Front Top Lock
Get this part fast! Average delivery time for in-stock parts via standard shipping: 1.8 days.

Check if this fits your product and find model diagrams
Need help finding your model number?Front Top Lock Specifications

How Buying OEM Parts Can Save You Time and Money
Ask our experts a question about this part and we'll get back to you as soon as possible!
- < Prev
- 1
- Next >
1 person found this helpful.
1 person found this helpful.
- < Prev
- 1
- Next >
Replacing your Kenmore Dryer Front Top Lock

- < Prev
- 1
- Next >
-
Mark from Huntington Station, NY
-
Difficulty Level:Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Screw drivers
-
James from COTTONWOOD, CA
-
Difficulty Level:Really Easy
-
Total Repair Time:1- 2 hours
-
Tools:Nutdriver, Pliers, Socket set, Wrench set
2) Remove the 2 screws that secure the chute for lint filter screen with
Phillips head screwdriver.
3) Remove the lint filter screen.
4) Depress plastic locking clip on each side with putty knife to release
tension and lift up top panel to clear the locking clips. Each locking
clip is located 2-1/2 inches from the front edge of side panel.
5) Lift the top panel and lean against the wall for support. If dryer top
panel cannot be raised all the way due to cabinet(s) above, tape
the dryer top panel to cabinet above or have somebody hold the
top panel for temporary support.
6) Install the new metal locking clips. Ensure that the elongated tab
of the metal locking clip is towards the front of dryer. Compress
locking clip lightly with pliers and push down into the hole.
7) Lower the dryer top panel and press it down in place over the metal
locking clips for a tight fit.
8) Reinstall the 2 screws to secure the lint filter chute.
9) Reinstall lint filter screen.
10) Reconnect power cable for dryer.
11) Turn on dryer and inspect that all dryer panels (top, sides and
front) are tight and secured.
Repair Duration: 5 minutes
-
MONTE from CHESAPEAKE, VA
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
-
Tools:Pliers, Screw drivers
-
Larry from Bethpage, NY
-
Difficulty Level:Really Easy
-
Total Repair Time:15 - 30 mins
-
Tools:Screw drivers
-
William D. from LUVERNE, AL
-
Difficulty Level:Very Easy
-
Total Repair Time:Less than 15 mins
- < Prev
- 1
- Next >
- < Prev
- 1
- Next >
- < Prev
- 1
- Next >
Manufacturer Part Number: WP18776
