Pump Outlet Seal WP302711

Researched parts - 10 minutes - - - Ordered parts - 5 minutes - - - Waited for parts - 14 DAYS! - - - Installed parts - 5 minutes

Did not use the new parts. After removing the spray arm, found a screw out of place. Put the seal ring back in place and the screw back in the hole. Machine works like new.

great parts select.com was a great place to get part for this dishwasher repair, super fast shipping thank you

The pump outlet gasket was sticking out and a screw was missing from the pump outlet housing. This was causing water to flood out under the door.

Once I removed the pump outlet housing I saw that the gasket was out of place almost all the way around. I cleaned around the housing, replaced the gasket and the missing screw.

You need a Torx T-15 for this repair. Note that all of the screws on the housing were loose so you might need to tighten them from time to time.

Be careful not to drip a screw when you are installing it since it's a real hassle to fish it out from under the screen.

Once everything was tightened up, the wash pressure seemed to be much higher.

first I removed lower basket. then removed lower sprayer attached to pump housing by unscrewing the cap by hand. the I removed the pump cover . there were six alan screw two of them were missing causing the failure of the seal spraying solution at the door. replaced the pumpseal working backwards until everthing was replaced.

At first, I suspected the door seal was at fault. However, after reading others' repair experiences, I found the dishwasher may leak if the wash arm bearings are worn. So, I took a look at those, and indeed they were quite worn.

After receiving the parts in the mail, I called my 7 and 9 year old kids over. They were excited to open the package, and weren't too disappointed when they found it was dishwasher parts. I told them it was up to them to fix the dishwasher. As I sat on a stool, I instructed them what to do. They did a great job and now it doesn't leak any more.

Removed 5 or 6 screws replaced O ring,Srewed cover back on ,no more leak.

actually my wife did the repair. she unsrewed the water sprayer and removed it, then unscrewd the star key screws and then replaced the seal. she put everything back the way it was and it is now ready to use and we no longer have the problem.
just a suggestion...if you take some baking soda and some vinager you can clean the drain out. just simply poor in the soda and then the vinager.and it will fiz cleaning your drain.
