Soap Dispenser Cover WP3378138

I used the screwdriver to pry the old lid off of the horizontal pin upon which it rotates. One must be careful before removing the old lid to note how the return spring is deployed. The short legs on the spring must be in the lip of the lid before you snap the new lid onto the horizontal pin. It was helpful to lubricate the two catches on the lid that snap on the pin with some liquid soap before attempting to snap them on the pin. After the lid is snapped into place and the short legs of the coil spring are in the lip of the lid, use needle nose pliers to attach the other end of the coil spring to the pillar where it was before you removed the old lid. There are videos showing how to do this on Youtube. The spring part is a little tricky. The video makes it look a bit easier than it is..

Followed instructions as the videos on this page show.

WATCHED THE VIDEO FOR 2 MINUTES. REPLACED THE 3 PARTS IN LESS THAN A MINUTE. THANKS FOR THE VIDEOS.

Remove old spring pin, spring, door
Waste of time effort and money didn't change a thing still won't dispense soap to wash dishes

I ordered a dishwasher soap dispenser "lid assembly". When it arrived, it was not an assembly at all but only a lid. I had to reorder a pin and spring, When i finally had every thing, it was an easy repair.

Had to be careful positioning the spring without breaking the hinge pin. Requires a certain amount of patience.

Got the new door and tried to put it on. The door went on very easily. However, there's a spring that opens the door when the main wash cycle comes around. I never did get that spring right. None of the drawings showed the correct position and after an hour of trying to get it to work right, I gave up. The door comes open slightly (but not because of the spring) when it's time, and the liquid soap runs out due to gravity. But I wouldn't try to use soap powder because the door doesn't come open far enough.

Sorry, probably need a spring as the door is fine. While reading other stories about how hard the spring was to get right, I assumed the spring was part of the door assembly.
I'll be calling and returnint the part.



















i'

Snap the old lid off, remove the pin & spring & install new Pin & Spring. Very easy. Thanks To Parts Select got the right parts.

Replacing the pin with the spring is a little tricky, it was hard to hold it. And the little plastic pin breaks real easy too, its hard to get the lid to snap in place without breaking the pin.
