This sensor (Temperature Sensor, Thermistor, Refrigerator Temperature Sensor) sends the temperature reading of the compartment to the control board. If you notice your refrigerator is too warm, too co...
This defrost termination thermostat (Defrost Limiter Thermostat, High Limit Thermostat, Refrigerator Defrost Bi-Metal Thermostat) acts as a safety device to stop the evaporator coil from overheating, ...
This 10 by 5 inch ice maker (Electromechanical Icemaker Kit, Ice Maker Assembly) produces ice. This particular model will produce seven crescent shaped cubes every cycle. It is constructed of plastic ...
Also called Vegetable Drawer. It is a compartment located within a refrigerator designed to prolong the freshness of stored produce.
Crisper drawers have a different level of humidity from the rest o...
The interior light of your refrigerator is controlled by a switch that is activated when the door is opened and closed. If your refrigerator light will not turn on, there could be an issue with the sw...
This 40-Watt light bulb is sold individually and is a genuine OEM replacement option for your home appliances. It is specially designed to withstand extreme temperatures, so this bulb is compatible wi...
This compression ring is meant to hold the evaporator fan motor in place in the freezer compartment of your refrigerator. This is is a genuine OEM part. The tools needed to complete this repair are a ...
The lid bumper or evaporator fan motor bumper in your refrigerator prevents the fan motor from scraping against the side bracket. If your refrigerator/freezer is noisy, the bumper could be worn down o...
This evaporator fan blade is for your refrigerator, and it circulates air so that the temperature of the fridge is regulated. This model has 3 blades, and is a little more than 4 inches in diameter. I...
This is a replacement evaporator fan grommet for your refrigerator. The fan grommet absorbs the vibration from the evaporator fan motor for quiet operation while it runs. If your evaporator fan is unu...
This is a replacement set screw for your refrigerator door. The set screw attaches the door handle to the stud on the refrigerator door. The screw is approximately ¼ of an inch in length and unlike so...
This part is the replacement drawer slide rail for your refrigerator. The crisper draw will slide in and out along this rail. If the rail is damaged or missing, the crisper will either hang from one s...
$24.05
In Stock
Questions And Answers for GFSS2HCYCSS
We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.
8 questions answered by our experts.
Sort by:
< Prev
1
2
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Kandis
May 15, 2023
How do I remove the plastic light casing to replace my refrigerator light?
For model number GFSS2HCYCSS
Hi Kandis, thank you for reaching out. You need to follow the following instructions to replace the light in the refrigerator:
1. Unplug the power to the appliance.
2. Open the refrigerator door to locate the light shield.
3. To remove the light shield, grasp the shield at the back and pull out to release the tabs at the back.
4. Rotate the shield down and then forward to release the tabs at the front of the shield.
5. After replacing the appliance bulb with one of the same or lower wattage, replace the shield.
6. Plug the refrigerator back in.
We hope this information helps!
2 people found this helpful.
Was this helpful?
Thank you for voting!
Bruce
December 7, 2019
Where is the water filter located at??
For model number GFSS2HCYCSS
Hello Bruce and thanks for writing.
For your convenience, we have attached the link to our video with repair instruction. We hope this helps. Good luck with your repair
https://www.youtube.com/watch?v=UerVcdQXJ_Y
1 person found this helpful.
Was this helpful?
Thank you for voting!
Pete
January 15, 2024
The refrigerator & Freezer are working O.K. temps are good.
The condenser fan motor doesn,t stop running. Compressor goes on & off as normal.. What controls the condenser fan? Is there a thermistor ? Do i need a new circuit bd ?
For model number GFSS2HCYCSS
Hi Pete, thank you for your inquiry. Based on our research, the control board controls the condenser fan. We would suggest replacing the control board, part number PS2371164, to fix the issue. Glad to be of help!
Hello Roberto, thank you for your inquiry. You can reset your appliance by simply unplugging it for 1 minute and then plugging back in. Glad to be of assistance!
Was this helpful?
Thank you for voting!
Sam
May 28, 2024
How to reset the temperature on my GE refrigerator model GFSS2HCYCSS
For model number GFSS2HCYCSS
Hi Sam, thank you for reaching out. Try resetting the control panel by turning off power to the refrigerator briefly. Unplug the refrigerator or turn it off at the circuit breaker for 30 seconds to reset the control. To adjust the freezer and refrigerator temperature, simply press the freezer/refrigerator cooler or warmer key multiple times. The normal setting should be 0 in the freezer and 38 in the refrigerator section. Glad to be of help!
The freezer in my side-by-side kept warming up -- often 20 degrees or more, which of course caused the fresh food side to warm up also. I do a lot of jump-in-with-both-feet home repairs, but never on a large appliance. Not having an ohmmeter, which cost about $100 for a reliable one, I took the symptoms to the internet. Countless self-hel
... Read morep sites and U-Tube videos later, I was positive it was one of two possible problems, either the defrost thermostat was broken and the defroster wasn't coming out of its cycle or the temperature sensor wasn't reading the correct temp and thus kicking in the fan motor when needed. Fortunately I found both parts easily on PartSelect.com and the total cost for both, including shipping, was $30, less than 1/3 of the cost of an ohmmeter. Not knowing for sure which part it was that was bad, I ordered both, figuring, since I had to pull out the panel anyway, I might just as well replace them both ... the price was right. (In retrospect I should have order 4 Temperature Sensors as my fridge has two in both the freezer side and the Fresh Food side. Any one of them being bad could have caused the same problem. Fortunately, I was lucky because it was either ONLY the Defrost Thermostat or I just happened to pick the right Sensor, but the repair worked.)
The repair was easy: Unplug the power. A Nut Driver removed the four screws holding on the panel in the back of the freezer. A screw driver removes the one screw holding the lamp cover in place. Remove the light bulbs, pull off the panel and right above the freezer coils you'll see both parts -- plain as day. (If your coils are clogged with ice, you will probably need de-ice first.) Cut the wires to both parts as close to the parts as you can to leave as much wire exposed as possible. Strip the ends of all four wires about 1/2 inch and also on the new parts. Match up the wires in the fridge to the wires on the parts and twist the ends together (Note: both wires on the Sensor are white so they match up either way, but the two wire on the thermostat will need to match up orange to orange and pink to pink.) I used silicone filled wire nuts, which you can buy at any hardware store or use your own wing nuts and fill them with silicone or shoe goo which works just as well ... anything to keep the moisture out and prevent the wires ends from corroding. Tuck the wires up and replace the panel, light bulbs and light cover That's it. Very easy. By far the hardest part was wedging my wide body into the narrow freezer compartment. Some one-handed work added a little extra time to the project.
In my case the freezer fan didn't kick in for about twenty minutes after I plugged it back in, but I assume that it either begins in the defrost mode or it takes that long for it to reset itself ... either way the repair worked great.
I went to a GE repair center to explain my problem, the service center reccomended that I have a techinician come out o look at it. $75.00 for the visit and what ever labor and materials wuld cost.
I went on line to see if there were others having this same problem and found that there were many with the same problem.
... Read more />After reading some of the ways that people found out what was wrong ...it became a matter of three components, the timer, heater or thermostat.
I tried the most common component and the less expensive one first , the thermostat switch I installed it very easily snipping two wires and attaching the news using wire nuts I used the diagram on this website to pinpoint the component and there has not been a problem since.
