Bake Element

★★★★★
★★★★★
4 Reviews

Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

PartSelect Number PS11750370
Manufacturer Part Number WPW10207398
Manufactured by Whirlpool
Product Description

Bake Element Specifications

This bake element is found on the bottom of the oven.
How Buying OEM Parts Can Save You Time and Money play video

How Buying OEM Parts Can Save You Time and Money

Troubleshooting
This part fixes the following symptoms:
Element will not heat | Little to no heat when baking
This part works with the following products:
Wall Oven, Range, Microwave Oven Combo.
This part works with the following products:
KitchenAid, Whirlpool, Maytag, Crosley.
Part# WPW10207398 replaces these:
AP6017075, 9760768, W10207398
Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

13 questions answered by our experts.
Sort by:
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Greg
May 6, 2018
The bake element for this model is not inside the oven. Where is the access for this hidden bake element? I'm assuming it's in the back. Can you explain how to access and change the element. Please do not provide a link to the same video - it's not applicable to this model. Thank you.
For model number KESS907SSS04
Hi Greg, Thank you for the question. For the hidden element, you will need to pull the appliance out from the wall to access it from the back. Hope this helps!

6 people found this helpful.

Was this helpful?
Thank you for voting!
Jimmy
August 12, 2019
Do you have instructions on installation of part w10207398 for the model kdss907sss05 ?
For model number KDSS907SSS05
Hello Jimmy, Thank you for the question. You will need to pull the appliance out from the wall to access the panel on the back of the appliance. Once the panel is removed you will need to move the insulation away and bend down a tin panel that covers the back of the element. Remove the wire connectors and element and reverse the steps to reinstall. Hope this helps!

3 people found this helpful.

Was this helpful?
Thank you for voting!
Mark
February 27, 2019
I am trying to replace the bottom hidden bake element on my KitchenAid oven and cannot for the life of me figure out how i am suppose to get it out. I have pull a few covers off the back and found the 2 element prongs sticking out the back and disconnected the wires. I move some of the insulation out of the way exposing 2 screws apparently holding it in. But now it will not come out any further and i am wondering if it is suppose to come out the front or the rear of the oven somehow. The video you keep listing to help people does not apply to this particular model.
For model number KESS907SSS04
Hi Mark, Thank you for your question. There is a video on our website that you can reference on how to install the bake element. You will find the video under part number PS249247. I hope this helps. Thank you and have a great day!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Earl
April 25, 2019
How to install bake element part# wpw10207398
For model number kebs107sss04
Hi Earl, Thank you for your inquiry. There is a video on our website that you can reference on how to install the. You will find the video under part number PS249247. I hope this helps. Thank you and have a great day!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Jean
October 27, 2017
How do you remove oven bake element to replace
For model number KESS907SSS04
Hi Jean, Thank you for your inquiry. There is a video on our website that you can reference on how to install the. You will find the video under part number PS249247. I hope this helps. Thank you and have a great day!

1 person found this helpful.

Was this helpful?
Thank you for voting!
Jean
October 27, 2017
Are the oven bake element and warming drawer element the same element
For model number KESS907SSS04
Hi Jean, Thank you for your question. They are not the same elements. I have listed the element for your drawer in a link down below. Good luck with your repair.

Was this helpful?
Thank you for voting!
Related Parts:
Jean
October 27, 2017
I can see broil element and warming drawer element bake element is not visible so how do i get to it
For model number KESS907SSS04
Hi Jean, Thank you for your inquiry. The bake element would be the bottom heating element in the oven. It would be exposed and fairly easy to access. We have a how to video that shows how to replace this part, you can follow the link below, hope this helps! https://www.youtube.com/watch?v=aahcHBzTrk8. I hope this helps. Thank you and have a great day!

Was this helpful?
Thank you for voting!
Cheryl
January 28, 2018
In this model the bake element is hidden, it is not visible in the bottom of the oven. So how do you access it to change the part? Does the entire unit have to be pulled out of the cabinet?
For model number KEMS308SSS00
Hi Cheryl, Thank you for your inquiry. The bake element would be the bottom heating element in the oven. It would be exposed and fairly easy to access. We have a how to video that shows how to replace this part, you can follow the link below, hope this helps! https://www.youtube.com/watch?v=aahcHBzTrk8. I hope this helps. Thank you and have a great day!

Was this helpful?
Thank you for voting!
Roy
April 5, 2018
How does one access the element to make a replacement repair
For model number kesk901sss06
Hi Roy, Thank you for your inquiry. The bake element would be the bottom heating element in the oven. It would be exposed and fairly easy to access. We have a how to video that shows how to replace this part, you can follow the link below, hope this helps! https://www.youtube.com/watch?v=aahcHBzTrk8.

Was this helpful?
Thank you for voting!
Linda
October 14, 2017
How do you get to the heating element to change it
For model number KDRS807SSS04
Hello Linda, thank you for contacting us. The bake element would be the bottom heating element in the oven. It would be exposed and fairly easy to access. We have a how to video that shows how to replace this part, you can follow the link below, hope this helps! https://www.youtube.com/watch?v=aahcHBzTrk8

Was this helpful?
Thank you for voting!
Customer Repair Stories
 Average Repair Rating: 2.3 / 5.0, 1 reviews. What's this?
    Sort by:
    Sorry, we couldn't find any existing installation instruction that matched.
    Corroded bake element
    Pull it away from the wall and take everything off the back. Unscrew the element cover, cut through the insulation and remove the part. Not easy, watch for sharp sheet metal edges
    • Tim from Langley, WA
    • Difficulty Level:
      Difficult
    • Total Repair Time:
      30 - 60 mins
    • Tools:
      Pliers, Screw drivers
    4 of 5 people found this instruction helpful.
    Was this instruction helpful to you?
    Thank you for voting!
      Customer Reviews
      Average Rating:
      ★★★★★
      ★★★★★
      4 Reviews
      5.0
      Filter By Rating:
      • 5 Stars
        4
      • 4 Stars
        0
      • 3 Stars
        0
      • 2 Stars
        0
      • 1 Star
        0
        Sort by:
        Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
          Model Cross Reference
          This part works with the following models:
          PartSelect Number: PS11750370
          Manufacturer Part Number: WPW10207398
          Brand
          Model Number
          Description
          Crosley
          CT15G4Q
          Refrigerator
          Whirlpool
          GBD279PVB00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBD279PVB02
          Wall Oven - Built-in, Electric, Double
          Whirlpool
          GBD279PVB03
          Wall Oven - Built-in 27" Electric, Double
          Whirlpool
          GBD279PVQ00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBD279PVQ02
          Wall Oven - Built-in, Electric, Double
          Whirlpool
          GBD279PVQ03
          Wall Oven - Built-in 27" Electric, Double
          Whirlpool
          GBD279PVS00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBD279PVS02
          Wall Oven - Built-in, Electric, Double
          Whirlpool
          GBD309PVB00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBD309PVB02
          Wall Oven - Built-in 30" Double Electric
          Whirlpool
          GBD309PVB03
          Wall Oven - Built-in 30" Double Electric
          Whirlpool
          GBD309PVQ00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBD309PVQ02
          Wall Oven - Built-in 30" Double Electric
          Whirlpool
          GBD309PVQ03
          Wall Oven - Built-in 30" Double Electric
          Whirlpool
          GBD309PVS00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBD309PVS02
          Wall Oven - Built-in 30" Double Electric
          Whirlpool
          GBS279PVB00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBS279PVB02
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS279PVB03
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS279PVB04
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS279PVQ00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBS279PVQ02
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS279PVQ03
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS279PVQ04
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS279PVS00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBS279PVS02
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS279PVS03
          Wall Oven - Built-in 27" Electric
          Whirlpool
          GBS309PVB00
          Wall Oven - Built-in, Electric
          Whirlpool
          GBS309PVB02
          Wall Oven - Built-in 30" Electric
