11747067-1-S-Whirlpool-WP9743002-Upper Wheel Gasket
11747067-1-S-Whirlpool-WP9743002-Upper Wheel Gasket 11747067-2-S-Whirlpool-WP9743002-Upper Wheel Gasket http://www.partselect.com/Schematics/Whirlpool/GWOHKAJE.gif

Upper Wheel Gasket

PartSelect Number PS11747067

Sold individually.

This part works with the following brands: Whirlpool, Admiral, Estate, Inglis, Kenmore, KitchenAid, Roper, Maytag, Crosley, Jenn-Air, Hardwick, Magic Chef, Amana, Caloric & Glenwood.

Compare At

$7.36

You Save

$1.23

Your Price

$6.13
Get this part fast. Average delivery time via standard shipping: 1.8 days.

Installation Instructions Provided by PartSelect customers like you.

Average Repair Rating: 3.8 / 5.0, 4 reviews What's this?
1-4 of 4


22 of 35 people found this instruction helpful

Parts Used:
Level of Difficulty: A Bit Difficult
Time to do repair: 30 - 60 mins
Tools: Screw drivers
Customer: Ray from Colton, OR

The top rack began to fall out of the track on the right side. Replacing it into the track was not a permanent fix. I could not visually see anything wrong but obviously something was. A web search quickly brought up a picture of that area of our machine. I ordered the part and upon installation,

I had to getto the side of the machine. After that, it was simply removing 4 screws and removing the old part, replacing the screws and putting the rack back in the track.

Help other customers find the most helpful instructions.

Were these instructions helpful?

1 of 1 people found this instruction helpful

Parts Used:
Level of Difficulty: Really Easy
Time to do repair: 30 - 60 mins
Tools: Screw drivers, Socket set
Customer: Mitchell from NEW ROCHELLE, NY

Lower wheel broke off upper wheel mount and dishrack wheel broke on the opposite side

Have all the tools at your disposal. Remove top rack after removing the track stop. Remove 2 screws that hold unit in to cabinet. They are under the little caps. That is when you need the magnet for the screwdriver. Wiggle tub out of space and remove hex head screws that hold the wheel mount. Save the gasket for install. Put things back the way they came off. Changing the upper dishrack requires some twisting and gentle pressure. Even if one is broken, replace all 4. Put back the screws to the cabinet and the end caps.

Help other customers find the most helpful instructions.

Were these instructions helpful?

2 of 13 people found this instruction helpful

Parts Used:
Level of Difficulty: Really Easy
Time to do repair: 15 - 30 mins
Tools: Screw drivers
Customer: Carolyn from Garland, TX

Rack tracks were broken

Loosen screws and pulled out dishwasher,
remove screws on the old rack tracks and screwed new rack tracks on. Pushed back in dishwasher and tightened screws. Very easy
to replace.

Help other customers find the most helpful instructions.

Were these instructions helpful?

11 of 41 people found this instruction helpful

Parts Used:
Level of Difficulty: Really Easy
Time to do repair: 15 - 30 mins
Tools: Screw drivers
Customer: Rick from Murfreesboro, TN

Broken wheel on top dish basket

I broke the wheel off the dishrack when I slipped and hit the edge. I was able to find the part easily on the part select website. I ordered and received the part in 3 days. Very easy fix even for a novice like me.
Thanks part select.
Rick Barber

Help other customers find the most helpful instructions.

Were these instructions helpful?

1-4 of 4
