewed the other was standard hose attachment. Put a shallow pan under the hose area where you will be removing them. There will be some water. Remove the hose assembly from the special plastic holder on the inside of the cabinet and remove the assembly from the entry point at the rear of the cabinet. Insert the new hose assembly, connecting the hoses first.
Check the old hose to determine roughly where it had been bracketed to the cabinet making sure you will have enough hose to reach your faucet. I left no slack inside the machine beyond the plastic holder. Reassemble the cabinet to the frame loosely screwing it in until all screws are in. The finish tightening them all. Reinstall the top.
Unscrew the old faucet connector and screw in the new one until fully hand tight. If you use a pair of pliers to tighten it more, protect it from the tool buy using a cloth of plastic jar cover remover to prevent damage. Connect the machine to the faucet, plug it in and let her rip. Mine was leak-less but NOTE- I connected it and tested it before re-assembling the cabinet, Otherwise you won't know if your connections were tight until its too late.

I ordered the part and it fit perfectly!! About five minutes to screw it onto my faucet and problem solved!!!

Turned machine on side. Removed two casters with Wonder Tool prybar. Then used it to remove plastic push screws holding cardboard bottom cover. Unscrewed water hose. Used screwdriver to remove clamp on drain hose. Stood machine upright, opened door. Unscrewed two screwsfrom tabs into woodblock top. Slid top forward and removed it. Cut plastic hose retainer. Removed hose assembly. Installed new hose by reversing steps. Used a new wire strap to hold hoses in place on top corner of machine.

I have a new faucet so I remove the screen then I used an extender ring put on your adapter an got the washer to run.

Use towels to catch water that spills from unit. Lay unit on side to expose bottom. Remove plastic retainers, rear wheels, and bottom cover. Disconnect inlet and discharge hoses. Tie pull cord onto each hose separately. Temporarily re-install rear wheels. Set uinit upright. Remove two star screws from underside of wooden top. Slide top forward to release and remove top. Remove tie strap holding hoses to inner bracket. Lay unit on side again and pull hoses out. Remove discharge hose first to allow removal of inlet hose from plastic housing on back of unit. Tie pull cords to new hoses. Pull new hoses into unit. Reconnect hoses. Turn unit upright. Replace tie strap on bracket with new hoses. Hoses are marked as to where they should be secured to the bracket. Replace top. Remove old door gasket by pulling from one end of gasket. Clean gasket groove. Push new gasket into place. Close door to seat gasket. Remove and replace faucet adapter kit. Run unit and check for leaks. Lay unit on side, remove rear wheels, replace bottom cover and plastic retainers, reinstall rear wheels.
