The door strike on your washing machine allows your washer door to lock properly, and operate efficiently. If you notice that your washer door will not open or close, leaks or the washer will not star...
This door lock and switch assembly is manufactured to lock the door on your front load washer to prevent it from opening while it is running. You may need to replace the door lock and switch if the do...
This shock absorber kit is an authentic OEM part that is sourced directly from the manufacturer. The kit includes two dual-stage shock absorbers, one spare shock mounting pin, and four locking nuts. T...
This is a 120 volt, 60 hertz drain pump that is manufactured to remove water from the tub of your washer once your clothes are washed. This part is the pump and motor assembly, which includes a red fl...
The water inlet and dispenser valve is used in washing machines. The function of this part is to control and monitor the amount of water flow into the washer. If there is leaking during use, your mach...
This is a screw in leveling leg for your washing machine. It supports the appliance by screwing in place to create a stable and flat surface. Take note that you are able to adjust the height of your a...
This is a replacement screw for your washer or dryer. The screw is approximately half an inch in length and is a Phillips-head screw. It screws in from the outside of the drum, into the vane/baffle. T...
Also known as a Door Boot Seal and is used in front load washers. This part is used to keep the clothes inside the tub during the wash cycle. The folds in the bellow allow the tub to move separately f...
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
5 questions answered by our experts.
< Prev
1
Next >
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Kevin
February 17, 2020
Will not start comes up e90.
For model number GLTF2940FS2
Hello Kevin, Thank you for the question. The error code E90 is a general error code. It is indicating a communication error between the two boards in your machine. It does not indicate what the problem may be. A power glitch may have caused the E90 error code or a loose connection. You can try to turn power off to the appliance for 5 mins to reset the code and check all wire harness connects to make sure they are secure and not damaged. If everything checks out good, one of the board may be defective. We hope this helps.
We recently had our washer serviced ( general maintenance ). Service mentioned that we will need door replaced/possibly the window of door seal ( minor leaking ). Having difficulty finding the door part/parts.
For model number GLTF2940FS2
Hello Steve, thank you for your question. We have several Door parts including the Door Glass PS1145708, the Door Glass Ring Adapter with Outer Glass PS1145960 and the Inner door panel PS1145709. We have an installation video for the door glass for you to access to see if this is a repair for you. We look forward to hearing from you soon
Hi Hansford, thank you for reaching out. The error E41 indicates that the door switch may not be locked properly. We recommend checking the door switch assembly, part number PS12364048, and the electronic control board, part number 137006000. We looked up the control board and it is listed as No Longer Available/Discontinued. There are no part substitutions listed. Our suggestion here would be to call the manufacturer and see if they can provide you with a substitution for the discontinued part. If they offer a new part number, please feel free to check back with us. We hope this helps.
Was this helpful?
Thank you for voting!
Hansford
February 16, 2023
Stuck in pau mode. E41
For model number GLTF2940FS2
Hi Hansford, thank you for contacting us. The error code e41 indicates that there is a problem with the door lock switch, part number PS12364048. If it does not solve the issue please check the electronic control board, part number 137006000. Unfortunately, the control board has been discontinued and we have no known replacement listed in our system. We have no further information. You are welcome to contact the manufacturer of the part to see if they have recently released a new substitute and then check again with us to see if we have it. We hope that helps. Good luck with your repair.
Was this helpful?
Thank you for voting!
Jaqueline
December 22, 2019
Will not finish washing a load. It will end with 13mins left on the timer and stop. Load still has water in it.
For model number GLTF2940FS2
Hello Jaqueline, Thank you for the question. In most cases this indicates the timer is defective and the Electronic Control Board, PartSelect Number PS2330931 will need to be replaced. Hope this helps!
This was one of the simpliest repairs I have ever done taking less than 5 minutes to complete. On the inner door I removed the two screws that hold the plastic catch in place. I then removed the broken catch and put the new catch in place. Finally I replaced the two screws that hold the catch in place and it was done.
1. Unplug unit. 2. Unscrew 2 nuts holding top in place in rear of unit using phillips head screwdriver. 3.Slide top back and remove. 4. Open door of washer and unscrew 2 screws holding in door lock unit. 5.Pull out unit from the top and install new unit reconnecting the 3 wire connections.
remove top of machine by removing 3 screws along the top edge in the back of your machine and then sliding the top back and up. Then loosen the screws holding on the control panel enough to get to the 2 screws at the top of the door panel. Next remove bottom panel by removing 2 screws along bottom edge then pulling it free from snaps. Then along the outside lip of the bellow, just inside the door, is a wire clip that is easily removed by prying it past rubber lip with a screw driver and lifting it away. Remove the door panel by removing the 2 screws you exposed by loosening the control panel and 2 more along the bottom that were exposed when removing bottom panel. After the door panel is removed and the bellow is completely exposed, you will find that it is held in place by a circular spring which wraps the whole way around the drum opening. Again it can be removed by prying it out away from the groove in which it sits with a screw driver. Now your machine is broken down as far as it needs to be. From here you can follow the directions included in your new bellow kit and put it back together by following these instructions in reverse.
